Bosch KSV series Bedienungsanleitung

en Instruction for Use

Refrigerator

KSV..

en Table of Contents

Safety and warning information ........... 3

Information concerning disposal ......... 5

Scope of delivery ................................... 6

Installation location ................................ 6

Ambient temperature and

ventilation ................................................. 7

Connecting the appliance .................... 7

Getting to know your appliance .......... 8

Switching the appliance on .................. 9

Setting the temperature ........................ 9

Usable capacity ...................................... 9

Refrigerator compartment .................. 10

Super cooling ....................................... 11

Interior fittings ....................................... 12

Sticker “OK” .......................................... 12

Switching off and disconnecting

the appliance ........................................ 12

Cleaning the appliance ....................... 13

Light (LED) ............................................ 13

Tips for saving energy ........................ 14

Operating noises ................................. 14

Eliminating minor faults yourself ....... 15

Appliance self-test ............................... 16

Customer service ................................. 16

enTable of Contents

enInstruction for Use

Safety and warning

information

Before you switch ON the

appliance

Please read the operating and

installation instructions carefully!

They contain important

information on how to install,

use and maintain the appliance.

The manufacturer is not liable if

you fail to comply with the

instructions and warnings.

Retain all documents for

subsequent use or for the next

owner.

Technical safety

The appliance contains a small

quantity of environmentally

friendly but flammable

refrigerant R600a. Ensure that

the tubing of the refrigerant

circuit is not damaged during

transportation and installation.

Leaking refrigerant may cause

eye injuries or ignite.

If damage has occurred

■Keep naked flames and/or

ignition sources away from the

appliance,

■thoroughly ventilate the room

for several minutes,

■switch off the appliance and

pull out the mains plug,

■inform customer service.

The more refrigerant an

appliance contains, the larger

the room must be in which the

appliance is situated. Leaking

refrigerant can form a

flammable gas-air mixture in

rooms which are too small.

The room must be at least 1 m³

per 8 g of refrigerant. The

amount of refrigerant in your

appliance is indicated on the

rating plate inside the appliance.

If the power cord of this

appliance is damaged, it must

be replaced by the

manufacturer, customer service

or a similarly qualified person.

Improper installations

and repairs may put the user

at considerable risk.

Repairs may be performed by

the manufacturer, customer

service or a similarly qualified

person only.

Only original parts supplied by

the manufacturer may be used.

The manufacturer guarantees

that only these parts satisfy the

safety requirements.

A extension cable may be

purchased from customer

service only.

Important information when

using the appliance

■Never use electrical

appliances inside the

appliance (e.g. heater, electric

ice maker, etc.). Explosion

hazard!

■Never defrost or clean the

appliance with a steam

cleaner! The steam may

penetrate electrical parts and

cause a short-circuit. Risk

of electric shock!

■Do not use pointed or sharp-

edged implements to remove

frost or layers of ice. You

could damage the refrigerant

tubes. Leaking refrigerant may

cause eye injuries or ignite.

■Do not store products which

contain flammable propellants

(e.g. spray cans) or explosive

substances in the appliance.

Explosion hazard!

■Do not stand on or lean

heavily against base

of appliance, drawers

or doors, etc

■For defrosting and cleaning,

pull the mains plug out or

switch off the fuse. Do not pull

out the mains plug by tugging

on the power cord.

■Store high-percentage alcohol

tightly closed and standing up.

■Keep plastic parts and the

door seal free of oil and

grease. Otherwise, parts and

door seal will become

porous.

■Never cover or block the

ventilation openings of the

appliance!

■Avoiding placing children

and vulnerable people at

risk:

At risk are children, people

who have limited physical,

mental or sensory abilities, as

well as people who have

inadequate knowledge

concerning safe operation of

the appliance.

Ensure that children and

vulnerable people have

understood the hazards.

A person responsible for

safety must supervise or

instruct children and

vulnerable people who are

using the appliance.

Only children from 8 years

and above may use the

appliance.

Supervise children who are

cleaning and maintaining the

appliance.

Never allow children to play

with the appliance.

Children in the household

■Keep children away from

packaging and its parts.

Danger of suffocation from

folding cartons and plastic

film!

■Do not allow children to play

with the appliance!

■If the appliance features a

lock:

keep the key out of the reach

of children!

General regulations

The appliance is suitable for

refrigerating food.

This appliance is intended for

use in the home and the home

environment.

The appliance is suppressed

according to EU Directive

2004/108/EC.

The refrigeration circuit has

been checked for leaks.

This product complies with

the relevant safety regulations

for electrical appliances

(EN 60335-2-24).

This appliance is intended for

use up to a maximum height of

2000 metres above sea level.

