NOTE:
Only non-combustible materials can be used in close proximity to this appliance.
In order to facilitate easy operation, drainage and servicing of appliance, a minimum
of 600mm clearance should be maintained at front of appliance.
Any gas burning appliance requires adequate clearance and ventilation for optimum and trouble-free
operation. The following minimum installation clearances are to be adhered to:
This model is delivered completely assembled. Ensure adjustable feet are securely attached.
NOTE:
This appliance is fitted with adjustable feet to enable appliance to be positioned
securely and level. This should be carried out on completion of gas connection. Refer
to ‘Gas Connection’ section below.
Optional Accessories (Refer to Replacement Parts List)
Plinth Kit. For installation details, refer to instructions supplied with each kit.
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON.
1. Blue Seal Pasta Cookers do not require an electrical connection, they function totally on gas supply
only.
2. It is essential that gas supply is correct for appliance to be installed and that adequate supply
pressure and volume are available. The following checks should be made before installation:-
a. Gas Type appliance has been supplied for is shown on
coloured stickers located above gas entry point and on rating
plate. Check that this is correct for gas supply appliance is
being installed for. Gas conversion procedure is detailed in this
manual.
b. Supply Pressure required for this appliance is show n in
‘Specifications’ section of this manual. Check gas supply to
ensure that adequate supply pressure exists.
c. Input Rate of this appliance is also shown on Rating Plate
fitted to inside of access door and in ‘Specifications’ section of
this manual. Input rate should be checked against available
gas supply line capacity. Particular note should be taken if
appliance is being added to an existing installation.
NOTE: It is important that adequately sized piping runs directly to
connection joint on appliance, with as few tees and elbows
as possible to give maximum supply volume.
3. Fit gas regulator supplied, into gas supply line as close to appliance as possible.
NOTE: Gas pressure regulator provided with this appliance is convertible between Natural Gas and
LPG as per ‘Gas Conversion Section’ in this manual.
Ensure regulator is converted to correct gas type that appliance will operate on.
Regulator outlet pressure is fixed ex-factory for gas type that regulator is converted to and
it is NOT to be adjusted.
Regulator connections are 3/4" BSP female.
Connection to appliance is 3/4" BSP male.
(Refer to 'Specifications' section for gas supply location dimensions).
Rating Plate
Location
Fig 1
Left / Right Hand Side 50mm 0mm
Rear 50mm 0mm
