Briggs & Stratton 319700 Series Einrichtungshandbuch

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS--6142--07/22/2010

REPLACES FORM MS--6142--05/10/2010

FILE IN SECT. 2 OF SERVICE MANUAL

319700

Illustrated Parts List

Model Series

319700

TYPE NUMBERS

0110 THROUGH 0115.

TABLE OF CONTENTS

Air Cleaner 6.........................

Blower Housing 6.....................

Camshaft 2...........................

Carburetor 4..........................

Controls 7............................

Crankshaft 2..........................

Cylinder 2............................

Cylinder Head 3.......................

Electric Starter 7......................

Engine Sump 2.......................

Flywheel 6............................

Fuel Supply 4.........................

Gasket Set -- Engine 2.................

Gasket Set -- Valve 3..................

Governor Spring 7....................

Ignition 7.............................

Intake Manifold 3.....................

Kit -- Carburetor Overhaul 4............

Lubrication 3.........................

Operator’s Manual 2..................

Piston, Rings, Connecting Rod 2.......

Valves 3..............................

Warning Label 2......................

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--2 Assemblies include all parts shown in frames. 07/22/2010

1017

29 32

307

306

718

691

552

684 11

584

585

1263

1264

1270

758

759

757

741

146

16 46

1058 OPERATOR’S MANUAL 1319 WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

850

239

1027

1022

585

358 ENGINE GASKET SET

868

691

524

20 617

883

1266

842

1266A 51A

943

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--3 Assemblies include all parts shown in frames. 07/22/2010

617

830

1034

1022

238 36

868

1029

534

192

383

337

635

1026

1022

868

1095 VALVE GASKET SET

847

523

842

525

524

750

943

965 42

883

1022

1023

914

850

54 654

1024A

883

51A

307 306

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--4 Assemblies include all parts shown in frames. 07/22/2010

431 1266A

1266

125

NIKKI

142

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--5 Assemblies include all parts shown in frames. 07/22/2010

1267

305

305A

1036 EMISSIONS LABEL

1040

304 1267

967

643

968

445 187D

601

187A

601

773

1139

304D

967

643

968

445

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--6 Assemblies include all parts shown in frames. 07/22/2010

783

1051

363

1044

1005

1005A

415A

1070A

1070

73B 324

Not for

Reproduction

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--7 Assemblies include all parts shown in frames. 07/22/2010

851

334

333

729

202

232

268

269

271

270

209 188

616

404

614

562

505

227

697

729A

802

462

579

503

310

801

309

1090 311

797

521

222A

356

1051

510

513

783

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--8 Assemblies include all parts shown in frames. 07/22/2010

1 796010 Cylinder Assembly

-- -- -- -- -- -- N o t e -- -- -- -- -- --

796010 Cylinder

Assembly

(Used Before Code

Date 08042800)

Must Be Used With

The After 08042700

Cylinder Shield, Ref

306.

2 399265 Kit--Bushing/Seal

(Magneto Side)

3 391086S Seal--Oil

(Magneto Side)

4A 790725 Sump--Engine

(Used After Code Date

05100200).

-- -- -- -- -- -- -- N o t e -- -- -- -- --

795939 Sump--Engine

(Used Before Code

Date 05100300).

(Must Use Kit 795939,

Includes Sump And

Counterweight).

5 796026 Head--Cylinder

6 690310 Washer

(Used After Code Date

07070900).

7 796584 Gasket--Cylinder Head

(Breather Assembly)

11 794683 Tube--Breather

12 697110 Gasket--Crankcase

(.015” Thick)

(Standard)

13 793988 Screw

(Cylinder Head)

(Used After Code Date

07010900).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

690360 Screw

(Cylinder Head)

(Used Before Code

Date 07011000).

15 690946 Plug--Oil Drain

(Square Head)

16 699106 Crankshaft

Used on Type No(s).

0110.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

797584 Crankshaft

Used on Type No(s).

0114, 0115.

793245 Crankshaft

Used on Type No(s).

0112, 0113.

20 795387 Seal--Oil

(PTO Side)

22 692125 Screw

(Crankcase

Cover/Sump)

23 693557 Flywheel

-- -- -- -- -- -- N o t e -- -- -- -- -- --

698281 Flywheel

Used on Type No(s).

0114, 0115.

24 222698S Key--Flywheel

25 796172 Piston Assembly

(Standard)

-- -- -- -- -- -- N o t e -- -- -- -- -- --

796173 Piston

Assembly

(.020” Oversize)

26 791936 Ring Set

(Standard)

(Used After Code Date

08042700).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

699026 Ring Set

(Standard)

(Used Before Code

Date 08042800).

792649 Ring Set

(.020” Oversize)

27 698469 Lock--Piston Pin

28 796007 Pin--Piston

(Standard)

(Used After Code Date

08042700).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

697099 Pin--Piston

(Standard)

(Used Before Code

Date 08042800).