Information concerning

disposal

*Disposal of packaging

The packaging protects your appliance

from damage during transit. All utilised

materials are environmentally safe and

recyclable. Please help us by disposing

of the packaging in an environmentally

friendly manner.

Please ask your dealer or inquire at your

local authority about current means of

disposal.

*Disposal of your old

appliance

Old appliances are not worthless

rubbish! Valuable raw materials can be

reclaimed by recycling old appliances.

This appliance is labelled in

accordance with European

Directive 2012/19/EU concerning

used electrical and electronic

appliances (waste electrical and

electronic equipment - WEEE).

The guideline determines the

framework for the return and

recycling of used appliances as

applicable throughout the EU.



m Warning

Redundant appliances

1. Pull out the mains plug.

2. Cut off the power cord and discard

with the mains plug.

3. Do not take out the trays

and receptacles: children are

therefore prevented from climbing in!

4. Do not allow children to play with

the appliance once it has spent its

useful life. Danger of suffocation!

Refrigerators contain refrigerant

and gases in the insulation. Refrigerant

and gases must be disposed

of professionally. Ensure that tubing

of the refrigerant circuit is not damaged

prior to proper disposal.

Scope of delivery

After unpacking all parts, check for any

damage in transit.

If you have any complaints, please

contact the dealer from whom you

purchased the appliance or our

customer service.

The delivery consists of the following

parts:

■Free-standing appliance

■Interior fittings (depending on model)

■Bag containing installation materials

■Operating instructions

■Installation manual

■Customer service booklet

■Warranty enclosure

■Information on the energy

consumption and noises

Installation location

A dry, well ventilated room is suitable as

an installation location. The installation

location should not be exposed to direct

sunlight and not placed near a heat

source, e.g. a cooker, radiator, etc. If

installation next to a heat source is

unavoidable, use a suitable insulating

plate or observe the following minimum

distances from the heat source:

■3 cm to electric or gas cookers.

■30 cm to an oil or coal-fired cooker.

The floor of the installation location must

not give way; if required, reinforce floor. If

the floor is uneven, compensate with

supports.

Distance from wall

Fig. #

A gap is not required between the

appliance and side wall. The containers

and shelves are still fully extendable.

Reversing the door

(if required)

If required, we recommend that you have

the door hinges changed over by our

customer service. You can find out the

costs for changing over the door hinges

from your appropriate customer service.

m Warning

While changing over the door hinges,

ensure that the appliance is not

connected to the power supply. Pull out

the mains plug beforehand. To prevent

damaging the back of the appliance,

place adequate padding underneath.

Carefully place the appliance on its

back.

Note

If the appliance is placed on its back,

ensure that the wall spacer is not fitted.

Ambient temperature

and ventilation

Ambient temperature

The appliance is designed for a specific

climate class. Depending on the climate

class, the appliance can be operated at

the following temperatures.

The climate class can be found on

the rating plate. Fig. -

Note

The appliance is fully functional within

the room temperature limits

of the indicated climatic class. If

an appliance of climatic class SN

is operated at colder room temperatures,

the appliance will not be damaged up to

a temperature of +5 °C.

Ventilation

Fig. $

The air on the rear

panel of the appliance heats up.

Conduction of the heated air must

not be obstructed. Otherwise,

the refrigerating unit must work harder.

This increases power consumption.

Therefore: Never cover or block

the ventilation openings!

Connecting

the appliance

After installing the appliance, wait at least

1 hour until the appliance is switched on.

During transportation the oil in

the compressor may have flowed into

the refrigeration system.

Before switching on the appliance for

the first time, clean the interior of

the appliance (see chapter “Cleaning

the appliance”).

Climate class Permitted ambient

temperature

SN +10 °C to 32 °C

N+16 °C to 32 °C

ST +16 °C to 38 °C

T+16 °C to 43 °C

Electrical connection

The socket must be near the appliance

and also freely accessible following

installation of the appliance.

The appliance complies with the

protection class I. Connect the appliance

to 220–240 V/50 Hz alternating current

via a correctly installed socket with

protective conductor. The socket must

be fused with a 10 to 16 A fuse.

For appliances operated in non-

European countries, check whether the

stated voltage and current type match

the values of your mains supply. This

information can be found on the rating

plate. Fig. -

m Warning

Never connect the appliance

to electronic energy saver plugs.

Our appliances can be used with mains

and sine-controlled inverters. Mains-

controlled inverters are used

for photovoltaic systems which

are connected directly to the national

grid. Sine-controlled inverters must be

used for isolated applications (e.g. on

ships or in mountain lodges) which are

not connected directly to the national

grid.

Getting to know your

appliance

Please fold out the illustrated last page.

These operating instructions refer

to several models.

The features of the models may vary.

The diagrams may differ.

Fig. !

* Not all models.

