Blanco BODE 62X Bedienungsanleitung

INSTRUCTION MANUAL

Oven

BODE 62X

Dear Customer

You will find that the clean lines and modern look of your Blanco oven blends in

perfectly with your kitchen décor. It is easy to use and performs to a high stan-

dard.

Blanco also makes a range of products that will enhance your kitchen – such as

cook tops, rangehoods, dishwashers, microwaves, sinks and taps. There are

models to complement your new Blanco oven.

Of course, we make every effort to ensure that our products meet all your requi-

rements, and our Customer Relations Department is at your disposal, to answer

all your questions and to listen to all your suggestions.

Please complete the warranty section of this manual and keep your receipt as

proof of purchase. Retain all documents relating to the purchase of Blanco pro-

duct.

Blanco is committed to providing increasingly efficient products that are easy to

use, respect the environment and are attractive and reliable.

BLANCO

TABLE OF CONTENTS

SAFETY RECOMMENDATIONS P.04

HOW TO INSTALL YOUR OVEN

• Electrical connections P.08

• 1st connection or change of the power cable P.09

• Dimensions for installation use P.11

YOUR OVEN

• Description P.13

• Accessories P.14

HOW TO USE YOUR UPPER OVEN

• How to cook straightaway P.15

• Upper oven cooking modes P.16

HOW TO USE YOUR LOWER OVEN

• The programmer P.17

• How to set the clock P.18

• How to program for immediate cooking P.19

• How to set a cooking programme P.20

• How to use the timer P.22

• Lower oven cooking modes P.23

CLEANING AND MAINTENANCE

• How to change the bulbs P.25

• How to clean the inside area of the oven P.26

TROUBLESHOOTING P.26

AFTER-SALES SERVICE P.27

BLANCO CUSTOMER SERVICE P.28

IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND

RETAIN FOR FUTURE USE.

Important

When you receive the appliance, unpack it or have it

unpacked immediately. Give it an overall inspection. Make

note of any concerns or reservations on the delivery slip and

make sure to keep a copy of this form. Keep this user guide with

your appliance. If the appliance is ever sold or transferred to

another person, ensure that the new owner receives the user

guide. Please become familiar with these recommendations

before installing and using your oven. They were written for your

safety and the safety of others.

WARNING:

— The Appliance is not intended for use by persons (including

Children) with reduced physical,sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervised instruction concerning use of the appliance by a

responsible person for their safety. Cleaning and maintenance

operations must not be carried out by children without supervi-

sion.

— Children must be supervised to prevent them from playing with

the appliance.

WARNING:

— The appliance and the accessible parts of it will become hot

during use. Be careful not to touch the heated elements. Children

must not be allowed to touch the appliance, unless they are super-

vised continually.

Use

— Before using your oven for the first time, heat it while empty for

approximately 15 minutes. You should ensure you heat each ele-

ment in the oven before use. Make sure that the room is sufficiently

ventilated. You may notice a particular odour, or a small release of

smoke. All of this is normal.

— Your appliance is intended for standard household use. Do not

use it for commercial or industrial purposes or for any other purpo-

SAFETY INSTRUCTIONS

se than that for which it was designed.

— This oven was designed for use by private individuals in their

homes. It is intended solely for cooking foodstuffs. This oven does

not contain any asbestos-based components.

— Do not modify or attempt to modify any of the characteristics of

this appliance. This would be dangerous to your safety.

— Never pull your appliance by the door handle.

— When placing dishes inside or removing them from the oven, do

not place your hands close to the upper heating elements and use

heat-protective kitchen gloves.

— At the end of cooking, do not pick up oven or grill items (grid, ro-

tisserie,...) with your bare hands.

— Never place aluminium foil directly in contact with the floor of the

oven (see the chapter on oven description), as accumulated heat

may cause deterioration of the enamel.

— Do not place heavy weights on the open oven door, and make

sure that children are able neither to climb nor sit on it.

— Do not use your oven as a larder or to store any items after use.

— After using your oven, make sure that all the controls are in their

stop position.

— In addition to the accessories supplied with your oven, only use

dishes capable of withstanding high temperatures (follow the ma-

nufacturer’s instructions).

Maintenance and cleaning

— Do not use a steam cleaner.

— For any cleaning operation inside the oven cavity, the oven must

be switched off.

