LA-3 SERIES

Automatic And Pour-Over Coffee Brewers

1034505, 1034521

Automatic Brewer, Left Hand

1034506, 1034520

Automatic Brewer, Right Hand

1034516

Pour-Over Brewer, Left Hand

1034517

Pour-Over Brewer, Right Hand

20333 S. Normandie Ave., CA 90502

800-421-6860 •310-787-5444 •Fax 310-787-5412

USA –E-mail: [email protected]

INT’L E-mail: [email protected]

Website: brewmatic.com

FM CS110 A 6/28/07

Page 2

TABLE OF CONTENTS

Important Information Page 3

Appliance Information Page 4

Wiring Diagrams Page 5

1034505, 1034506, 1034521 & 1034521 – LA-3 Automatic Brewers Page 5

1034516 & 1034517 – LA-3 Pour-Over Brewers Page 6

Troubleshooting Guide Pages 7 - 13

Parts Diagrams And Parts Lists Pages 14 – 24

6003093 - Element Pan Assembly W/PTC Black Page 14

1034505, 1034506, 1034520, 1034521 – LA-3 Automatic Brewers

Pages 15 - 18

Tank Assembly – LA-3 Brewers Pages 19 - 20

1034516 & 1034517 – LA-3 Pour-Over Brewers Pages 21 - 24

Page 3

IMPORTANT INFORMATION

Read all instructions and safeguards included in the original packaging and in this service manual carefully and

completely before installing, operating or servicing this appliance. Additional copies of installation instructions

and service manuals are available upon request.

The proper performance of service is essential for the safe and effective operation of this appliance. Repairs

should be performed by qualified service personnel only. If you are unable to, or need help servicing this

appliance, contact the nearest Brewmatic Authorized Service Agent or you can contact Brewmatic Company at

800-421-6860.

Only Authorized Replacement Parts Should Be Used. Part substitutions could create a fire hazard and the risk

of personal injury. The use of replacement parts or accessory attachments not recommended by Brewmatic may

be hazardous.

Do Not By-Pass Any Safety Mechanisms Or Operate This Appliance Without Covers In Place. Brewmatic

requires that all safety devices and covers be in place and functioning at all times to guard against a fire hazard

and the risk of personal injury.

Brewmatic Does Not Recommend, And Will Not Furnish Anyone With Information For Changing The Electrical

Rating Of Any Appliance Manufactured Or Distributed By Brewmatic Company. Brewmatic will not approve of

any unauthorized changes to the basic design of this appliance. Any modification or alteration to the appliance

may create a fire hazard, may create a risk of personal injury, may void the safety listings and may void the

warranty.

Plumbing connections - All plumbing connections to water supply lines and drains should be performed by a

licensed plumber complying with all applicable plumbing codes having jurisdiction.

Electrical connections - With the exception of cords with plugs already attached, all electrical connections or

alterations to the power supply should be performed by a licensed electrician complying with all applicable

electrical codes having jurisdiction.

When repairing or replacing internal electrical wiring, in part or in whole, use only terminals and wires with the

same rating, gauge and insulation covering.

When calling for information, parts or service, have the model number, serial number, voltage, wattage, phase

and date of purchase available. Electrical information may be obtained from the electrical information nameplate

located on the appliance.

All procedures, diagrams and specifications contained in this manual are based on the latest information available

at the time of publication. Information, parts and specifications are subject to change without notice.

We assume no liability for any damage to person or property caused by the utilization of this publication to effect

maintenance or repairs.

Due to periodic reviews and changes in safety listing standards, listings and approvals may change at any time.

For current listing and approval information contact Brewmatic.

Page 4

APPLIANCE INFORMATION

Appliance Specifications:

Model Number: 1034505 1034521 1034506 1034520 1034516 1034517

Description: LA-3 Automatic Brewer With

Faucet. Left Hand.

LA-3 Automatic Brewer With

Faucet. Leftt Hand.

LA-3 Automatic Brewer With

Faucet. Right Hand.

LA-3 Automatic Brewer With

Faucet. Right Hand.

LA-3 Pour-Over Brewer. Left

Hand.

LA-3 Pour-Over Brewer. Right

Hand.

Volts: 120 120/240 120 120/240 120 120

Watts: 1700 2220 1700 2220 1700 1700

Amps: 14.2 11 14.2 11 14.2 14.2

Hertz: 60 60 60 60 60 60

Phase: 1 1 1 1 1 1

Power Supply Cord: 6 ft., 2 wire + ground,

15 amp, 14 awg.

6 ft., 3 wire + ground,

15 amp, 14 awg.

