BIXOLON SRP-F310 Bedienungsanleitung

User’s Manual

SRP-F310/312

Front Exit Thermal Printer

Rev. 1.00

http://www.bixolon.com

Rev. 1.00 - 2 -

SRP-F310/312

■Safety Precautions

In using the present appliance, please keep the following safety regulations in order to

prevent any hazard or material damage.

WARNING

Violating following instructions can cause serious injury or death.

Do not bend the cable by force or leave it under any

heavy object.

• A damaged cable can cause a fire.

Do not plug in or unplug with your hands wet.

•You can be electrocuted.

Keep the plastic bag out of children’s reach.

•If not, a child may put the bag on his head.

Do not pull the cable to unplug.

•This can damage the cable, which is the origin of a fire or a

breakdown of the printer.

You must use only the supplied adapter.

•It is dangerous to use other adapters.

Do not plug several products in one multi-outlet.

• This can provoke over-heating and a fire.

• If the plug is wet or dirty, dry or wipe it before usage.

• If the plug does not fit perfectly with the outlet, do not plug in.

•Be sure to use only standardized multi-outlets.

PROHIBITED

PROHIBITED PROHIBITED

ONLY SUPPLIED ADAPTER

PROHIBITED

Rev. 1.00 - 3 -

SRP-F310/312

CAUTION

Violating following instructions can cause slight wound or damage the appliance.

Do not use the printer when it is out of order. This

can cause a fire or an electrocution.

•Switch off and unplug the printer before calling your dealer.

Do not let water or other foreign objects in the

printer.

•If this happened, switch off and unplug the printer before

calling your dealer.

Use only approved accessories and do not try to

disassemble, repair or remodel it for yourself.

•Call your dealer when you need these services.

• Do not touch the blade of auto cutter.

Install the printer on the stable surface.

•If the printer falls down, it can be broken and you can hurt

yourself.

Keep the desiccant out of children’s reach.

•If not, they may eat it.

If you observe a strange smoke, odor or noise from

the printer, unplug it before taking following

measures.

• Switch off the printer and unplug the set from the mains.

•After the disappearance of the smoke, call your dealer to

repair it.

TO UNPLUG

PROHIBITED

DISASSEMBLING

PROHIBITED

TO UNPLUG

PRINTER

DEALER

PRINTER

Rev. 1.00 - 4 -

SRP-F310/312

■Warning - U.S.A

This equipment has been tested and found to comply with the limits for a Class A digital

device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

■Notice - Canada

This Apparatus complies with class “A” limits for radio interference as specified in the

Canadian department of communications radio interference regulations.

Get appareil est conforme aux normes class “A” d’interference radio tel que specifier par

ministre canadien des communications dans les reglements d’interference radio.

■Caution

Some semiconductor devices are easily damaged by static electricity. You should turn the

printer “OFF”, before you connect or remove the cables on the rear side, in order to guard

the printer against the static electricity. If the printer is damaged by the static electricity, you

should turn the printer “OFF”.

■Waste Electrical and Electric Equipment (WEEE)

This marking shown on the product or its literature, indicates that is should not

be disposed with other household wastes at the end of its working life, To

prevent possible harm to the environment or human health from uncontrolled

waste disposal, please separate this from other types of wastes and recycle it

responsibly to promote the sustainable reuse of material resources. Household

users should contact either the retailer where they purchased this product, or

their local government office, for details of where and how they can take this item for

environmentally safe recycling. Business users should contact their supplier and check the

terms and conditions of the purchase contract. This product should not be mixed with other

commercial wastes for disposal.

■Label Material

* Control Label: PC

* Other Labels: PET

Rev. 1.00 - 5 -

SRP-F310/312

■Introduction

The SRP-F310/312 Roll Printer are designed for use with electronic instruments such as

system ECR, POS, banking equipment, computer peripheral equipment, etc.

