BITMAIN ANTMINER S17e Bedienungsanleitung
S17e Server Installation
Guide
Document Version 1.0
Oct. 2019
© Copyright Bitmaintech Pte.Ltd. 2007 –2019. All rights reserved.
Bitmaintech Pte.Ltd. (Bitmain) reserves the right to make corrections, modifications, enhancements, improvements, and other
changes to its products and services at any time and to discontinue any product or service without notice.
Customers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All products are sold subject to Bitmain's terms and conditions of sale supplied at the time of order acknowledgment.
Bitmain warrants performance of its products to the specifications applicable at the time of sale in accordance with Bitmain's standard
warranty. Testing and other quality control techniques are used to the extent Bitmain deems necessary to support this warranty.
Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.
Bitmain assumes no liability for third-party applications assistance. Customers are responsible for their products and applications
using Bitmain components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.
Bitmain does not warrant or represent that any license, either express or implied, is granted under any Bitmain patent right, copyright
or other Bitmain intellectual property right relating to any combination, machine, or process in which Bitmain products or services
are used. Information published by Bitmain regarding third-party products or services does not constitute a license from Bitmain to
use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party
under the patents or other intellectual property of the third party, or a license from Bitmain under the patents or other intellectual
property of Bitmain.
Resale of Bitmain products or services with statements different from or beyond the parameters stated by Bitmain for that product
or service voids all express and any implied warranties for the associated Bitmain product or service and is an unfair and deceptive
business practice. Bitmain is not responsible or liable for any such statements.
All company and brand products and service names are trademarks or registered trademarks of their respective holders.
- 2 -
S17e Server Installation Guide
All text and figures included in this publication are the exclusive property of Bitmaintech Pte.Ltd. (Bitmain), and may not be copied,
reproduced, or used in any way without the express written permission of Bitmain. Information in this document is subject to change
without notice and does not represent a commitment on the part of Bitmain. Although the information in this document has been
carefully reviewed, Bitmain does not warrant it to be free of errors or omissions. Bitmain reserves the right to make corrections,
updates, revisions or changes to the information in this document.
Bitmaintech Pte.Ltd.
Tel:+86-400-890-8855
www.bitmain.com
- 3 -
S17e Server Installation Guide
Table of Contents
1. Overview .............................................................................................................................................4
1.1 S17e Server Components .................................................................................................................5
1.2 Specifications....................................................................................................................................7
2. Setting Up the Server ...........................................................................................................................8
3. Configuring the Server .......................................................................................................................10
4. Monitoring Your Server......................................................................................................................11
5. Administering Your Server .................................................................................................................12
5.1 Checking Your Firmware Version....................................................................................................12
5.2 Upgrading Your System ..................................................................................................................12
5.3 Modifying Your Password...............................................................................................................13
5.4 Restoring Initial Settings.................................................................................................................13
Environmental Requirements ................................................................................................................14
Regulations............................................................................................................................................16
- 4 -
S17e Server Installation Guide
1.Overview
1. Overview
The S17e server is Bitmain’s newest version in the 17e server series. Power supply APW9+ is part of S17e server. All S17e servers
are tested and configured prior to shipping to ensure easy set up.
Front View Back View
Caution:
1.The equipment must be connected to an earthed mains socket-outlet. The socket-outlet shall be installed near the
equipment and shall be easily accessible.
2.The equipment has two power inputs, only by connecting those two power supply sockets simultaneously can the
equipment run. When the equipment is powered off, be sure to power off all power inputs.
3.Please refer to the layout above to place your goods in usage in case of any damage.
4. DO NOT remove any screws and cables tied on the product.
5. DO NOT PRESS the metal button on the cover.
- 5 -
S17e Server Installation Guide
1.Overview
1.1 S17e Server Components
The main components and controller front panel of S17e servers are shown in the following figure:
- 6 -
S17e Server Installation Guide
1.Overview
APW9+ Power Supply:
Note:
1.Power supply APW9+ is part of S17e server. For detailed parameters, please refer to the specifications below.
2.Additional two power cords are needed.
- 7 -
S17e Server Installation Guide
1.Overview
1.2 Specifications
Notes:
(1-1) Including PSU size
(1-2) Including PSU weight
Product Glance
Value
Version
Model No.
Crypto Algorithm/Coins
S17e
266-A
SHA256/BTC/BCH
Hashrate, TH/s
64.00
Reference power efficiency on wall @25°C, J/TH
45.00+10%
Detailed Characteristics
Value
Min
Typ
Max
Hardware Configuration
Miner Size (Length*Width*Height, w/o package), mm(1-1)
338.0*175.0*304.0
Net weight, kg(1-2)
10.50
- 8 -
S17e Server Installation Guide
2.Setting Up the Server
2. Setting Up the Server
To set up the server:
1. Go to the following site:
https://shop.bitmain.com/support.htm?pid=00720160906053730999PVD2K0vz0693
2. Download the following file: IPReporter.zip.
3. Extract the file.
4. Right-click IPReporter.exe and run it as Administrator.
5. Select one of the following options:
■Shelf, Step, Position –suitable for farm servers to mark the location of the servers.
■Default –suitable for home servers.
6. Click Start.
The file IPReporter.zip is supported by Microsoft Windows only.
The default DHCP network protocol distributes IP addresses automatically.
- 9 -
S17e Server Installation Guide
2.Setting Up the server
7. On the controller board, click the IP Report button. Hold it down until it beeps (about 5 seconds).
The IP address will be displayed in a window on your computer screen.
8. In your web browser, enter the IP address provided.
9. Proceed to login using root for both the username and password.
10. In the Network section, you can assign a DHCP IP address (optional).
11. Click Save & Apply.
- 10 -
S17e Server Installation Guide
3.Configuring the Server
3. Configuring the Server
Setting Up the Pool
To configure the server:
1. click General Settings.
2. Set the options according to the following table:
Option
Description
Pool URL
Enter the URL of your desired pool.
The S17e servers can be set up with three mining pools, with decreasing priority
from the first pool (pool 1) to the third pool (pool 3).
The pools with low priority will only be used if all higher priority pools are offline.
Worker
Your worker ID on the selected pool.
Password
The password for your selected worker.
3. Click Save & Apply to save and restart the server.
