BT4600 and BT5600 CDMA 1xEvDO Modems

Product Manual

November 2005

UG-BT4600 & BT5600 CDMA

BlueTree Wireless Data, Inc.

2425 46th Avenue

Lachine, QC, Canada H8T 3C9

Tel: +1 (514) 422-9110

Toll Free: 1-877-422-9110

www.bluetreewireless.com

Printed in Canada

BlueTree™, the BlueTree logo, and BlueVue™ are trademarks of

BlueTree Wireless Data, Inc.

All other trademarks are the property of their respective owners.

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 4

Patents

Portions of this product are covered by some or all of the following

patents:

Declaration of Conformity

FCC Compliance and Industry Canada Statement

FCC ID: (TBD)

Industry Canada: (TBD)

The device complies with Part 15 of FCC rules and with ICES-003 of

Industry Canada Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

Caution: Unauthorized modifications or changes not expressly approved by

BlueTree Wireless Data, Inc. could void compliance with regulatory rules,

and thereby your authority to use this equipment.

This equipment generates uses and can radiate radio frequency energy

and, if not installed and used in accordance with the manufacturer's

instructions, may cause interference harmful to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 5

Warning: “Antenna must not exceed 3 dBi for Cellular band

and 4 dBi for PCS band. This device must be used in mobile

configurations. The antenna(s) used for this transmitter must

be installed to provide a separation distance of at least 30 cm

or 12 inches from all persons and must not be co-located or

operating in conjunction with any other antenna or transmitter.

Users and Installers must be provided with antenna installation

instruction and transmitter operating conditions for satisfying

RF exposure compliance”

Liability Notice

While every effort has been made to achieve technical accuracy,

information in this document is subject to change without notice and

does not represent a commitment on the part of BlueTree Wireless

Data, Inc., or any of its subsidies, affiliates, agents, licensors, or

resellers. There are no warranties, express or implied, with respect to

the content of this document.

Safety

Do not operate the BlueTree Wireless Data BT4600 or BT5600 modem

in areas near medical equipment, where blasting is in progress, where

explosive atmospheres may be present, or near any equipment that

may be susceptible to any form of radio interference.

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 6

Contents

Chapter 1: Introduction ......................................................... 7

Welcome................................................................................... 7

Customer Support...................................................................... 7

Chapter 2: Product Description..............................................8

Overview .................................................................................. 8

Available Models ........................................................................ 8

Modem Features ........................................................................ 9

Operational Description..............................................................10

Physical Description...................................................................12

Technical Specifications..............................................................17

Chapter 3: Installation Requirements .................................. 18

Cellular antenna........................................................................18

GPS antenna ............................................................................18

Serial cable ..............................................................................19

Ethernet cable ..........................................................................19

USB cable ................................................................................19

Power source............................................................................19

Mounting Hardware ...................................................................19

Wireless network account...........................................................19

Chapter 4: Installing the Modem.......................................... 20

1) Unpacking the Modem............................................................20

2) Mounting the Modem .............................................................20

3) Installing the Cellular Antenna ................................................20

4) Installing the GPS Antenna .....................................................21

5) Installing the Power Cable ......................................................22

6) Connecting the Data Cables....................................................24

7) Configuring the modem..........................................................25

8) Connecting to a wireless network using the serial port (DB9).......25

9) Connecting to a wireless network using the Ethernet port (RJ45)..26

Appendix A: Warranty and Customer Support...................... 28

Warranty .................................................................................28

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 7

Chapter 1: Introduction

Welcome

Thank you for choosing the BT4600/5600, BlueTree’s CDMA wireless

data modem.

Customer Support

Help desk Toll-free 1-877-422-9110

Phone (514) 422-9110

Hours 09:00 - 17:00 Eastern Time

Email [email protected]

Sales desk Phone (514) 422-9110

Hours 09:00 - 17:00 Eastern Time

Email [email protected]

Mail BlueTree Wireless Data, Inc.

2425 46th Avenue

Lachine, QC, Canada H8T 3C9

Fax (514) 422-3338

Web www.bluetreewireless.com

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 8

Chapter 2: Product Description

Overview

The BT4600/5600 modem gives today's mobile organization the

reliable, instant access to information that is critical for its teams.

The unit is a fully integrated CDMA modem, which adds wireless

1xEvDO functionality to remote and mobile applications. These are

designed for harsh environment installations and are tested to meet

strict military and automotive standards.

These modems are intended for use with a host platform such as a

computer or remote data terminal unit. These modems also contain an

embedded processor and the intelligence to transfer data from one

source to another over the wireless network without the need for any

additional computing device.

