FILMMAKING I

BLACK MAGIC POCKET 4K

QUICK GUIDE & NOTES

BMPCC 4k camera body with:

- Shape CBM4K cage

- Metabones N/F – MFT Ultra 0.71x speed booster

- removable Canon LP-E6 style internal battery

- Manfrotto tripod plate

Shape Candy

DSLR handle

82 mm

diameter

variable ND

filter

58 mm diameter

variable ND filter

Zeiss

28 mm

f 2.0 lens

Zeiss

50 mm

f 1.4 lens

Tokina

11 - 20 mm

f 2.8 lens

media case containing two

128 GB SD memory cards

multi-format USB 3.0

memory card reader

Pro-X Powerbase 70

external battery

Pro-X Powerbase 70

external battery

- charger for external batteries

- external battery to camera cable

- power supply for camera

- memory card reader to computer cable

soft case with clip

for external battery

(lies loose on top of cabling)

PLEASE

DO NOT

REMOVE THE

METABONES

SPEED

BOOSTER

FROM

THE

CAMERA!

PLEASE

DO NOT

REMOVE THE

CAMERA

BODY

FROM

THE

CAGE!

BMPCC 4K CAMERA KIT

CASE LAYOUT

version 1.0 on 15 JAN 2019

CONCORDIA CINEMA DEPOT

514.848.2424 extension 4652

room FB307.06

Please exercise caution with connector present on:

- power supply for camera

- external battery to camera cable

PLEASE PULL ON COLLAR TO RELEASE/REMOVE

THE CONNECTOR FROM THE CAMERA

PLAN A MINIMUM OF 1 HOUR

FOR CHECK OUT & PREP

1. IN CAMERA MENU >SET-UP: PRESS “FACTORY RESET”

2. PHYSICALLY INSPECT ALL LENSES

3. MOUNT LENSES ON CAMERA AND CHECK FOCUS

4. INSPECT ALL FILTERS AND ALL ACCESSORIES

4. BUILD TRIPOD, MOUNT & BALANCE THE CAMERA

5. VERIFY ALL CARDS AND CARD READER FUNCTION

MICRO FOUR THIRDS SENSOR

MICRO FOUR THIRDS MOUNT

TOKINA 11mm-20mm / 2.8

ZEISS 28mm / 2.0

ZEISS 50mm / 1.4

BMP4K LENSES

CAMERA IS EQUIPPED WITH

A SPECIALIZED ADAPTER

“METABONES SPEEDBOOSTER”

IMPORTANT NOTE ABOUT

METABONES ADAPTER

1. STAYS ON THE CAMERA

2. MUST BE TREATED WITH CARE AS

IT CONTAINS AN OPTICAL ELEMENT

3. SPECIAL MOUNTING INSTRUCTIONS

for 28mm and 50mm

STEP 1: BEFORE ATTACHING LENS

STOP LENS DOWN TO MAXIMUM (E.G., F22)

STEP 2: ALIGN WHITE LENS NOTCH

WITH RED DOT ON ADAPTER

STEP 3: ATTACH AND TURN CCW TO LOCK
