Boston Acoustics VS 260 Bedienungsanleitung

Boston Acoustics · Beemdstraat 11 · 5653 MA Eindhoven · The Netherlands · Tel. +31 (0)40 250 7873 · www.bostona.eu

Boston Acoustics UK · Padbury Oaks · Kingsbridge House, 581 Bath Road, Longford · Middlesex · UB7 0EW, United Kingdom

Tel. + 44 (0)1753 287967 · www.bostona.eu

Specications VPS 210

Frequency Range 22 Hz – 150 Hz, ±3dB

Amplier Power Class D, 500 watt RMS (1,800 watt peak)

Bass Driver 254mm Long throw OCCM woofer

with 3”voice coil

Passive Radiator 254mm OCCM passive radiator

Dimensions (H x W x D) 381 x 353 x 540mm

Weight: 28.2kg

Boston Acoustics continually strives to update and improve its products.

The specications and construction details are subject to change without notice.

Standard end panel nishes

Cherry gloss black enclosure with gloss cherry end panels and black grille

Black gloss black enclosure with gloss black end panels and black grille

Premium end panel nishes

Bird’s Eye Maple gloss black enclosure with gloss bird’s eye maple end panels

and black grille

Ebony gloss black enclosure with gloss ebony end panels

and black grille

Limited edition nishes

Arctic White gloss white enclosure with gloss silver end panels and silver grille

Red gloss red enclosure with gloss red end panels and black grille

Introducing

Vista Loudspeakers

... where performance and beauty are one

Specications VS 240 VS 260 VS 325C VS 336

Frequency Range (±3dB) 70Hz – 30kHz 49Hz – 30kHz 65Hz – 30kHz 35Hz – 30kHz

Recommended Amplier 10 – 150 watts 10 – 250 watts 10 – 250 watts 10 – 400 watts

Sensitivity 86dB SPL/2.8V/m 88dB SPL/2.8V/m 90dB SPL/2.8V/m 87dB SPL/2.8V/m

Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms

Crossover Frequency 2,000Hz 2,000Hz 2,400Hz 250 / 2,500Hz

Bass Driver 114mm 165mm Dual 133mm Triple 165mm

Midrange Driver — — 76mm 114 mm

High-Frequency Driver 25mm 25mm 25mm 25mm

Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth

Dimensions (H x W x D) 240 x 150 x 162mm 365 x 225 x 260mm 181 x 716 x 161 mm 1170 x 250 x 325 mm

Weight: 2.9Kg 4.1Kg 11.78 Kg 30.12 Kg

Vista

Great sound has a whole new look

Introducing Boston Vista Series Loudspeakers–our best performing, best-looking products. Vista delivers a

home theater or audio-only experience. Innovative driver and cabinet designs yield exceptional sonic char-

acteristics. Each Vista Series model is voiced to blend with the others so they can be combined to deliver the

best performance in any conguration.

Dispelling all notions of the typical loudspeaker “rectangular box,”Vista Series models all feature elegant

piano lacquer nish cabinets and high-gloss furniture-grade end panels. And further reecting the seamless

merging of art and science that denes Vista, the structural elements of the cabinets are made of high-

frequency-molded MDF with “wave like” curved surfaces that reduce internal standing

waves and panel resonances. Additionally, substantial internal bracing

enhances the strength of the cabinets to provide an ideal environment

for high-performance sound.

* Available this Fall

Available

this summer.

3-Way Triple 6½”

Floorstanding Loudspeaker

VS 336

3-Way Dual 5¼”

Center Channel Loudspeaker

VS 325C

VS 260 2-Way 6½”Bookshelf Loudspeaker

VS 240 2-Way 4½”Bookshelf Loudspeake

VS 260*and 240

10” High-Powered Subwoofer

500-watt RMS 1800-watt Peak Proprietary

Class-D Amplier

VPS 210

Key features

SuperWide Bandwidth (SWB)Tweeter featuring a Coupled Dual

ConcentricDiaphragm (CDCD) minimizes phase shift and distortion while

improving pistonic motion. (exceptVPS 210)

Organic Composite Cone Material (OCCM) was developed using a mix of select

natural bers to reduce resonance and improve accuracy.

High-frequency-molded MDF cabinet features curved surfaces, which reduce

internal standing waves and panel resonances.

Bi-amp, Bi-wire capability (VS 336 and VS 325C)

MagnaGuard® video shielding

Gold-plated 5-way binding posts

Elegant lacquer piano nish cabinet

High-gloss multi-layer furniture-grade end panels
