Bischoff & Bischoff
Operating manual
Pyr start plus+
2
Contents
1| Preliminary note 4
1.1. Important safety instructions
2| Indications / Contraindications 7
3| Purpose 8
4| Declaration of conformity 8
5| Scope of supply and checking the delivery 9
6| Overview of the wheelchair 11
7| Assembly/adjustments 13
7.1. Folding and unfolding
7.2. Legrests
7.3. Side parts
7.4. Seat
7.5. Wheelbase
7.6. Brake
7.7. Wheels and tyres
7.8. Quick-release axles
7.9. Tip assist
8| Accessories 25
8.1. Anti-tip protection
8.2. Safety belt
8.3. Drum brake
Pyro start
plus+
Bisch ff & Bisch ff GmbH • 27.08.2012 3
English
9| Use 27
9.1. Getting in and out from the side
9.2. Getting in and out from the front
9.2. Negotiating stairs and high steps
10| Driving 29
11| Technical data 31
12| Transport 32
12.1. Transporting the wheelchair
12.2. Seat in a vehicle for transporting disabled
people
13| Storage / shipping 38
14| Reuse 38
15| Repair 39
16| Disposal 39
17| Appendices: 40
Care, hygiene and maintenance advice
Hygiene and risk assessment
Maintenance schedule
18| Warranty 48
4
1. 1. Preliminary n te
Dear User
By purchasing your Bischoff & Bischoff Pyro start plus+
folding wheelchair, you are getting a top German product
that sets new standards in term of its flexibility.
The wheelchair was designed to offer you a lot of benefits
and to meet your needs. The many varied setting options
and the optimum adjustability in terms of seat height,
seat angle and lower leg length means the Pyro start
plus+ can be adjusted to your individual body size.
The Pyro start plus+ is intended both for indoor and out-
door use.
This operating manual is to help you become more famili-
ar with the operation and use of the wheelchair.
English
Pyro start
plus+
Bisch ff & Bisch ff GmbH • 27.08.2012 5
1.1 Important safety
instructions
In order to avoid toppling and dangerous situations, you
should practice handling your new wheelchair in a flat,
easily manageable area. We recommend that someone
accompanies you in this situation.
• The person accompanying you should be physically and
mentally capable of operating a wheelchair
• Before using the wheelchair, please check whether all
fitted parts are properly fixed.
• Never lift the wheelchair by parts that are not securely
fixed (armrests or legrests).
• Make sure that the quick-release axles are seated pro-
perly in the axle holders, otherwise there is a danger of
injury.
• Please note that the risk of tipping is increased by
shifts in weight (e.g. strong upper body movements or
negotiating obstacles).
• Steps and larger obstacles may only be negotiated with
the help of at least two accompanying people. Use lif-
ting points 1 and 2 for this (see overview of the
wheelchair). If equipment such as access ramps, lifts or
step climbing aids are available, these should be used.
•When using on a slope, it must be noted that there is a
risk of tipping as from 12% (7°). Use of anti-tip protec-
tion is recommended.
• The seat materials comply with the flammability resi-
stance requirements of N 1021-1 and N 1021-2.
Nevertheless, you should exercise the necessary caution
when smoking and you should not put the cigarette
down on the wheelchair.
6
• Avoid running into obstacles without braking (steps,
kerbs) or "jumping down" from one level to another.
• Avoid using on uneven, loose surfaces.
• Someone should be asked to accompany you when
negotiating obstacles (steps, etc.). Use the tip assist
(see overview of the wheelchair) to tip the wheelchair in
an appropriate way.
• When getting into or out of the wheelchair, apply both
locking brakes.
• Make sure your tyres have sufficient tread depth.
• Always follow the road traffic regulations when on the
road.
• The passive lighting (reflectors) on your wheelchair must
always be visible to other road users.
• The locking brake must not be used to brake when
moving.
• When braking from fast speeds or on long downward
slopes by using the push rims, fingers and palms get
hot. Caution, risk of burning!
• We recommend the use of leather gloves outdoors.
These increase grip as well as protecting your fingers
and palms from dirt and injury at the same time.
• Please note that upholstery parts which are exposed to
direct solar radiation heat up and can cause injury to
the skin on contact. You should therefore cover these
parts or protect the wheelchair from solar radiation..
• When transferring between wheelchair and bed, please
always ensure that:
- both locking brakes are applied
- the side part on the side for getting in / out is swung
back.
English
Pyro start
plus+
Bisch ff & Bisch ff GmbH • 27.08.2012 7
- the foot plates are folded upwards (for getting in /
out), are swung inwards/outwards, or if necessary
removed.
2. Indication /
Contraindication
Inability to walk or severe walking disability as a
result of:
• paralysis
• loss of limbs
• meromelia/limb deformation
• joint contractures/joint damage
• other ailments
Use of the wheelchair is not suited for:
• perception disorders
• severe disturbances of equilibrium
• loss of limbs on both arms
• contractures/damage to joints on both arms
• inability to sit
• reduced or insufficient eyesight
8
3. Purpose
The wheelchair is made solely to increase mobility and to
transport people with impaired mobility in accordance
with the above-mentioned indications.
To be noted:
We are only able to provide a warranty if the product is
used in accordance with the specified conditions and for
the intended purposes
4. Declaration of
conformity
As manufacturer of the product, B&B declares that the
„Pyro light plus+“ wheelchair fully complies with the requi-
rements of the 93/42/ C directive.
English
Pyro start
plus+
Bisch ff & Bisch ff GmbH • 27.08.2012 9
5. Scope of supply and
checking the delivery
The scope of supply in the special box includes:
• 1 wheelchair, folded
• 1 air pump (only for pneumatic tyres)
• 1 operating manual
• 1 set of tools (3 Allen keys, SW3, SW4 and SW6, 1 cros-
shead screwdriver, 2 ring spanners, SW10 and SW13)
All B+B wheelchairs are subjected to a proper final in-
house inspection and provided with the C mark.
B+B wheelchairs are supplied folded in a special box.
Supply, assembly and training in use of the wheelchair are
carried out by the qualified medical supplies retailer.
If shipped by rail or a forwarding agent, the goods are to
be checked with regard to transportation damage at once
in the presence of the delivery company.
If there is any damage, the following points are to be
adhered to:
•Recording the facts of the case
•Producing a declaration of assignment; all claims arising
from the damage are assigned to the delivery company.
•Returning the record of the facts of the case, waybill and
declaration of assignment to B+B.
10
In the event of transport damage...
1. Leave the goods and packaging unaltered in any case
and do not use the goods yet.
2. Report the damage in writing to the transport company
as shown below.
3. Then contact our customer service department
(+49 (0)700/6000 7070)
4. To be able to register claims for compensation with
transport insurance firms, representatives of the trans-
port company making the delivery must be informed
about any damage in good time.
Damage or loss visible externally must be certified on the
accompanying documentation by the deliverer before
accepting the shipment.
Hidden damage which only becomes visible when
unpacking must be reported to the transport company
immediately in writing.
Specific timescales must be adhered to:
• Parcel services and post within 24 hours
• Rail within 7 days
• Shippers within 4 days of receipt of the shipment.