The main features of the printer are as follows:

1. High speed printing : 63.82/72 lines per second.

2. Low noise thermal printing.

3. RS-232 (IFE-S TYPE), Parallel (IFE-P TYPE), Ethernet(10/100BaseT),

WLAN(USB adaptor), USB2.0(High Speed).

4. The data buffer allows the unit to receive print data even during printing.

5. Peripheral units drive circuit enables control of external devices such as cash drawer.

6. Characters can be scaled up to 64 times compared to it’s original size.

7. Bar code printing is possible by using a bar code command.

8. Different print densities can be selected by DIP switches.

9. IPX 1

※For network information, refer to the ‘Network user manual’

Please be sure to read the instruction in this manual carefully before using your new

SRP-F310/312.

※NOTE

The socket-outlet shall be near the equipment and it shall be easy accessible.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and

quality of all our products. In following, product specifications and/or user manual content

may be changed without prior notice.

Rev. 1.00 - 6 -

SRP-F310/312

■Table of Contents

1. Setting Up the Printer ................................................................................................... 7

1-1 Unpacking.................................................................................................................. 7

1-2 Connecting the Cables .............................................................................................. 8

1-2-1 Serial Interface (RS-232C) ............................................................................ 8

1-2-2 Parallel Interface (IEEE1284) ........................................................................ 9

1-2-3 USB Interface .............................................................................................. 10

1-3 Connecting the Drawer ............................................................................................ 10

1-4 Setting the Dip Switches.......................................................................................... 11

1-4-1 Serial Interface .............................................................................................11

1-4-2 Parallel & USB Interface...............................................................................11

1-5 Installing or Replacing the Paper Roll...................................................................... 12

1-6 Adjustments and Settings ........................................................................................ 14

1-7 Using the Printer...................................................................................................... 14

1-8 Connecting the computer......................................................................................... 15

1-9 Connecting the Power Supply ................................................................................. 15

2. Self Test....................................................................................................................... 16

3. Hexadecimal Dumping ............................................................................................... 17

4. Specification ............................................................................................................... 18

5. Appendix .....................................................................................................................19

5-1 Cleaning Printer....................................................................................................... 19

Rev. 1.00 - 7 -

SRP-F310/312

1. Setting Up the Printer

1-1 Unpacking

Your printer box should include these items. If any items are damaged or missing, please

contact your dealer for assistance.

SRP-F310/312 CD

Roll Paper Manual Power Cord

Rev. 1.00 - 8 -

SRP-F310/312

1-2 Connecting the Cables

You can connect up the three cables to the printer. They all connect to the connector panel

on the back of the printer, which is shown below:

※NOTE

Before connecting any of the cables, make sure that both the printer and the host are

turned off.

1-2-1 Serial Interface (RS-232C)

※When the Dip Switch is “ON” on the Serial Interface Board,

DTR and RTS are connected each other.

Pin No. Signal name Direction Function

1 FG - Frame Ground

2 TxD Output Transmit Data

3 RxD Input Receive Data

4 RTS Output Ready To Send

5 CTS Input Clear To Send

6 DSR Input Data Set Ready

7 SG - Signal Ground

20 DTR Output Data Terminal Ready

IFE-S TYPE

USB

connector

ETHERNET

connector

Interface connector

PRINTER

SIDE (25P)

HOST

SIDE (25P)

PRINTER

SIDE (25P)

HOST

SIDE (9P)

Rev. 1.00 - 9 -

SRP-F310/312

1-2-2 Parallel Interface (IEEE1284)

