Boss Audio Systems Armor AR12D Bedienungsanleitung

AR12D

AR12D

02

12

12

Box is given as internal air volume including driver displacement

Ported Enclosure

Frequency

AR12D Amplitude Response(dB/Hz)

Box is given as internal air volume including driver displacement

Recommended Enclosures

Frequency

Please note : Our recommended box volumes are given for

internal air requirements.

AR12D Amplitude Response(dB/Hz)

Sealed Enclosure

Ported Enclosure

36

38

Port Frequency : 40 to 33 Hz

Port Diameter : 4

Port Length : 18 to 16 lnches

Box Volume:

Sealed Enclosure

(Recommended)

1.0 (cu. ft.) to 2.5 (cu. ft.)

Box Volume:

1.0 (cu. ft.) to 1.6 (cu. ft.)

lnches

28

1.015

5.429

1.248

3.024

0.356

1.8

94

1200W/2400W

2

28

0.985

5.225

1.214

3.015

0.356

7.2

94

1200W/2400W

8

12” (305mm) Subwoofer

(1200 Watts RMS Sealed Enclosure)

Wiring

Please take every precaution to wire your DVC woofers

for the correct impedance

12” (305mm) Dual Voice Coil Subwoofer

2400 Watts Peak Power/1200 Watts RMS

Frequency Response: 28Hz-1.5kHz

Sensitivity: 94 dB (1 Watt/1 Meter)

Impedance: Dual 4 OHMS

Cone Material: Color Chrome Treated Poly Injection

Butyl Rubber Surround

Dual 2” (51mm) High Temperature KAPTON Voice Coil

Mounting Depth: 5-3/16” (132mm)

+-+-

+-+-

2 ohms 8 ohms