BlueVue Device Manager software

The modem package also includes BlueVue Device Manager software.

The Device Manager application makes configuring and monitoring

your modem simple and quick. With this software modem

administrators can:

•Provision modem on wireless network (Activation)

•Configure operating parameters

•Monitor status information

Note: Refer to BlueVue Device Manager manual for more details.

Available Models

BlueTree offers two models of CDMA wireless rugged modem:

•BT4600 wireless modem - base model with TCP/IP capability.

•BT5600 wireless modem - GPS model with TCP/IP and positioning

capabilities.

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 9

Modem Features

The BT4600/5600 modems offers the following features:

CDMA Dual-band Supports both North American frequency bands:

800 and 1900 MHz

CDMA 1xEvDO Compatible with CDMA IS-2000 (1xEvDO )

Wireless data services. Backward compatible with

IS95 protocols.

Short Message Services (SMS) Supports both mobile originate and mobile

terminate text messaging

3 different data connection

interfaces Serial/RS-232, Ethernet, and USB.

Note: USB is not available on product release 1.0

TPC/IP Stack Fully integrated TCP/IP protocols allowing the

modem to connect autonomously to the packet

network (internet). This feature enables capabilities

such as: In-call diagnostic, Serial-IP, stand-alone

GPS, remote configuration, and remote firmware

upgrade.

In-call diagnostic Allows the user to get modem status information

while in a data call, without interrupting the data

session.

Serial-IP Encapsulates data coming from the serial port into

a TCP or UDP packet and sends it to a remote

server on the packet network. Decapsulates IP

packets coming from the network and sends raw

data to the serial port.

Remote configuration Using the BlueVue Device Manager, this feature

allows the administrator to remotely configure or

perform remote diagnostics on the modem.

Note: For more information, refer to the BlueVue

Device Manager manual.

Remote firmware upgrade Using the BlueVue Device Manager, this feature

allows the administrator to remotely upgrade the

modem’s firmware.

Note: For more information, refer to the BlueVue

Device Manager manual.

Remote access security For remote configuration, the modem offers access

protection through username and password

authentication.

Integrated GPS Receiver Available on the BT5600 only, a Trimble GPS

receiver is embedded into the modem for

Automatic Vehicle Location (AVL). The modem can

report this positioning data locally to any of the

data interfaces (serial, Ethernet, USB), or also

remotely to a predefined server (see stand-alone).

Draft 1 BlueTree Wireless BT-4600/BT-5600 Product Manual 10

Stand-alone GPS Available on the BT5600 only, this feature allows

remote asset tracking by sending GPS data to a

remote server without the need for a client

application on the data terminal.

Store and Forward Available on the BT5600 only, this feature allows

GPS data storage. If a unit loses communication,

the data being collected through GPS will be

stored in memory and forwarded when

communication is reestablished.

Inputs and Outputs Not available on the product release 1.0.

Operational Description

Wireless connection modes

The BT4600/5600 can connect to the wireless data network in three

different ways:

•Packet Data (1xEvDO/1xRTT): allows outgoing calls using

either IS-2000 1xEvDO or 1xRTT cellular protocols, in the same

order of priority. It is intended for TCP/IP connections to the

internet. 1xEvDO allows speed up to 2.4Mbps.

•Packet Data (1xRTT): allows outgoing calls only using either IS-

2000 1xEvDO cellular protocols. It is intended for TCP/IP

connections to the internet. 1xEvDO allows speed up to 2.4M.

•Packet Data (QNC): allows outgoing calls only using IS-95 QNC

cellular protocols. It is intended for TCP/IP connections to the

internet. QNC allows speeds of up to 14.4Kbps.

•Circuit Switched Data: allows for both outgoing and incoming

calls using the circuit-switched IS-95 cellular protocol. It is

intended for direct connections with a landline analog modem.

Allows speeds of up to 14.4Kbps.

Modem operating modes

The BT-5000/4000 series modems are capable of operating in two

different networking modes, Router and Simple Modem modes.

The mode that is in effect when a connection is established depends on

the modem startup configuration and/or on the dialing strings used

when a host or a terminal attached to the modem’s serial port initiates

a connection.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere BlueTree Modem Handbücher

BlueTree

BlueTree BT4400 Bedienungsanleitung

BlueTree

BlueTree 4600A Bedienungsanleitung

BlueTree

BlueTree BT-2010 Bedienungsanleitung

BlueTree

BlueTree BT-6800 Bedienungsanleitung

BlueTree

BlueTree BT-GPRS-S Bedienungsanleitung

BlueTree

BlueTree BT-5600v2 Bedienungsanleitung

BlueTree

BlueTree 4000 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