— Before removing the back, ensure that the appliance is powered

down. After cleaning, the back should be replaced in accordance

with the instructions.

— To clean both the electronic programmer window and the oven

door, use a window washing product applied to a soft cloth.

— Do not use abrasive creams or scouring sponges.

SAFETY INSTRUCTIONS

EN SAFETY INSTRUCTIONS

Warning:

Make sure the appliance is disconnected from the power

before replacing the lamp in order to avoid the risk of electric

shock. Change the lamp only when the appliance has cooled

down. To unscrew the view port and the light, use a rubber

glove, which will make disassembly easier.

Warning:

Installation should only be performed by qualified installers

and technicians.

Warning:

The electrical plug must remain accessible after installation.

It must be possible to disconnect the appliance from the

power supply, either using a plug or by fitting a switch on the

fixed wiring system in accordance with installation rules.

If the power cable is damaged, it must be replaced by a cable

or a special kit available from the manufacturer or its After-

Sales Service Department.

SAFETY INSTRUCTIONS

PACKAGING

— This appliance’s packing materials are recy-

clable. Recycle them by depositing them in

local authority containers provided for this

purpose.

— Your appliance also contains many recyclable

materials. It is therefore marked with this logo to indi-

cate that used appliances must not be mixed with

other waste.

•

HOW TO INSTALL YOUR OVEN

The electrical connections are made be-

fore the oven is installed in its housing.

• Before connecting your oven, make

sure you are using the correct size cable.

The cross-section should be the same as

the cable connected to the oven. The

fuse for your installation must conform to

the table shown opposite.

• When the oven is connected using a

separate plug and socket this must be

accessible after the oven has been instal-

led.

• When the appliance is not connected

to the mains electricity supply by a plug,

an omnipolar cutout

device (with a contacts gap of at least 3

mm) must be fitted on the supply side of

the connection to meet

requirements.

• The oven must be connected using a

standard power cable for which the num-

ber of conductors is

dependent upon the type of connection

required and in conformity with the table

shown below.

min.

network voltage connection diameter fuse

of cable

➀230V- 50Hz 1 L + N 4 mm² 32 A

➁400V 2N-50Hz 2 L + N 1,5 mm² 16 A

230V 2-2N-50Hz 2 L + N 2,5 mm² 16 A

➀

➁

③

Ph 2

ELECTRICAL CONNECTIONS

•

Ph 1

Ph 1 Ph 2

N1 N2

HOW TO INSTALL YOUR OVEN

•

—The power cable (H05 RR-F, H05 RN-F or H05 VV-F)

must be of sufficient length to be connected to the build-

in oven while it sits on the floor in front of the cabinet.

To do this the appliance must be disconnected from the

electrical network:

—Open the inspection flap located at the lower right of

the back cover by unscrewing the two screws, then pivot

the inspection flap.

—Strip 12 mm along each wire of the new power cable.

—Carefully twist the strands together.

—Loosen the screws from the terminal board and remove

the power cord to be replaced.

—Insert the power cable through the side of the cover

into the cable clip located to the right of the terminal

board.

—All the strands of the electrical wires must be secured

tightly under the screws.

— The phase wire on the L terminal.

— The green-yellow coloured according table earth wire

should be connected to the terminal .

—The neutral wire (blue) on the N terminal.

--Connect the wires according table (on previous page).

—Screw down tightly the screws on the terminal board and

check the connection by pulling on each wire.

—Attach the cable with the cable clip located to the right

of the terminal board.

—Close the inspection flap using the two screws.

st CONNECTION OR CHANGE OF THE POWER CABLE

Warning

Wecannotbeheldresponsibleforanyaccident

resultingfrominexistent,defectiveorincorrectearthing.

Iftheelectricalinstallationinyourresidencerequiresany

changesinordertohookupyourappliance,contacta

professionalelectrician.

Iftheovenmalfunctionsinanyway,unplugtheappliance

orremovethefusecorrespondingtothesectorwherethe

ovenishookedup.

Youmustenabletheappliancetobedisconnectedfrom

thesupplynetworkafterinstallation.

Disconnectioncanbeenabledbyensuringthatthere

isanaccessiblepowerplugorbyincorporatinga

switchintothefixedwiringincompliancewith

theinstallationrules.

Theovenissoldwithoutacable.

HOW TO INSTALL YOUR OVEN
