Briggs & Stratton 09P700 Series Einrichtungshandbuch

Not for

Reproduction

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS10242 REV A 03/01/2012

REPLACES FORM MS10242 REV -- 11/08/2011

FILE IN SECT. 2 OF SERVICE MANUAL

09P700

Illustrated Parts List

Model Series

09P700

TYPE NUMBERS

0001 through 0061.

TABLE OF CONTENTS

Air Cleaner 3.........................

Armature 7...........................

Blower Housing 6.....................

Camshaft 2...........................

Carburetor 4..........................

Controls 7............................

Crankshaft 2..........................

Cylinder 2............................

Cylinder Head 3.......................

Electrical System 7...................

Exhaust System 5.....................

Flywheel 6............................

Fuel Supply 5.........................

Gasket Set 2..........................

Governor Spring 7....................

Ignition 7.............................

Operator’s Manual 2..................

Piston/Rings/Connecting Rod 2........

Rewind Starter 6......................

Spark Plug 7..........................

Sump 2..............................

Warning Label 2......................

Not for

Reproduction

09P700

10242--2 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

1022

718

1058 OPERATOR’S MANUAL

1319 WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

1264

505

616

562

615

227

1036 EMISSIONS LABEL

1263

1319A WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

404

718

22A

741

524

847 523

842

522

524

358 ENGINE GASKET SET

842

868

524

163

623

Not for

Reproduction

09P700

10242--3 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

875B

968B

535

1026

1029

238

155

868

1029A

192

163

623

445

875

968

875A

1395

318

163

528

1022

914

1022

1023

Not for

Reproduction

09P700

10242--4 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

163

623

493

163

1238

951

125

121

133

975

1127

617

104

217

122

623

104

724

617

623

217

163

125A

133

975

1127

617

104

623

724

216

Not for

Reproduction

09P700

10242--5 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

972

601

187

300A

300

836

832

613

300B

832B

957

957A

836

613

836A

Not for

Reproduction

09P700

10242--6 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

455

332

305

770

930

850

363

857

857A

60A 60B

Not for

Reproduction

09P700

10242--7 Assemblies include all parts shown in frames. 03/01/2012

Illustrations cover a range of engines. Parts shown without text may not be used on your specific engine.

270

269

268

271

202

267

265

188

222

334

333

337

745

745A

209

621

922

356

383

635

923

216

505

562

227

222A

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

09P700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

10242--8 Assemblies include all parts shown in frames. 03/01/2012

1 590519 Cylinder Assembly

3 299819S Seal--Oil

(Magneto Side)

4 590569 Sump--Engine

5 590525 Head--Cylinder

7 799586 Gasket--Cylinder Head

11 590522 Tube--Breather

12 799587 Gasket--Crankcase

13 590512 Screw

(Cylinder Head)

16 590538 Crankshaft

-- -- -- -- -- -- N o t e -- -- -- -- -- --

590537 Crankshaft

Used on Type No(s).

0011, 0012, 0013,

0014, 0015, 0016,

0017, 0018, 0019,

0028, 0029, 0031,

0042, 0043, 0044,

0046, 0049, 0050,

0054, 0056, 0060.

591152 Crankshaft

Used on Type No(s).

0037, 0047.

20 391483S Seal--Oil

(PTO Side)

22 692551 Screw

(Crankcase

Cover/Sump)

22A 590763 Screw

(Crankcase

Cover/Sump)

23 590544 Flywheel

24 222698S Key--Flywheel

25 590521 Piston Assembly

(Standard)

26 590523 Ring Set

(Standard)

27 691588 Lock--Piston Pin

28 699659 Pin--Piston

29 590518 Rod--Connecting

32 691664 Screw

(Connecting Rod)

33 590531 Valve--Exhaust

34 590530 Valve--Intake

35 590532 Spring--Valve

(Intake)

36 590532 Spring--Valve

(Exhaust)

37 590582 Guard--Flywheel

40 590528 Retainer--Valve

43 697799 Slinger--Governor/Oil

45 590514 Tappet--Valve

46 590524 Camshaft

58 591108 Rope--Starter

60 691915 Grip--Starter Rope

60A 281434S Grip--Starter Rope

60B 799716 Grip--Starter Rope

75 590546 Washer

(Flywheel)

78 793480 Screw

(Flywheel Guard)

104 590558 Pin--Float Hinge

121 590589 Kit--Carburetor

Overhaul

122 590549 Spacer--Carburetor

125 591109 Carburetor

-- -- -- -- -- -- N o t e -- -- -- -- -- --

799584 Carburetor

Used on Type No(s).