29 794122 Rod--Connecting

(Standard)

Used on Type No(s).

0110.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

794571 Rod--

Connecting

(Standard)

Used on Type No(s).

0112, 0113, 0114,

0115.

32 791118 Screw

(Connecting Rod)

33 792868 Valve--Exhaust

34 791935 Valve--Intake

35 691279 Spring--Valve

(Intake)

36 691279 Spring--Valve

(Exhaust)

37 697352 Guard--Flywheel

42 499586 Keeper--Valve

43 691968 Slinger--Governor/Oil

45 690564 Tappet--Valve

46 793880 Camshaft

50 793668 Manifold--Intake

51 692137 Gasket--Intake

51A 692137 Gasket--Intake

53 690227 Stud

(Carburetor)

54 691148 Screw

(Intake Manifold)

73B 697133 Screen--Rotating

(Used Before Code

Date 07040900).

74 697897 Screw

(Rotating Screen)

78 691003 Screw

(Flywheel Guard)

125 793115 Carburetor

(Nikki Mixer Assembly)

142 793906 Nozzle--Carburetor

146 691639 Key--Timing

187A 791806 Line--Fuel

(Formed)(21 Inches

Long)(Cut to Required

Length)

187D 791744 Line--Fuel

(Formed)(14 Inches

Long)(Cut to Required

Length)

188 691693 Screw

(Control Bracket)

192 691986 Adjuster--Rocker Arm

202 691841 Link--Mechanical

Governor

209 792602 Spring--Governor

(Used After Code Date

05112700).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

690480 Spring--

Governor

(Used Before Code

Date 05112800).

222A 694335 Bracket--Control

227 694339 Lever--Governor

Control

232 691842 Spring--Governor Link

238 691843 Cap--Valve

239 694115 Switch--Oil Pressure

268 691025 Casing--Control Wire

(Cut To Required

Length)

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--9 Assemblies include all parts shown in frames. 07/22/2010

269 691026 Wire--Control

(Cut To Required

Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever--Control

304 796416 Housing--Blower

(Black)

(Used After Code Date

08082400).

304D 790719 Housing--Blower

(Black)

(Used Before Code

Date 08082500).

305 697102 Screw

(Blower Housing)

305A 793376 Screw

(Blower Housing)

306 796006 Shield--Cylinder

(Used After Code Date

08042700).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

697107 Shield--

Cylinder

(Used Before Code

Date 08042800).

307 691003 Screw

(Cylinder Shield)

309 693552 Motor--Starter

310 691263 Screw

(Starter Motor)

311 497608 Brush Set

324 796308 Screen--Rotating

(Used After Code Date

07040800)

333 795315 Armature--Magneto

334 691061 Screw

(Magneto Armature)

337 491055S Plug--Spark

356 697397 Wire--Stop

358 796187 Gasket Set--Engine

363 19203 Puller--Flywheel

383 89838S Wrench--Spark Plug

404 691691 Washer

(Governor Crank)

415A 794129 Plug

(Cover/Retainer)

431 793669 Elbow--Intake

445 790263 Filter--Air Cleaner

Cartridge

(UL Recognized)

462 691261 Washer

(Starter Cable)

503 691532 Strap--Starter

505 691251 Nut

(Governor Control

Lever)

510 693699 Drive--Starter

513 692024 Clutch--Drive

521 690581 Shield--Cable

523 699908 Dipstick

524 691032 Seal--Dipstick Tube

525 697184 Tube--Dipstick

552 697144 Bushing--Governor

Crank

562 691119 Bolt

(Governor Control

Lever)

579 691029 Nut

(Starter Cable)

584 794682 Cover--Breather

Passage

(Use With Liquid

Sealant Reference

850)

585 697109 Gasket--Breather

(Used Before Code

Date 07071900).

(After Date Code Use

Liquid Sealant

Reference 850)

601 791850 Clamp--Hose

(Green)

614 691620 Pin--Cotter

616 692012 Crank--Governor

617 692138 Seal--O Ring

(Intake Manifold)

635 691909 Boot--Spark Plug

643 698401 Retainer--Air Filter

654 690958 Nut

(Carburetor)

684 697157 Screw

691 692407 Seal--Governor Shaft

697 791680 Screw

(Drive Cap)

718 690959 Pin--Locating

729 691335 Clip--Wire

(Wire Saddle)

729A 691224 Clip--Wire

(Aluminum Coated

Steel)

741 697128 Gear--Timing

750 790832 Screw

(Oil Pump Cover)

757 793242 Link--Counterweight

773 796448 Retainer

(Fuel Pump)

758 793763 Counterweight

(Used After Code Date

05100200).

-- -- -- -- -- -- -- N o t e -- -- -- -- --

795939 Counterweight

(Used Before Code

Date 05100300).

(Must Use Kit 795939,

Includes Sump And

Counterweight).

