REFLECTION SERIES

by Boston Acoustics

Modern elegance. Legendary performance.

Modern elegance.

Legendary performance.

In an elegant fusion of technology, performance,

and stylish good looks, our new Reﬂection Series speakers

deliver clean, balanced sound worthy of our thirty year

heritage. While performance is the monarch of this line’s

feature set, its cutting-edge drivers and well-designed

crossovers are enclosed in an ultra scratch-resistant high

gloss ﬁnish that will endure years of play. That means these

speakers will make themselves at home in any environment

from living room to home theater. And after three decades of

perfecting the Boston Sound, you can be sure these speakers

will sound every bit as good as they look.

Attention to detail

Meticulously designed and solidly crafted, the most

discriminating enthusiasts will revel in the small details.

Each Reﬂection Series speaker comes cleverly appointed

with magnetic grilles and stylish contours for an uncluttered

modern appeal—but don’t be fooled, the 1,000 watt

powered subwoofer is both beauty and beast,

delivering wave after wave of heart-pounding bass

under its elegant exterior.

Advanced cabinet design

and driver conﬁguration

While each speaker baﬄe features a smooth surface and invisible

hardware, the real secret behind Reﬂection’s Super Linear Plane (SLP)

Baﬄes is their unique ability to nearly eliminate acoustic diﬀraction.

Super-shallow grilles using an invisible magnetic attachment create an

almost entirely seamless alignment with the

baﬄe plane to signiﬁcantly reduce sonic barriers.

The resulting sound is equally pristine with

the grilles on or oﬀ. Coupled with Reﬂection’s

tightly spaced driver placement, each speaker

delivers near-point-source sonic coherence,

wide dispersion, and astonishing imaging.

Multi-composite woofer cones

All Reﬂection models incorporate our new Fiber Ceramic

Copolymer Material (FCCM) Woofer cones made from a

composite of ﬁber and ceramic materials and impregnated in a

proprietary copolymer. By combining these

multi-composite cones with Boston’s

Deep Channel® Design, these woofers

produce a smooth response over the

entire operating range. That means

you get all the thunder of high-output

bass and all the subtleties and detail of

the midrange—with minimal distortion.

Smart tweeter technology

While looks do impress, one of Reﬂection Series’ unique features is

actually “under the hood.” Our new EWB (Extended Wide Bandwidth)

tweeter borrows the same performance attributes found in our

ﬂagship VS line—stabilized linear motion, lower distortion, improved

dispersion, power handling, and clarity. This was accomplished

by special central diaphragm termination (creating a dimple)

and rear chamber venting.

Shown above, the EWB tweeter’s unique design

features a diaphragm that is terminated at its center.

RS 334

Quadruple 4” Floorstanding Loudspeaker

Video-shielded for safe placement next to a TV • freq. response 43Hz-26kHz (±3dB)

• handles up to 250 watts • sensitivity 89 dB • 1” EWB tweeter • four 4” FCCM woofers

• scratch-resistant high gloss black ﬁnish • ﬁve-way gold-plated binding posts

RS 326

Dual 6-½” 3-Way Floorstanding Loudspeaker

Video-shielded for safe placement next to a TV • freq. response 38Hz-26kHz (±3dB)

handles up to 250 watts • sensitivity 89 dB • 1” EWB tweeter • 3-½” FCCM midrange

• dual 6-½” FCCM woofers • scratch-resistant high gloss black ﬁnish

• ﬁve-way gold-plated binding posts

RS 244C

Quadruple 4” Center Channel

Perfectly acoustically matched to the RS 344 • Video-shielded for safe placement

next to a TV • freq. response 50Hz-26kHz (±3dB) • handles up to 200 watts

• sensitivity 89 dB • 1” EWB tweeter • four 4” FCCM woofers • scratch-resistant

high gloss black ﬁnish • ﬁve-way gold-plated binding posts

RS 223

Dual 3½” LCR Loudspeaker

Video-shielded for safe placement next to a TV • freq. response 78Hz-26kHz (±3dB)

