Boundless Technology TERA Bedienungsanleitung
TERA
MANUAL
Table of Contents
Page #
3 - What is Included
4 - About the Tera
6 - Key Features
8 - What is in a Tera device?
9 - How the Tera Works
10 - How to Turn the Tera ‘ON’
11 - Using the Temperature
12 - Mouthpiece Components
13 - How to remove the
Mouthpiece
15 - How to Load Herb and
Concentrate
16 - How to Use the WPA
18 - How to Clean the Tera
20 - Battery and Charging
23 - Warranty
26 - Safety Disclaimers
30 - Contact Information
2
What Is Included
—(1) Tera Unit
— (1) Swivel Mouthpiece
—(1) Glass Mouthpiece
—(2) LG 18650 2500 mAh
Batteries
— (1) Water Pipe Adapter
—(5) Stainless Steel
Chamber Screens
—(1) Stainless Steel Mesh
Concentrate Pads
—(2) Mouthpiece Screens
—(1) Cleaning Brush
—(1) Packing Tool
—(1) USB Charger
— (1) User Manual
3
About the Tera
The Tera is the newest aromatherapy
device addition to the Boundless
line. Small enough to comfortably t
in the palm of your hand, the Tera
delivers truly powerful smooth
clouds from the rst draw. Featuring
two removable 18650 batteries, the
unit can also be charged via USB. The
Tera is perfect for on the go use and
can also be attached to a glass water
pipe using the Boundless water pipe
adapter. This portable aromatherapy
device uses convection heated air
and radiative heat transfer to
eciently vaporize your materials.
This means that
there is a complete
separation between
the heating element
and the herb
chamber.
4
Answering to the demands of our
customers we have included a
chamber which produces full and
thick clouds in less than sixty
seconds. The Tera encompasses an
stainless steel convection chamber
which is designed to heat up quickly
to the desired temperature while
evenly vaporizing terpenes and
cannabinoids. The unit comes
equipped with full temperature
control ranging from 104°F-428°F
(40°C-220°C). Also, featuring a fully
rotatable mouthpiece with an
improved airow, there is also the
option to interchange with a sleek
glass mouthpiece for an improved
taste.
5
Key Features
Dimensions
• Height: 107mm
• Width: 44.5mm
• Depth: 59mm
• Weight: 0.7 lbs
Temperature levels
104-428 F // 40-220 C
Screen: Digital OLED screen
Battery Capacity:
2x18650 (removable)
Unit can be charged via USB
Airow
Redesigned mouthpiece produce
bigger clouds with less irritation
Chamber: Stainless Steel
Convection
6
Heaiting System
Convection heating system with an
isolated heating path
Heating Element
Ceramic heating rod located below
completely separated from herb
chamber.
Haptic Feedback operation
Compact and rugged design with
textured grooves for comfortable
hand placement
Built with medical and food grade
material
Non combustion aromatherapy
device
7
Power Button
Temperature Control
Swivel
Mouthpiece
Micro USB
Charge Port/Cable
Battery Cover Plate
What’s in a Tera
aromatherapy device?
8
Water Pipe
Adapter
Glass
Mouthpiece
How it works:
Powered by two 18650 removable
batteries the ceramic heating rod
element generates heat working as
radiative heat which moves towards
the separate stainless steel convec-
tion chamber. Once the stainless
steel chamber is heated it quickly
and eciently vaporizes the materi-
al and extracts terpenes and canna-
binoids. The Tera has an isolated
airpath away from any interfering
internal wiring which ensures a pure
and clean tasting vaping experience
each time.
9
How to power
the Tera on
To power the Tera 'ON’ click the
rectangular button ve times in
rapid succession. Please note unit
will not power up if the clicks are too
slow. Once in the 'ON’ mode the
screen will illuminate and it will
automatically heat up to the last
previously used temperature. The
unit will stay on for a period of ve
minutes.*The unit will not heat up
until directed. To heat the chamber
hold down the power ‘ON’button for
three seconds; it will automatically
heat to the last previously used
temperature. Once the ve minute
timer ends, the unit will vibrate and
enter sleep mode until turned back
on. To restart the heating process
hold the button button
on for 3 seconds.
10
Power Button