759 697392 Pin--Counterweight

783 693713 Gear--Pinion

797 693167 Nut

(Brush Retainer)

801 691283 Cap--Drive

802 691286 Cap--End

830 691095 Stud--Rocker Arm

842 691031 Seal--O Ring

(Dipstick Tube)

847 790442 Dipstick/Tube

Assembly

850 100100 Sealant--Liquid

(Rocker Cover Gasket

and Breather Gasket)

(Used After Code Date

07071800).

851 692424 Terminal--Spark Plug

868 690968 Seal--Valve

883 692236 Gasket--Exhaust

914 697551 Screw

(Rocker Cover)

943 690589 Seal--O Ring

(Oil Pump Cover)

965 499613 Cover--Oil Pump

967 697015 Filter--Pre Cleaner

968 698403 Cover--Air Cleaner

(Black)

1005 796083 Fan--Flywheel

(Used After Code Date

07040800).

1005A 796201 Fan--Flywheel

(Used Before Code

Date 07040900).

1017 690770 Screen--Oil Pump

(Push In)

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

319700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6142--10 Assemblies include all parts shown in frames. 07/22/2010

1022 272475S Gasket--Rocker Cover

(Used Before Code

Date 07091000).

(After Date Code Use

Liquid Sealant

Reference 850)

1023 797421 Cover--Rocker

1024A 794644 Pump--Oil

(Used After Code Date

07051600).

1026 692003 Rod--Push

(Intake)

-- -- -- -- -- -- N o t e -- -- -- -- -- --

692011 Rod--Push

(Exhaust)

1027 492932S Filter--Oil

1029 691751 Arm--Rocker

1034 690822 Guide--Push Rod

1035 693784 Shaft--Pump

1036 Label--Emissions

(Available From A

Briggs & Stratton

Authorized Dealer)

1040 698368 Plate--Trim

1044 698139 Screw

(Flywheel)

1051 691265 Ring--Retaining

1058 277766 Manual--Operator’s

1070 791680 Screw

(Flywheel Fan)

(Used Before Code

Date 07040900).

1070A 690363 Screw

(Flywheel Fan)

(Used Before Code

Date 08061000 and

After Code Date

07040800).

1090 691293 Retainer--Brush

1095 690190 Gasket Set--Valve

1139 796449 Washer

1263 697124 Reed--Breather

1264 697104 Screw

(Breather Reed)

1266 691917 Seal--O Ring

(Intake Elbow)

1266A 697123 Seal--O Ring

(Intake Elbow)

1267 697419 Latch--Blower Housing

1270 793243 Plug--AVS

Counterweight

(Used After Code Date

06081300).

-- -- -- -- -- -- N o t e -- -- -- -- -- --

697156 Plug--AVS

Counterweight

(Used Before Code

Date 06081400).

1319 794467 Warning Label

Not for

Reproduction

Andere Briggs & Stratton Motor Handbücher

Briggs & Stratton

Briggs & Stratton Intekt 825 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 21000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton Vanguard 300000 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 445600 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 233400 to 233499 Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 400000 Professional Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Bedienungs- und Montageanleitung

Briggs & Stratton

Briggs & Stratton 126L00 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 90000 series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 91200 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton Classic Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 21000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton THE POWER WITHIN 625 SERIES Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 205300 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 400000 Professional Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 280000 Series Installations- und Betriebshandbuch

Briggs & Stratton

Briggs & Stratton 210000 Series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 170700 Series Handbuch

Briggs & Stratton

Briggs & Stratton 110600 series Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton NXT2242 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton 356400 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 49G500 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton 281H00 Series Einrichtungshandbuch

Briggs & Stratton

Briggs & Stratton Classic 100000 Series Bedienungsanleitung

Beliebte Motor Handbücher anderer Marken

Rotax

Rotax 125 senior MAX evo Bedienungsanleitung

Kohler

Kohler K361 Bedienungsanleitung

MTD

MTD OHV Series Bedienungsanleitung

Kohler

Kohler COMMAND CH18-745 Bedienungsanleitung

Mercury

Mercury D4.2L D-Tronic Bedienungsanleitung

Selve

Selve SE Plus-RC Series Bedienungsanleitung

Perkins

Perkins 1206E-E66TA Bedienungsanleitung

Skov

Skov DA 174 Handbuch

Rossi

Rossi TX11 Series Bedienungsanleitung

Siemens

Siemens SIMOTICS T-1FW3 Merkblatt

AL-KO

AL-KO PRO 350 Bedienungsanleitung

MTU

MTU 12 V 4000 Lx4 Bedienungsanleitung

Nanni

Nanni N3.30 Gebrauchsanweisung

Nanni

Nanni N5.160 CR2 Bedienungsanleitung

KSB

KSB SuPreme Series Montageanleitung

Hiwin

Hiwin EM1 Series Bedienungsanleitung

Rotax

Rotax 912 i series Betriebsanleitung

Siemens

Siemens SIMOTICS XP 1MB1 Bedienungsanleitung