1-4 Controls

5 Light (LED)

6 Glass shelf

7 Condensation outlet

8 Vegetable container with humidity

control

9 Height-adjustable feet

10* Butter and cheese compartment

11* Egg rack

12 Door shelf

13 Shelf for large bottles

Controls

Fig. "

Switching the

appliance on

Fig. "

Switch on the appliance with the On/Off

button 1.

The temperature display 2 indicates the

set temperature.

The appliance begins to cool. Light is

switched on when the door is open.

We recommend a factory setting of

+4 °C in the refrigerator compartment.

Do not store perishable food warmer

than +4 °C.

Operating tips

■While the refrigeration unit is running,

water droplets or a thin layer of ice

may form at the rear panel of

the refrigerator. This is nothing

unusual. It is not necessary to scrape

off the frost or wipe off the water

droplets. The rear panel defrosts

automatically. The condensation

collects in the condensation channel

and is carried to the refrigeration unit

where it evaporates.

■If the air humidity is high,

condensation may form

in the refrigerator compartment,

especially on the glass shelves. If this

is the case, pack or wrap the food

and select a lower temperature

in the refrigerator compartment.

Setting

the temperature

Fig. "

The temperature can be set from +2 °C

to +8 °C.

Keep pressing temperature setting

button 4 until the required refrigerator

compartment temperature is set.

The value last selected is saved. The set

temperature is indicated on the

temperature display 2.

Usable capacity

Information on the usable capacity can

be found inside your appliance on

the rating plate. Fig. -

1On/Off button

Serves to switch the appliance on

and off.

2Temperature display

The numbers correspond

to the set refrigerator

compartment temperatures in °C.

3“super” display

Illuminates, if the super cooling is

in operation.

4Temperature selection button

Press this button to set the

temperature.

Refrigerator

compartment

The refrigerator compartment is the ideal

storage location for meat, sausage, fish,

dairy products, eggs, ready meals

and pastries.

Storing food

■Store fresh, undamaged food. The

quality and freshness will then

be retained for longer.

■In the case of ready-made products

and bottled goods, observe the best-

before date or use-by date specified

by the manufacturer.

■To retain aroma, colour

and freshness, pack or cover food

well before placing in the appliance.

This will prevent the transfer

of flavours and the discolouration

of plastic parts in the refrigerator

compartment.

■Allow warm food and drinks to cool

down before placing in the appliance.

Note

Avoid contact between food and rear

panel. Otherwise the air circulation will

be impaired.

Food or packaging could freeze to

the rear panel.

Note the chill zones

in the refrigerator

compartment

The air circulation in the refrigerator

compartment creates different chill

zones:

■Coldest zone is between the arrow

stamped on the side and the glass

shelf situated below. Fig. %

Note

Store perishable food (e.g. fish,

sausage, meat) in the coldest zone.

■Warmest zone is at the very top

of the door and in the vegetable

container.

Note

Store at the very top of the door e.g.

hard cheese and butter. Cheese can

then continue to release its flavour

and the butter will still be easy to

spread.

Andere Handbücher für KSV series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Bosch Kühlschrank Handbücher

Bosch

Bosch KAD93VBFPG Einrichtungshandbuch

Bosch

Bosch KGF49PI40 Bedienungsanleitung

Bosch

Bosch KIF41 Series Bedienungsanleitung

Bosch

Bosch CTC29S04DI Bedienungsanleitung

Bosch

Bosch GSN33CW32 Bedienungsanleitung

Bosch

Bosch KIF86 Series Bedienungsanleitung

Bosch

Bosch KIR Series Bedienungsanleitung

Bosch

Bosch KS36FPW30/01 Bedienungsanleitung

Bosch

Bosch KIR41VFE0G Technisches Datenblatt

Bosch

Bosch KGN36 Series Technisches Datenblatt

Bosch

Bosch B20CS5 Series Installationsanleitung

Bosch

Bosch KSR Bedienungsanleitung

Bosch

Bosch KIL18NSF0 Bedienungsanleitung

Bosch

Bosch KGV Series Bedienungsanleitung

Bosch

Bosch KIF41 Series Bedienungsanleitung

Bosch

Bosch B26FT70SNS Betriebsanleitung

Bosch

Bosch KIR18V20GB Bedienungsanleitung

Bosch

Bosch KGN Series Bedienungsanleitung

Bosch

Bosch KU15LADF0 Bedienungsanleitung

Bosch

Bosch KGN36 Series Technisches Datenblatt

Bosch

Bosch B24 80 Series Bedienungsanleitung

Bosch

Bosch KSR38N11GB Bedienungsanleitung

Bosch

Bosch KSV36AWEPG Technisches Datenblatt

Bosch

Bosch KDN76 Series Technisches Datenblatt

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