0001, 0003, 0005,

0006, 0007, 0010,

0024, 0033, 0045,

0046, 0047, 0055.

125A 591110 Carburetor

Used on Type No(s).

0011, 0012, 0015,

0017, 0021, 0023,

0028, 0029, 0034,

0040, 0043, 0048,

0056, 0057, 0058.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

590556 Carburetor

Used on Type No(s).

0002, 0004, 0008,

0009, 0025, 0027,

0036, 0037.

133 591120 Float--Carburetor

155 590529 Plate--Cylinder Head

163 799580 Gasket--Air Cleaner

187 791766 Line--Fuel

(Cut To Required

Length)

188 793480 Screw

(Control Bracket)

192 590535 Adjuster--Rocker Arm

202 590517 Link--Mechanical

Governor

209 590541 Spring--Governor

-- -- -- -- -- -- N o t e -- -- -- -- -- --

591497 Spring--

Governor

Used on Type No(s).

0057, 0058.

216 590547 Link--Choke

217 590740 Spring--Choke Return

222 590560 Bracket--Control

222A 590561 Bracket--Control

Used on Type No(s).

0012, 0013, 0017,

0018, 0031, 0048,

0050, 0056, 0057,

0058.

227 590520 Lever--Governor

Control

238 590533 Cap--Valve

265 690798 Clamp--Casing

267 691044 Screw

(Casing Clamp)

268 691025 Casing--Control Wire

(Cut To Required

Length)

269 691026 Wire--Control

(Cut To Required

Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever--Control

300 590563 Muffler

300A 590564 Muffler

Used on Type No(s).

0034, 0057, 0058.

300B 590565 Muffler

305 590586 Screw

(Blower Housing)

318 793480 Screw

(Mounting Bracket)

332 690662 Nut

(Flywheel)

333 799582 Armature--Magneto

334 691061 Screw

(Magneto Armature)

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

09P700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

10242--9 Assemblies include all parts shown in frames. 03/01/2012

337 692051 Plug--Spark

-- -- -- -- -- -- N o t e -- -- -- -- -- --

491055S Plug--Spark

Used on Type No(s).

0007, 0008, 0009.

797434 Plug--Spark

Used on Type No(s).

0015.

692720 Plug--Spark

Used on Type No(s).

0016, 0017, 0018,

0022, 0028, 0049.

356 692390 Wire--Stop

358 590590 Gasket Set--Engine

363 19069 Puller--Flywheel

383 19576S Wrench--Spark Plug

404 690272 Washer

(Governor Crank)

445 798452 Filter--Air Cleaner

Cartridge

455 590545 Cup--Flywheel

493 590551 Bracket--Mounting

(Carburetor)

505 793515 Nut

(Governor Control

Lever)

522 590580 Plug--Dipstick/Fill

523 796503 Dipstick

524 691876 Seal--Dipstick Tube

528 793006 Hose--Primer

(Cut to Required

Length)

535 799579 Filter--Air Cleaner

Foam

562 793514 Bolt

(Governor--Control

Lever)

601 791850 Clamp--Hose

613 590562 Screw

(Muffler)

615 690340 Retainer--Governor

Shaft

616 590516 Crank--Governor

617 270344S Seal--O Ring

621 692310 Switch--Stop

623 799581 Seal--O Ring

(Carburetor Spacer)

635 692076 Boot--Spark Plug

718 690959 Pin--Locating

(Crankcase Cover)

724 697478 Retainer--Seal

741 796210 Gear--Timing

(Plastic)

745 691146 Screw

(Brake)

745A 690859 Screw

(Brake)

770 590588 Kit--Rewind/Blower

Housing

832 590566 Guard--Muffler

832B 590567 Guard--Muffler

836 690661 Screw

(Muffler Guard)

836A 793500 Screw

(Muffler Guard)

842 691876 Seal--O Ring

(Dipstick Tube)

847 590572 Dipstick/Tube

Assembly

850 100106 Sealant--Silicone

857 591113 Trim--Blower Housing

Cover

857A 591114 Trim--Blower Housing

Cover

868 590534 Seal--Valve

(Intake)

875 590553 Base--Air Cleaner

875A 590557 Base--Air Cleaner

Used on Type No(s).

