BIXOLON SRP-350plusV Gebrauchsanweisung

Bluetooth Connection Manual

Thermal POS Printer

Ver. 1.00

http://www.bixolon.com

Bluetooth Connection Manual

Ver.1.00

- 2 -

Table of Contents

Copyright......................................................................................................................... 3

1. Introduction................................................................................................................4

2. Precaution...................................................................................................................4

3. Bluetooth Information Printing ...............................................................................5

3-1 Bluetooth Information Print ........................................................................................5

3-2 Initializing Bluetooth Setting .......................................................................................6

4. Bluetooth Connection Instructions ......................................................................... 7

4-1 iOS Device ......................................................................................................................7

4-2 Android Device ..............................................................................................................9

5. Troubleshooting ....................................................................................................... 11

Bluetooth Connection Manual

Ver.1.00

- 3 -

This user manual and all property of the product are protected under copyright law.

It is strictly prohibited to copy, store, and transmit the whole or any part of the manual

and any property of the product without the prior written approval of BIXOLON Co.,

Ltd.

The information contained herein is designed only for use with this BIXOLON product.

BIXOLON is not responsible for any direct or indirect damages, arising from or

related to use of this information.

• The BIXOLON logo is the registered trademark of BIXOLON Co., Ltd.

•All other brand or product names are trademarks of their respective companies or

organizations.

BIXOLON Co., Ltd. maintains ongoing efforts to enhance and upgrade the functions

and quality of all our products.

In the following, product specifications and/or user manual content may be changed

without prior notice.

Caution

Some semiconductor devices are easily damaged by static electricity. You should turn

the printer “OFF”, before you connect or remove the cables on the rear side, in order

to guard the printer against the static electricity. If the printer is damaged by the static

electricity, you should turn the printer “OFF”.

Bluetooth Connection Manual

Ver.1.00

- 4 -

1. Introduction

This Bluetooth Connection Manual provides information on the connection of

Bluetooth-enabled iOS or Android Host devices with the printer.

2. Precaution

1) To connect the printer with another device via Bluetooth, the devices must be

within 80m of one another. The connection is broken if the distance between devices

exceeds 80m.

2) The maximum separating distance may be shortened if transmission obstacles,

such as cement walls, are present.

3) If a device (such as a microwave oven, wireless LAN, etc.) that uses the same

frequency is present, transmission may be interrupted. Separate the printer and

Bluetooth-enabled device from such interrupting devices by a distance of at least 5m.

Bluetooth Connection Manual

Ver.1.00

- 5 -

3. Bluetooth Information Printing

After the printer has finished booting, open the printer cover and press and hold the

FEED Button. This will cause the interface setting confirmation mode.

Then add the paper, close the cover, and check that the following message is printed.

Errors LED is toggled/blinked until Bluetooth is booted.

The number of Bluetooth setting information may be different for each

interface type of the product.

3-1 Bluetooth Information Print

• If the above message is printed, select Mode 1, and you will see the following

Bluetooth data. (To select Mode 1, press the Feed button once quickly/ once long.)

Checking Interface Setting

0: Exit

1: LAN Information Print

2: LAN Factory Reset and Reboot Printer

3: B/T Information Print

4: B/T Factory Reset and Reboot Printer

5 or more: None

Select Modes by Feed button control

as below.

Step 1. Short-press as many times as

The mode number to choose.

Step 2. Long-press over 1 second.

*e.g. To choose Mode 2, press Feed

Button 3 times(short-short-long)

Bluetooth Connection Manual

Ver.1.00

- 6 -

3-2 Initializing Bluetooth Setting

• If the above message is printed, select Mode 2, and you will see the following

Bluetooth information. (To select Mode 2, press the Feed button twice quickly /

once long.)

After the above message is printed, the printer will automatically reboot.

B/T Factory Reset OK! Reboot Printer.

Bluetooth Connection Manual

Ver.1.00

- 7 -

4. Bluetooth Connection Instructions

4-1 iOS Device

1) Select the icon. 2) Select “Bluetooth”.

Bluetooth Connection Manual

Ver.1.00

- 8 -

3) Select the printer to connect. 4) If PIN is required, enter PIN

(default: 0000).

5) Select “Pair” 6) Bluetooth communication is

available.

Bluetooth Connection Manual

Ver.1.00

- 9 -

4-2 Android Device

1) Select the icon. 2) Select “Bluetooth”.

3) Select the printer to connect. 4) If PIN is required, enter PIN

(default: 0000).

Bluetooth Connection Manual

Ver.1.00

- 10 -

5) Select “OK”. 6) Bluetooth communication is

available.