6 ft., 2 wire + ground,

15 amp, 14 awg.

6 ft., 3 wire + ground,

15 amp, 14 awg.

6 ft., 2 wire + ground,

15 amp, 14 awg.

6 ft., 2 wire + ground,

15 amp, 14 awg.

Plug: NEMA 5-15 P. Furnished and

attached.

Plug Not attached. NEMA 5-15 P. Furnished and

attached.

Plug Not attached. NEMA 5-15 P. Furnished and

attached.

NEMA 5-15 P. Furnished and

attached.

Power Supply Required: 120 volt, 15 amp, dedicated

circuit.

240 volt, 15 amp, dedicated

circuit.

120 volt, 15 amp, dedicated

circuit.

240 volt, 15 amp, dedicated

circuit.

120 volt, 15 amp, dedicated

circuit.

120 volt, 15 amp, dedicated

circuit.

Wall Receptacle Required: 15 amp. NEMA 5-15 R. Not

furnished.

Not furnished. 15 amp. NEMA 5-15 R. Not

furnished.

Not furnished. 15 amp. NEMA 5-15 R. Not

furnished.

15 amp. NEMA 5-15 R. Not

furnished.

Water Supply Required: 30 psi min., 80 psi max. 30 psi min., 80 psi max. 30 psi min., 80 psi max. 30 psi min., 80 psi max. None required. None required.

Water Connection: 1/4" flared fitting. Flared nut

supplied.

1/4" flared fitting. Flared nut

supplied.

1/4" flared fitting. Flared nut

supplied.

1/4" flared fitting. Flared nut

supplied.

None. None.

Listings: ETL safety & sanitation. ETL safety & sanitation. ETL safety & sanitation. ETL safety & sanitation. ETL safety & sanitation. ETL safety & sanitation.

Additional Information:

Brewing Capacity: 60 oz. 12 Cups. 60 oz. 12 Cups. 60 oz. 12 Cups. 60 oz. 12 Cups. 60 oz. 12 Cups. 60 oz. 12 Cups.

Brewing Temperature: 192°- 196°F 192°- 196°F 192°- 196°F 192°- 196°F 192°- 196°F 192°- 196°F

Temperature Adjustment: 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease

Beverage Adjustment: 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease 3Increase. 4Decrease None None

Timer Setting: 1:50 Min., Approximately 1:50 Min., Approximately 1:50 Min., Approximately 1:50 Min., Approximately None None

Faucet Adjustment: 5 oz. in 15 to 20 seconds.

4Increase. 3Decrease

5 oz. in 15 to 20 seconds.

4Increase. 3Decrease

5 oz. in 15 to 20 seconds.

4Increase. 3Decrease

5 oz. in 15 to 20 seconds.

4Increase. 3Decrease

None None

Flow Control: .25 gpm. Not Adjustable. .25 gpm. Not Adjustable. .25 gpm. Not Adjustable. .25 gpm. Not Adjustable. None None

Hi-Limit Thermostat: Manual Reset.

Not adjustable.

Manual Reset.

Not adjustable.

Manual Reset.

Not adjustable.

Manual Reset.

Not adjustable.

Manual Reset.

Not adjustable.

Manual Reset.

Not adjustable.

Page 5

WIRING DIAGRAM

1034505, 1034506, 1034520, 1034521 – LA-3 Automatic Coffee Brewers

120V (Auto)

120/240V (Auto)

Page 6

WIRING DIAGRAM

1034505, 1034506, 1034520, 1034521 – LA-3 Automatic Coffee Brewers

120V (PO)

Page 7

TROUBLESHOOTING

Read and follow the cautions below before attempting to service this coffee brewer.

CAUTION:

Read and verify that the installation instructions have been followed before attempting to operate this appliance.

Incorrect installation or operating procedures will void the warranty and may damage this appliance.

Unplug the power cord before servicing, unless electrical testing is required. Be certain the power supply is of

the correct rating and polarity before connecting the power supply cord. The chassis must be grounded to

prevent possible electric shock. Failure to heed this warning may damage this appliance and may cause injury.

Under no circumstance should the hi-limit thermostat be by-passed. In the event of failure the hi-limit

thermostat should be replaced. Use only original or authorized replacement parts.

Carefully inspect the internal wiring for wear or damage when servicing. Worn or damaged wiring may cause

malfunctions and premature component failures. Replace any wires that have loose connections, damaged

insulation or show evidence of overheating. When repairing or replacing internal electrical wiring, in part or in

whole, use only terminals and wires with the same rating, gauge and insulation covering.

Adjusting the faucet flow beyond factory recommended settings could result in rapid cooling of the faucet flow or

result in excessive faucet head pressure.

