Blaupunkt 40FB5000 Bedienungsanleitung

Union Distribution s.r.o. address: Na Srtzi

1702/65, 140 00 Prague 4, Czech Republic

USER'S MANUAL

LED TV

40FB5000

Table of contents

Help/Package contents ........................................................................................................ 1

Warning................................................................................................................................ 2

Safety instructions................................................................................................................5

Getting started .....................................................................................................................7

Controls and connections.....................................................................................................8

Connecting antennae, Internet and external devices..........................................................

Getting started ...................................................................................................................12

After use.............................................................................................................................12

Trouble-shooting................................................................................................................ 13

Specifications..................................................................................................................... 15

Service and certification information................................................................................... 15

Figures and illustrations in this Operation Manual are provided for reference

only and may differ from actual product appearance. Product design and

specifications may be changed without notice.

Help

The Help feature offers a lot of information about your TV operation. To use the Help featur

e, press the Home button, and then use the arrow and OK buttons to access to the Help

menu. You can find how to troubleshoot from the list or keyword search. If you update APK,

the Help feature and information will be updated.

Package contents

1.Led TV

2.Remote Control

3.Stand

4.User Manual 1

5.Screw

Operating conditions: air temperature from 15 to 35 ° C; humidity from 45 to 75%;

atmospheric pressure from 86 to 106 to Pa (from 650 to 800 mm of mercury).

Transportation: Packed TVs are allowed to be transported by all modes of transport

air temperature from +50 to - 40 ° C and humidity from 75 to 100%.

Getting started

Fitting the stand

Before you can install your TV set, you need to fit the stand. Alternatively, you can mount it

on the wall. A Phillips screwdriver is needed to perform the installation.

Setting up the TV set

Place your TV set on a flat, stable surface (e.g. a table or a specially designed TV stand).

Make sure that all cables are laid simply and safely and do not represent a trip hazard. The

device must be connected to a mains socket using the mains cable. This mains socket must

be easily accessible so that the mains plug can be removed immediately in the event of an

emergency.

Fitting the batteries into the remote control

1. Turn the remote control over with its underside facing upwards, insert a finger into the

recess, and push the battery compartment cover in the direction of the arrow. Remove

the battery compartment cover.

2. Insert the batteries supplied into the remote control. Make sure that you insert the

batteries correctly with the polarity as shown inside the battery compartment.

3. Replace the battery compartment cover and push in the opposite direction to the arrow

until it clicks into place.

Caution: Remove the batteries from the remote control if you are not going to

use the device for an extended period of time. Otherwise, the remote control

can be damaged by leaking battery acid.

Controls and connections

Caution: Before connecting or disconnecting any cables, switch off all related

devices (also the TV). Otherwise you could damage the devices.

Back

USB2.0

(5V 500mA)

HDMI3 HDMI2

LAN

ANT1 ANT2

SATELLITE DIGITAL

AUDIO OUT

AV USB2.0

(5V 500mA)

13/18V 400mA13/18V 400mA

COMMON

INTERFACE

HDMI1(ARC/CEC)

1. Headphone out : Earphones/headphones jack.

2. Common Interface slot.

3. USB2.0: USB port. Connector a USB Storage device for multimedia file playback.

4. AV IN: AV audio/video signal input.

5. DIGITAL AUDIO OUT: Connect to an external digital audio device.

6. ANT2:Connection for satellite antenna (ANT 2) (SATELLITE)

7. ANT1:For connection of the external antenna.

8. HDMI1/HDMI2: HDMI (High-Definition Multimedia Interface) input.

(HDMI1 supports ARC function)

9. LAN: Local area network (LAN) port. Connect a LAN cable to this port to connect to

the Network.

Remote control

Definition of the buttons on remote control:

Buttons escription

1 Power Turn on/off TV

2 Mute Mute or restore sound

3 Media

Control media playback in Media

mode

4 Number Number buttons

5 Info Display program information

6 EPG Launch Electronic Program Guide

7 Settings Display System Settings Menu

8 Source Select signal source

9 Direction/

Press the direction buttons to

select menu options or settings.

Press OK to select or confirm

menu item.

10 Menu Display main menu

11 Back Return to last viewed program

12 Voice Activate Voice command function

13 Volume Adjust the volume

14 Program Select programs in ascending or

descending order

15 Home Open Android TV Homepage

16 NETFLIX Open Netflix App

17 YouTube Open YouTube App

18 Color Use in accordance with the

Operation interface instructions

19 Audio Select audio languages and

Audio channels

20 Subtitle Select subtitle

21 TTX Show or hide Teletext
