Black Stone 1866 Bedienungsanleitung
North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com
36" GRIDDLE
COOKING STATION
Parts & Assembly
MODEL
Before proceeding, make certain
that you read and understand the
Owner’s Manual included with
your griddle.
Hazardous fire or explosion may
result if instructions are ignored.
It is the consumer’s responsibility
to see that the griddle is prop-
erly assembled, installed, and
maintained. Failure to follow the
instructions in this manual could
result in bodily injury and/or
property damage.
SAFETY ALERT KEY
Read and follow all of the notices
found throughout the manual.
INSTALLER/ASSEMBLER:
Leave these instructions with consumer.
CONSUMER:
Keep this manual for future reference.
TO REGISTER your Blackstone product please go to
www.blackstoneproducts.com/register-griddle
Model Number _____________________________
Serial Number______________________________
Date Purchased ____________________________
!DANGER
Indicates an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
!WARNING
Indicates the possibility of serious
bodily injury if the instructions
are not followed.
!CAUTION
Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
36" Griddle Cooking Station | Parts & Assembly
PARTS & ASSEMBLY
ILLUSTRATED PARTS LIST
01. Griddle body (1 piece) 02. Griddle top (1 piece) 03. Le side shelf (1 piece)
04. Right side shelf (1 piece) 05. Hard cover (1 piece) 06. Bottom tray (1 piece)
07. Handle (1 piece) 08. Le shelf brackets (2 pieces) 09. Right shelf brackets (2 pieces)
10. Propane tank hanger (1 piece) 11. Propane tank holder (1 piece) 12. Hard cover handle (2 pieces)
Hard cover hook (2 pieces)
13. Rear grease cup (1 piece) 14. Paper towel holder (1 piece) 15. Fixed wheels (2 pieces)
Swivel wheels (2 pieces)
a b a b
36" Griddle Cooking Station | Parts & Assembly
01
16. Hardware pack (1pc):
a. Cross head screw M6X12mm (9pcs)
b. Control knobs (4pcs)
c. Washers (2pcs)
d. Bolt M6X70mm (1pc)
e. Flange nut (1pc)
f. M8X14mm screw (4pcs)
g. Metal pegs (8pcs)
h. Large thumbscrew M6X60mm (1pc)
i. Medium thumbscrew M6X40mm (1pc)
j. Metal pegs washer (8pcs)
NOT INCLUDED - 20lb LP Gas Tank
& AA Battery
a.
b.
c.
d. f.
g.
h.
i.
j.
36" Griddle Cooking Station | Parts & Assembly
02
ASSEMBLY INSTRUCTIONS
Please read all instructions thoroughly before proceeding. Make sure all
the plastic packing material is removed before assembling
Find a large, clean area to assemble your griddle. Please refer to the parts list
and assembly diagrams as necessary.
Griddle assembly involves large components; therefore, it is advised to have
two people assemble the unit.
TOOLS NEEDED: Phillips Head
Screwdriver & Adjustable Wrench
STEP 01
Remove the griddle body from the packaging and lay it upside down on a
smooth, at surface with the help of another person.
Rotate the legs into a vertical position. Install the two (2) xed wheels (le
wheels) with the two (2) preinstalled small thumbscrews and two (2) swivel
wheels (right wheels) with wrench. Be sure that swivel wheels are in locked
position when attaching.
36" Griddle Cooking Station | Parts & Assembly
03
!CAUTION
Two people are recommended for
the assembly of this product.
!WARNING
The manufacturer has made every
eort to eliminate any sharp
edges. However, you should
handle all components with care
to avoid accidental injury.
Some parts may contain sharp
edges, especially as noted
in these instructions. Wear
protective gloves if necessary.
!WARNING
The use of alcohol, prescription
or non-prescription drugs may
impair the consumer’s ability
to properly assemble or safely
operate the appliance.
STEP 02
Place the bottom shelf and secure it with one (1) M6x60 large thumbscrew
to between the two legs on the le. Use one (1) M6x40 medium thumbscrew
to attach the shelf and the propane tank holder in between the two lockable
caster wheels on the right.
STEP 03
With the help of another person, place the griddle on it’s feet. Then, install
propane tank hanger with one (1) M6X70 bolt and one (1) M6 nut. Next,
install the 4 control knobs by pushing them into place.
36" Griddle Cooking Station | Parts & Assembly
04
STEP 04
Install the paper towel holder by sliding it into the slot beneath side shelf.
Secure it using one (1) M6x12 screw and two (2) washers.
STEP 05
Attach two (2) side shelf brackets to the right side of the griddle unit with
four (4) M6x12 bolts. Then repeat this step on the le side of the griddle unit
with four (4) M6x12 screws.
STEP 06
Install the handle to the griddle body with four (4) M6x12 screws. Next place
the grease cup on the back of the griddle body in the center of the unit.
36" Griddle Cooking Station | Parts & Assembly
05
STEP 07
Attach the four (4) side shelf pegs and four (4) peg washers to the right side
shelf by screwing them into the precut holes. Repeat this step with the le
side shelf using four (4) side shelf pegs and four (4) peg washers.
STEP 08
Attach the hard cover handle and hook with four (4) M4x10 screws. (The
screws are inside the handles.)
36" Griddle Cooking Station | Parts & Assembly
06
STEP 09
Install the right side shelf on to the griddle body with two (2) M8 screws.
STEP 10
Repeat this step with two (2) M8 screws on the le side of the unit.
36" Griddle Cooking Station | Parts & Assembly
07
STEP 11
With the help of another person, place the griddle top onto the griddle body.
Be sure that the pins are securely inserted in the corresponding holes. Then,
place hard cover on the griddle top.
STEP 12
Proceed to the seasoning instructions section in the Owner’s Manual.
Enjoy cooking outdoors on your Blackstone 36" Griddle!
NEED HELP? Call Blackstone Information
Center for missing parts, assembly or and
operation questions: 435-252-3030
or email us at:
support@blackstoneproducts.com
Insert one AA battery (not included)
into the battery socket with the
positive terminal facing out, and
then screw on the Ignition Button
until tight; be careful not to
over tighten.
36" Griddle Cooking Station | Parts & Assembly
08