Symptoms Solutions

1. The coffee brewer will not

operate. The lights and

warmers do not work, and the

coffee brewer will not brew

coffee.

Make sure the power supply cord is connected to a proper, working wall

receptacle.

Make sure the "Power" switch has been turned on.

Check the main circuit breaker in the building to see if it has tripped.

Reset or replace the hi-limit thermostat.

Check to make sure the internal wiring is correct. Inspect for loose,

damaged or overheating wires or terminals. Repair or replace wiring as

necessary.

Test the "Power" switch. Replace it if necessary.

Test the power supply cord. Replace it if necessary.

Page 8

Symptoms Solutions

2. The coffee brewer will not

brew coffee. The lights and

warmers work, and the coffee

brewer heats.

On automatic models, the start switch must be pressed to initiate a brew

cycle. (Automatic models only.)

On pour-over models, water must be poured in to initiate a brew cycle.

Pour in approximately 60 oz. of water for each brew cycle. See installation

instructions for correct procedures. (Pour-over models only.)

Test the start switch. Replace it if necessary. (Automatic models only.)

Inspect the reservoir and reservoir tubing for blockage.

Check to make sure the internal wiring is correct. Inspect for loose,

damaged or overheating wires or terminals. Repair or replace wiring as

necessary.

Test the timer. Replace it if necessary. (Automatic models only.)

Open the flow control and clean the flow control washer and flow control

screen. (Automatic models only.)

Test the solenoid valve. Replace it if necessary. (Automatic models only.)

If present, check any in-line water filters, check valves or shut-off valves for

proper operation or blockage. (Automatic models only.)

3. The coffee brewer will not

heat. The brew cycle and

warmers work. The water for

brewing is cold.

Test the thermostat. Replace it if necessary.

Test the thermostat sensor. Replace it if necessary. (See #7)

Test the immersion element. Replace it if necessary.

Check to make sure the internal wiring is correct. Inspect for loose,

damaged or overheating wires or terminals. Repair or replace wiring as

necessary.

4. The coffee brewer takes much

longer than normal to heat.

The lights and warmers work.

Test the thermostat. Replace it if necessary.

Test the thermostat sensor. Replace it if necessary. (See #7)

Test the voltage supply. The voltage supplied should match the voltage

requirement on the electrical nameplate.

Test the immersion element. Replace it if necessary.

Check to make sure the internal wiring is correct. Inspect for loose,

damaged or overheating wires or terminals. Repair or replace wiring as

necessary.

Page 9

Symptoms Solutions

5. The hi-limit thermostat keeps

activating.

Check to make sure the tank has been filled with water. See the installation

instructions for filling procedures.

Test the hi-limit thermostat. Replace it if necessary.

Make sure that the thermostat sensor is inserted all of the way into the well. (See

#7)

Test the brewing temperature. Adjust the thermostat if necessary. (See #7).

Inspect the wiring on the hi-limit thermostat for loose, damaged or overheating

wires or terminals. Repair or replace wiring as necessary.

WARNING

Under no circumstance should the hi-limit thermostat be by-passed. In the event

of failure, the hi-limit thermostat should be replaced. Use only original or

authorized replacement parts.

6. The coffee brewer trips the

buildings circuit breaker.

Too many appliances are connected on one electrical circuit.

The electrical circuits amperage rating is too low. Locate a correctly rated circuit

or call an electrician to correct this problem.

This coffee brewer may require a dedicated wall circuit or circuit breaker. Check

the electrical specifications.

Check to make sure the internal wiring is correct. Inspect for loose, damaged or

overheating wires or terminals. Repair or replace wiring as necessary.

Inspect the warmer elements for damage. Replace it if necessary.

Inspect the immersion element for damage. Replace it if necessary.

7. The brewing temperature is

either too hot or too cold.

Make sure that the thermostat sensor is inserted all of the way into the well.

Adjust or replace the thermostat. Turn the adjustment screw clockwise to

increase the temperature, counter-clockwise to decrease. Turn the adjustment

screw a maximum of 1/8 turn per adjustment. Retest and adjust again if

necessary. The recommended temperature is between 192°and 196°F. Test

below the brew cone with water only.

WARNING:

If the thermostat cannot be adjusted properly it should be replaced. The

thermostat is calibrated at the factory and no attempt should be made to

recalibrate it. Use only original or authorized replacement parts.

Test the thermostat sensor with an ohm meter. The sensor should read

approximately 100,000 Ωat a normal room temperature of approximately 25c.

As the heat to the sensor increases, the reading should decrease to zero.

