Brandt WFB194QWA Kurzanleitung
GB
GUIDE TO INSTALLATION AND USE (EN)
Washing Machine
1
GB
CONTENTS
Safety instructions....................................................................2
Installation................................................................................5
Operation...............................................................................11
Maintenance ..........................................................................24
Troubleshooting.....................................................................28
Availability of spare parts.......................................................30
GB
Safety instructions
•This appliance is designed to be used for domestic and similar
applications such as:
-kitchen areas for staff in shops, offices and other
professional premises;
-farms;
-use by hotel, motel and other residential clients;
-B&B type environments.
•The appliance must be connected to the mains water supply
using the brand new connection fittings supplied with the
appliance. Never reuse old fittings.
•Never obstruct the ventilation openings.
•This appliance can be used by children aged 8 years and over
and by individuals with physical, sensory or reduced mental
capacity, or lack of experience and knowledge under
supervision or if they have been given instructions on how to
use the appliance safely and have fully understood the risks
involved. Children must not be allowed to play with the
appliance. Cleaning and maintenance operations must not be
carried out by children without supervision.
•Children under the age of three should be kept away from the
appliance unless they are under constant supervision.
•If the power cord is damaged, it should be replaced by the
manufacturer, its after-sales service department or a similarly
qualified person, so as to avoid danger.
•Regarding the instructions for installing the appliance and
making its electrical connections, please refer to the
appropriate section in this guide.
•WARNING: Do not connect the appliance to hot water.
•The maximum weight of dry laundry is 10 kilograms.
•Maximum water supply pressure: 1 MPa
•Minimum water supply pressure: 0.05MPa
3
GB
Warning!
Product installation
•This washing machine is intended for indoor use only.
•It is not designed for built-in installation.
•Never obstruct the openings.
•This washing machine must not be installed in bathrooms, very
damp rooms or in rooms where there are explosive gasses or
caustic substances.
•If the washing machine has only one water inlet valve, connect
it to a cold water source only.
•The power plug must remain accessible after the appliance is
installed.
•Remove all packaging materials and the transit bolts before
using the appliance. Failure to do so may seriously damage
your washing machine.
Appliance damage hazard!
•Your appliance is for household (domestic) use only and is
designed solely for machine washable textiles.
•Do not climb on the top of the washing machine.
•Do not lean against the door of the washing machine.
Care when handling the washing machine:
1. The transit bolts must be refitted to the washing machine by a
qualified person.
2. Drain any water from the appliance before moving the washing
machine.
3. Handle the appliance with care. Never lift the appliance by
grabbing projecting parts. The door must not be used as a
handle when moving the appliance.
4. This appliance is heavy. Carry it with care.
•Do not close the door using excessive force. If the door is hard
to close, make sure that the drum is not overloaded and that
the laundry is properly distributed.
•Do not wash carpets.
GB
Operation of the appliance
•Before using the appliance for the first time, perform a complete
washing cycle empty.
•Use of inflammable and explosive solvents is prohibited. Never
use fuel and alcohol, etc. as detergents. Only choose
detergents that are suitable for machine washing.
•Empty the pockets of your clothes. Cutting and rigid objects like
coins, pins, nails, screws, stones, etc. may seriously damage
this appliance.
•Check that the water inside the drum has been drained before
opening the door. Do not open the door if you can still see water
inside the washing machine.
•Be careful to avoid injury when draining very hot washing water.
•Never add water by hand during washing.
•Once the washing cycle has finished, wait two minutes before
opening the door.
5
GB
Installation
Description of the product
1.
Top panel
6.
Drain hose
2.
Control panel
7.
Water supply hose
2.
Power cord
8.
Detergent compartment
4.
Drum
9.
Window
5.
Filter
Note!
•The illustration of the accessories is provided for reference
purposes only. Please refer to the actual product.
GB
Accessories
Transit bolt
hole covers
Cold water
supply hose
Hot water
supply hose
(not supplied)
Drain hose
holder
(not supplied)
User guide
Installation location
Warning!
•It is important that the product be stabilised so that it will not
move!
•Ensure that the appliance is not resting on the power cord.
To install your washing machine, choose a location that is:
1. On a hard, dry, flat surface
2. Not exposed to direct sunlight
3. Adequately ventilated
4. In a room at ambient temperature
5. Away from heat sources
The washing machine is designed to operate at
ambient temperature. If it is used in a room where
the temperature is below 0°C, the water inlet valve
and the drainage system may be damaged.
7
GB
Unpacking the washing machine
Warning!
•Packaging materials (e.g. plastic film, polystyrene) can be
hazardous to children.
•There is a suffocation hazard! Keep all packaging materials
away from children.
1. Remove the cardboard box and the
polystyrene wrapping.
2. Lift the washing machine and remove
the packaging under it. Don't forget to
remove the small foam triangle at the
same time as the lower packaging. If
you cannot do so, lay the washing
machine on its side and remove the
small foam triangle by hand.
3. Remove the adhesive tape that holds
the power cord and the drain hose in place.
4. Remove the water supply hose from the drum.
Remove the transit bolts
Warning!
•You need to remove all of the transit bolts located at the back
of the washing machine before using it.
•You'll need the transit bolts again if you move the washing
machine. Keep them in a safe place.
GB
Proceed as follows to remove the transit bolts
1. Use a spanner to loosen the four transit bolts
then pull them out.
2. Push the four transit bolt cover caps provided
for this purpose into the holes.
3. Keep the transit bolts in a safe place for future
reuse.
Adjusting the levelling feet
Warning!
•The lock nuts on the four levelling feet must be tightened
against the washing machine body.
1. Check that the feet are still firmly attachedto the washing machine.
If this is not the case, return them to their original position and
tighten the nuts.
2. Slacken the lock nut and turn the foot until it touches the floor.
3. Adjust the feet and lock them into position using a spanner. Check
that the washing machine is stable.
Up
Down
Foot lock nut
1
2
3
4
