BIXOLON SRP-S200 Gebrauchsanweisung

Network Connection Manual

SRP-S200

LINERLESS PRINTER

Ver. 1.00

http://www.bixolon.com

Ver. 1.00

- 2 -

SRP-S200

Table of Contents

1. Manual Information ............................................................................................ 3

2. Specifications........................................................................................................ 3

3. How to Connect .................................................................................................... 4

3-1 Checking Network Setting...................................................................................................................... 4

3-1-1 LAN.............................................................................................................................................. 4

3-1-2 LAN Setting Values.................................................................................................................... 5

4. Ethernet Test by using Windows Test Page....................................................... 6

5. Troubleshooting................................................................................................. 13

Ver. 1.00

- 3 -

SRP-S200

1. Manual Information

This manual provides information on the connection of wireless network with the

printer.

This document contains proprietary information of BIXOLON and its affiliates.

You may utilize the information solely for the purpose of facilitating authorized sales

and service of, or developing software and similar products for authorized use with,

BIXOLON products, provided that such proprietary information may not be used,

reproduced, or dis-closed to any other parties for any other purpose without the

prior written permission of BIXOLON.

BIXOLON has no liability for loss or damage arising from or relating to your use of

the information in the document.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and

quality of all our products. In following, product specifications and/or user manual

content may be changed without prior notice.

2. Specifications

CATEGORIES

FEATURE

IMPLEMENTATION

LAN

Specification

Interface

10/100 Base-T All in one(Auto detection)

Protocol

DHCP Client, HTTP, ARP, ICMP, IPv4, TCP, UDP

Ver. 1.00

- 4 -

SRP-S200

3. How to Connect

LAN can be configured through the printer’s LAN interface.

3-1 Checking Network Setting

3-1-1 LAN

After the printer has finished booting, open the printer cover and press and hold the

FEED Button. This will cause the interface setting confirmation mode.

Then add the paper, close the cover, and check that the following message is printed.

FEED Button

Cover Open Lever

Ver. 1.00

- 5 -

SRP-S200

If the above message is printed, select Mode 1, and you will see the following LAN

data. (To select Mode 1, press the Feed button once quickly/ once long.)

3-1-2 LAN Setting Values

Classification

Item

Description

Input Range

Network

Inactivity Time

TCP connection hold time

0~3600 integer

IP Assignment

Method

IP Assignment Method DHCP/Manual

IP Address

Printer IP

IP Address

Subnet Mask

Subnet mask

IP Address

Gateway

Default Gateway

IP Address

Note

For changing network setting values using Net configuration

tool, Refer to ‘Net configuration tool manual’.

Checking Interface Setting

0: Exit

1: LAN Information Print

2: LAN Factory Reset and Reboot Printer

3 or more: None

Select Modes by Feed button control

as below.

Step 1. Short-press as many times as

The mode number to choose.

Step 2. Long-press over 1 second.

*e.g. To choose Mode 2, press Feed

Button 3 times(short-short-long)

Ver. 1.00

- 6 -

SRP-S200

4. Ethernet Test by using Windows Test Page

You can use the Windows printer driver as shown below when there is no test

program. Operating systems that allow you to use the Windows printer driver are

Windows, XP, Server 2003, VISTA, 2008 Server, 7, 8, 10.

Note

You can download the latest version of Windows driver from

our home page. (www.bixolon.com)

1) Double-click the Windows Driver installation file.

2) Click Install.

Ver. 1.00

- 7 -

SRP-S200

3) Select Installation and click Next..

4) Select Model Name and click Next.

Ver. 1.00

- 8 -

SRP-S200

5) Select Ethernet and click Add TCP/IP Port.

6) Enter the IP address and port number, and then click Next.

Ver. 1.00

- 9 -

SRP-S200

7) Click Next.

8) Click Next.

Ver. 1.00

- 10 -

SRP-S200

9) Click Next.

10) Click Finish.