Note: The thermostat sensor must be coated with a thermal mastic heat transfer

compound. (KMP Catalog Number PM8 or equivalent.)

Inspect the inside of the tank for excessive hard water deposits on the thermostat

well. Clean the well if necessary.

Page 10

Symptoms Solutions

8. The brewing cycle is too slow. Inspect and clean the spray head, silicone tubing and siphon fittings.

Do not over tighten the tank lid hold-down screw. (See #10.)

9. The beverage level is

consistently high or

consistently low. (Automatic

models only.)

Adjust the timer. To increase the beverage level turn the timer adjustment knob

clockwise. To decrease the beverage level turn the adjustment knob

counterclockwise. Turn the adjustment knob 1/2 reference mark maximum per

adjustment. Retest and adjust again if necessary. Note: The marks on the timer

are for reference only and are not intended as an accurate measurement of time.

Test the timer. Replace it if necessary.

Open the flow control and clean the flow control washer and flow control screen.

The flow control washer should be .25 gpm. Incorrect flow washers can cause

inaccurate beverage levels. The code printed on the back of the flow washer

should be “CCP”.

Test the incoming water supply pressure. Water pressure should be between 30

and 80 psi. If the water pressure exceeds 80 psi, install a water pressure

regulator and reduce the water pressure to 50 psi.

10. The beverage level is

inconsistent.

Inspect and clean the spray head, silicone tubing and siphon fittings.

Inspect the reservoir and reservoir tubing for blockage.

Make sure the tank cover is in place correctly and that the gaskets are in good

condition.

Do not over tighten the tank lid hold-down screw. (See page 18, Item #16.) The

screw should be just tight enough to seal the tank. Over tightening the screw can

deform the tank lid causing water leaks and can also change the angle of the

siphon fitting causing inconsistent brew levels

Water or condensation on the timer may cause it to malfunction. Dry the timer

and retest. (Automatic models only.)

Test the incoming water supply for inconsistent water pressure. If the water

pressure is inconsistent, install a water pressure regulator and reduce the water

pressure to minimize water pressure fluctuations. (Automatic models only.)

Test the timer. Replace it if necessary. (Automatic models only.)

If present, check any in-line water filters, check valves or shut-off valves for

proper operation or blockage. (Automatic models only.)

Check the faucet coil fittings inside the tank for leaks. Tighten or replace these

fittings as necessary. (Automatic models only.)

Test the solenoid valve for leaks. Repair or replace it if necessary. (Automatic

models only.)

11. Water drips from the spray

head for a long time after the

brew cycle is finished.

Inspect and clean the spray head, silicone tubing and siphon fittings.

Inspect the reservoir and reservoir tubing for blockage.

Andere Handbücher für LA-3 SERIES

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Brewmatic Kaffeemaschine Handbücher

Brewmatic

Brewmatic BICA 1033060 Bedienungsanleitung

Brewmatic

Brewmatic 1033510 Bedienungsanleitung

Brewmatic

Brewmatic DIPLOMAT II Kurzanleitung

Brewmatic

Brewmatic 1033054 Kurzanleitung

Brewmatic

Brewmatic LA-3 SERIES Handbuch

Brewmatic

Brewmatic 9700000 Bedienungsanleitung

Brewmatic

Brewmatic 1032555 Bedienungsanleitung

Beliebte Kaffeemaschine Handbücher anderer Marken

Taurus

Taurus Livorno 6 Bedienungsanleitung

Delta-q

Delta-q QUICK Bedienungsanleitung

Bunn

Bunn LCA-1 Fehlerbehebungshandbuch

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Montageanleitung

Saeco

Saeco Vienna Plus Sup 018M Bedienungsanleitung

DeLonghi

DeLonghi DC300 Bedienungsanleitung

INCAPTO

INCAPTO BXCO1470E Bedienungsanleitung

Bosch

Bosch TASSIMO finesse TAS16B Series Bedienungsanleitung

Exido

Exido 245-072 Bedienungsanleitung

Animo

Animo OptiVend Choco Bedienungsanleitung

Siemens

Siemens TQ505DF Series Bedienungsanleitung

DeLonghi

DeLonghi ECI341 Bedienungsanleitung

Krups

Krups KT406511 Bedienungsanleitung

Cimbali

Cimbali M32 Classic Bedienungsanleitung

Philips

Philips HL3844N Bedienungsanleitung

Bosch

Bosch TES 515 SERIES Bedienungsanleitung

Tekmatix

Tekmatix TMFM - 65 Bedienungsanleitung

Scarlett

Scarlett SC-CM33005 Bedienungsanleitung