Pin No. Source Compatibility Mode Nibble Mode Byte Mode

1 Host nStrobe HostClk HostClk

2 Host / Printer Data 0 (LSB) - Data 0 (LSB)

3 Host / Printer Data 1 - Data 1

4 Host / Printer Data 2 - Data 2

5 Host / Printer Data 3 - Data 3

6 Host / Printer Data 4 - Data 4

7 Host / Printer Data 5 - Data 5

8 Host / Printer Data 6 - Data 6

9 Host / Printer Data 7 (MSB) - Data 7 (MSB)

10 Printer nAck PtrClk PtrClk

11 Printer Busy PtrBusy /Data3,7 PtrBusy

12 Printer Perror AckDataReq/Data2,6 AckDataReq

13 Printer Select Xflag /Data1,5 Xflag

14 Host nAutoFd HostBusy HostBusy

15 NC NC NC

16 GND GND GND

17 FG FG FG

18 Printer Logic-H Logic-H Logic-H

19~30 GND GND GND

31 Host nInit nInit nInit

32 Printer nFault nDataAvail /Data0,4 nDataAvail

33 GND ND ND

34 Printer DK_Status ND ND

35 Printer +5V ND ND

36 Host nSelectIn 1284-Active 1284-Active

IFE-P TYPE

USB

connector

ETHERNET

connector

Interface connector

Rev. 1.00 - 10 -

SRP-F310/312

1-2-3 USB Interface

Pin No. Signal Name Assignment (Color) Function

Shell Shield Drain Wire Frame Ground

1 VBUS Red Host Power

2 D- White Data Line(D-)

3 D+ Green Data Line(D+)

4 GND Black Signal Ground

1-3 Connecting the Drawer

※WARNING

Use a drawer that matches the printer specification. Using an improper drawer may

damage the drawer as well as the printer.

※CAUTION

Do not connect a telephone line to the drawer kick-out connector; otherwise the printer and

the telephone line may be damaged.

Plug the drawer cable into the drawer kick-out connector on the back of the printer next to

the power supply connector.

Pin No. Signal name Direction

1 Frame ground -

2 Drawer kick- out drive signal 1 Output

3 Drawer open/close signal Input

4 +24V -

5 Drawer kick- out drive signal 2 Output

6 Signal ground -

ETHERNET

connector

USB

connector

Andere Handbücher für SRP-F310

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere BIXOLON Drucker Handbücher

BIXOLON

BIXOLON SRP-F310 Bedienungsanleitung

BIXOLON

BIXOLON SRP-350III Montageanleitung

BIXOLON

BIXOLON SPP-R410 Bedienungsanleitung

BIXOLON

BIXOLON SRP-380II Bedienungsanleitung

BIXOLON

BIXOLON SRP-350PG - SRP 350 B/W Direct Thermal... Bedienungsanleitung

BIXOLON

BIXOLON SRP-350plusIII SRP-352plusIII Bedienungsanleitung

BIXOLON

BIXOLON SPP-R200III Gebrauchsanweisung

BIXOLON

BIXOLON SRP-350 PlusA Bedienungsanleitung

BIXOLON

BIXOLON SRP-350IIOBEi Bedienungsanleitung

BIXOLON

BIXOLON SRP-350V Montageanleitung

BIXOLON

BIXOLON SRP-S3000 Bedienungsanleitung

BIXOLON

BIXOLON SRP-352plusA&C Bedienungsanleitung

BIXOLON

BIXOLON SRP-370 - Two-color Direct Thermal Printer Bedienungsanleitung

BIXOLON

BIXOLON SRP-QE300 Bedienungsanleitung

BIXOLON

BIXOLON SRP-330II Installations- und Betriebsanleitung

BIXOLON

BIXOLON SRP-372 Bedienungsanleitung

BIXOLON

BIXOLON SPP-R200II Bedienungsanleitung

BIXOLON

BIXOLON SRP-Q300 Bedienungsanleitung

BIXOLON

BIXOLON SRP-350plusIII SRP-352plusIII Bedienungsanleitung

BIXOLON

BIXOLON Bixolon SRP-270 Bedienungsanleitung

BIXOLON

BIXOLON SRP-F310 Bedienungsanleitung

BIXOLON

BIXOLON SRP-350II Installations- und Betriebshandbuch

BIXOLON

BIXOLON SRP-Q302 Installations- und Betriebsanleitung

BIXOLON

BIXOLON SPP-L3000 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