0011, 0012, 0015,

0017, 0021, 0023,

0028, 0029, 0034,

0040, 0043, 0048,

0056, 0057, 0058.

875B 590584 Base--Air Cleaner

Used on Type No(s).

0002, 0004, 0008,

0009, 0025, 0027,

0036, 0037.

914 591103 Screw

(Rocker Arm Cover)

922 692135 Spring--Brake

923 691487 Brake

930 590585 Guard--Rewind

951 591104 Lever--Choke

957 799585 Cap--Fuel Tank

(Black)

-- -- -- -- -- -- N o t e -- -- -- -- -- --

591003 Cap--Fuel

Tank

(Red)

957A Cap--Fuel Tank

(Order Replacement

Fuel Tank Cap

Reference Number

957)

968 590548 Cover--Air Cleaner

968B 590581 Cover--Air Cleaner

Used on Type No(s).

0002, 0004, 0008,

0009, 0025, 0027,

0036, 0037.

972 590568 Tank--Fuel

975 591116 Bowl--Float

1022 591255 Gasket--Rocker Cover

1023 590513 Cover--Rocker Arm

1026 590515 Rod--Push

1029 590526 Arm--Rocker

1029A 590527 Arm--Rocker

1036 Label--Emissions

(Available From A

Briggs & Stratton

Authorized Dealer)

1058 380406 Manual--Operator’s

1127 590554 Screw

(Float Bowl to

Carburetor Body)

1238 590550 Screw

(Carburetor Spacer)

1263 697124 Reed--Breather

1264 793453 Screw

(Breather Reed)

1319 794467 Label--Warning

1319A 797669 Label--Warning

1395 590552 Screw

(Air Cleaner Base to

Carburetor)

Not for

Reproduction

Andere Briggs & Stratton Motor Handbücher

Briggs & Stratton

Briggs & Stratton 60700 Series Handbuch

Briggs & Stratton

Briggs & Stratton Intek 200000 Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 255700 Series Handbuch

Briggs & Stratton

Briggs & Stratton 90000 series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 445600 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton Vanguard 380000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 11000B Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 21000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton PROFESSIONAL SERIES 110000 Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton Classic 100000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 204400 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 131D000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 190000 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 543200 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton Vanguard 290000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 120000 Handbuch

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 406700 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 54E000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 21000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 276781 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 130000 950 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton PROFESSIONAL SERIES 110000 Bedienungsanleitung

Beliebte Motor Handbücher anderer Marken

Rotax

Rotax 125 senior MAX evo Bedienungsanleitung

Kohler

Kohler K361 Bedienungsanleitung

MTD

MTD OHV Series Bedienungsanleitung

Kohler

Kohler COMMAND CH18-745 Bedienungsanleitung

Mercury

Mercury D4.2L D-Tronic Bedienungsanleitung

Selve

Selve SE Plus-RC Series Bedienungsanleitung

Perkins

Perkins 1206E-E66TA Bedienungsanleitung

Skov

Skov DA 174 Handbuch

Rossi

Rossi TX11 Series Bedienungsanleitung

Siemens

Siemens SIMOTICS T-1FW3 Merkblatt

AL-KO

AL-KO PRO 350 Bedienungsanleitung

MTU

MTU 12 V 4000 Lx4 Bedienungsanleitung

Nanni

Nanni N3.30 Gebrauchsanweisung

Nanni

Nanni N5.160 CR2 Bedienungsanleitung

KSB

KSB SuPreme Series Montageanleitung

Hiwin

Hiwin EM1 Series Bedienungsanleitung

Rotax

Rotax 912 i series Betriebsanleitung

Siemens

Siemens SIMOTICS XP 1MB1 Bedienungsanleitung