• handles up to 150 watts • sensitivity 88 dB • 1” EWB tweeter • dual 3½” FCCM woofers

• scratch-resistant high gloss black ﬁnish • ﬁve-way gold-plated binding posts

RS 260 and 230

RS 260 6½” Bookshelf Loudspeaker

RS 230 3½” Compact Satellite Loudspeaker

Video-shielded for safe placement next to a TV • scratch-resistant high

gloss black ﬁnish • ﬁve-way gold-plated binding posts • 1” EWB tweeter

•

freq. response 50Hz-26kHz (78Hz-26kHz) ±3dB • handles up to 200

(150) watts

• sensitivity 89 (87) dB • 6½(3½)” FCCM woofer

RPS 1000

10” 1000-Watt Peak Powered Subwoofer

Freq. response 23-150Hz (±3dB) • variable 40-180Hz crossover

• line-level and speaker-level inputs • front-ﬁring 10” FCCM woofer,

dual 8” radiators • scratch-resistant high gloss black ﬁnish

• ﬁve-way gold-plated binding posts

Shown with included base

300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com

Specications RS 326 RS 334 RS 244C RS 223 RS 260 RS 230

Frequency Range (±3dB) 38Hz – 26kHz 43Hz – 26kHz 50Hz – 26kHz 78Hz – 26kHz 50Hz – 26kHz 78Hz – 26kHz

Recommended Amplier 10 – 250 Watts 10 – 250 Watts 10 – 200 Watts 10 – 150 Watts 10 – 200 Watts 10 – 150 Watts

Sensitivity 89 dB SPL/2.8V/m 89 dB SPL/2.8V/m 89 dB SPL/2.8V/m 88 dB SPL/2.8V/m 89 dB SPL/2.8V/m 87 dB SPL/2.8V/m

Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms

Crossover Frequency 3,700 Hz, 600 Hz 2,000 Hz 2,000 Hz 2,000 Hz 2,000 Hz 2,000 Hz

Bass Driver Dual 6½” (165mm) Quadruple 4” (102mm) Quadruple 4” (102mm) Dual 3½” (89mm) 6½” (165mm) 3½” (89mm)

Fiber Ceramic Copolymer Material Fiber Ceramic Copolymer Material Fiber Ceramic Copolymer Material Fiber Ceramic Copolymer Material Fiber Ceramic Copolymer Material Fiber Ceramic Copolymer Material

Midrange Driver 3½” (89mm) — — — — —

High-Frequency Driver 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm)

Extended Wide Bandwidth Extended Wide Bandwidth Extended Wide Bandwidth Extended Wide Bandwidth Extended Wide Bandwidth Extended Wide Bandwidth

Dimensions (H x W x D) 441⁄16 x 10½ x 125⁄16” 427

⁄16 x 8½ x 95⁄16” 57

⁄8 x 233⁄8 x 611⁄16” 233⁄8 x 515⁄16 x 515⁄16” 125⁄8 x 77

⁄8 x 911⁄16” 711⁄16 x 415⁄16 x5¼”

(1118.5 x 266 x 312mm) (1076.5 x 215 x 235mm) (148 x 720 x 169mm) (593 x 150 x 150mm) (320 x 200 x 245mm) (195 x 125 x 132.5mm)

with base with base with base

Weight: 47 lbs (21.3kg) 32.2 lbs (14.6kg) 25.4 lbs (11.5kg) 7.8 lbs (3.5kg) 14 lbs (6.4 kg) 4.6 lbs (2 kg)

Specications RPS 1000

Frequency Range 23 Hz – 150 Hz, ±3dB

Amplier Power 500 watts RMS (1,000 watts peak)

Bass Driver 10” (254mm) FCCM woofer

Passive Radiator Dual 8” (203mm) FCCM passive radiators

Dimensions (H x W x D) 135⁄8 x 13¼ x 1613⁄16”

(345 x 335 x 427mm)

Weight: 48.4 lbs (22kg)

Boston Acoustics continually strives to update and improve its products.

The speciﬁcations and construction details are subject to change without notice.
