Brocade® 7850 Extension Switch Hardware Installation Guide
Installation Guide
July 31, 2023
7850-Install-IG101
July 31, 2023
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Table of Contents
Introduction...........................................................................................................................................6
Supported Hardware and Software................................................................................................................................ 6
Notes, Cautions, and Danger Notices........................................................................................................................... 6
Contacting Technical Support for Your Brocade® Product......................................................................................... 6
Document Feedback........................................................................................................................................................ 7
Device Overview...................................................................................................................................8
Brocade 7850 Extension Switch Software Features.................................................................................................... 8
Brocade 7850 Extension Switch Hardware Features................................................................................................... 9
Brocade 7850 Extension Switch Configurations...........................................................................................................9
Port-Side View of the Device........................................................................................................................................ 10
Nonport-Side View of the Device................................................................................................................................. 11
Device Management Options........................................................................................................................................ 12
Preparing for Installation.................................................................................................................. 13
Safety Precautions......................................................................................................................................................... 13
General Precautions..................................................................................................................................................13
ESD Precautions....................................................................................................................................................... 14
Power Precautions.................................................................................................................................................... 14
Lifting and Weight-Related Precautions................................................................................................................... 15
Laser Precautions..................................................................................................................................................... 15
Facility Requirements.................................................................................................................................................... 16
Quick Installation Checklist.......................................................................................................................................... 17
Shipping Carton Contents.............................................................................................................................................19
Mounting the Device..........................................................................................................................20
Precautions Specific to Mounting................................................................................................................................ 20
Installing the Device as a Standalone Unit................................................................................................................. 21
Installing the Universal Four-Post Rack Kit (XBR-R000296).....................................................................................21
Time and Items Required......................................................................................................................................... 22
Parts List................................................................................................................................................................... 23
Flush-Front Mounting................................................................................................................................................ 24
Attaching the Front Brackets............................................................................................................................. 25
Attaching the Extension Brackets to the Device............................................................................................... 26
Installing the Device in the Rack.......................................................................................................................27
Attaching the Rear Brackets to the Extensions................................................................................................ 28
Attaching the Rear Brackets to the Rack Posts................................................................................................29
Flush-Rear (Recessed) Mounting............................................................................................................................. 30
Attaching the Front Brackets to the Rear of the Device................................................................................... 30
7850-Install-IG101
2
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Attaching the Extensions to the Front of the Device........................................................................................ 32
Installing the Device in the Rack.......................................................................................................................33
Attaching the Rear Brackets to the Extensions at the Front of the Device.......................................................34
Attaching the Rear Brackets to the Front Rack Posts...................................................................................... 36
Installing the Universal Two-Post Rack Kit (XBR-R000294)...................................................................................... 37
Time and Items Required......................................................................................................................................... 37
Parts List................................................................................................................................................................... 38
Flush-Front Mounting................................................................................................................................................ 39
Attaching the Front Brackets to the Device...................................................................................................... 40
Attaching the Front Brackets to the Rack......................................................................................................... 41
Attaching the Rear Brackets to the Rack..........................................................................................................42
Attaching the Rear Brackets to the Device....................................................................................................... 43
Mid-Mounting............................................................................................................................................................. 43
Attaching the Front Brackets to the Device...................................................................................................... 44
Attaching the Front Brackets to the Rack......................................................................................................... 45
Attaching the Rear Brackets to the Rack..........................................................................................................46
Attaching the Rear Brackets to the Device....................................................................................................... 47
Initial Setup and Verification.............................................................................................................48
Items Required................................................................................................................................................................48
Providing Power to the Device.....................................................................................................................................48
Establishing a First-Time Serial Connection.............................................................................................................. 48
Configuring the IP Address.......................................................................................................................................... 49
Using DHCP to Set the IP Address......................................................................................................................... 50
Setting a Static IP Address.......................................................................................................................................50
Setting the Date and Time............................................................................................................................................ 50
Setting the Time Zone.............................................................................................................................................. 51
Synchronizing the Local Time with an External Source...........................................................................................51
Customizing the Chassis Name and Switch Name.................................................................................................... 52
Establishing an Ethernet Connection.......................................................................................................................... 52
Setting the Domain ID................................................................................................................................................... 52
FCIP and Fibre Channel Routing Services Configuration......................................................................................... 53
Verifying Correct Operation.......................................................................................................................................... 53
Backing Up the Configuration...................................................................................................................................... 54
Powering Down the Device........................................................................................................................................... 55
Installing Transceivers and Cables..................................................................................................56
Precautions Specific to Transceivers and Cables......................................................................................................56
Cleaning the Fiber-Optic Connectors.......................................................................................................................... 56
Managing Cables............................................................................................................................................................ 56
Installing an SFP+ Transceiver.....................................................................................................................................57
7850-Install-IG101
3
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Replacing an SFP+ Transceiver................................................................................................................................... 59
Installing an SFP-DD Transceiver.................................................................................................................................61
Replacing an SFP-DD Transceiver............................................................................................................................... 64
Verifying the Operation of New Transceivers............................................................................................................. 66
Monitoring the Device....................................................................................................................... 67
Interpreting Port-Side LEDs.......................................................................................................................................... 67
System Power LED........................................................................................................................................................ 68
System Status LED........................................................................................................................................................ 68
Management Port LEDs.................................................................................................................................................69
FC Port (SFP-DD) Status LEDs.....................................................................................................................................69
FC Port (SFP+) Status LEDs.........................................................................................................................................69
Ethernet Port (SFP+) Status LEDs............................................................................................................................... 70
Ethernet Port (QSFP) Status LEDs.............................................................................................................................. 71
Interpreting Nonport-Side LEDs................................................................................................................................... 71
Interpreting POST Results............................................................................................................................................ 72
Interpreting Boot Results.............................................................................................................................................. 72
Running Diagnostic Tests............................................................................................................................................. 72
Power Supply Assemblies................................................................................................................ 74
Precautions Specific to the Power Supply Assemblies............................................................................................ 75
Identifying the Direction of the Power Supply Assembly Airflow............................................................................ 75
Power Supply Assembly Fault Indicators................................................................................................................... 76
Power Supply Assembly Task Guide...........................................................................................................................77
Installing an Additional Power Supply (Hot-Install)...................................................................................................77
Replacing a Power Supply (Hot-Swap).................................................................................................................... 77
Replacing Both Power Supplies (Cold-Swap).......................................................................................................... 77
Time and Items Required.............................................................................................................................................. 77
Recording Critical Information about the Power Supply Assembly.........................................................................78
Removing a Power Supply Assembly......................................................................................................................... 78
Inserting a New Power Supply Assembly................................................................................................................... 79
Verifying the Operation of the Power Supply Assemblies........................................................................................ 80
Fan Assemblies.................................................................................................................................. 81
Precautions Specific to the Fan Assemblies.............................................................................................................. 81
Identifying the Direction of the Fan Assembly Airflow..............................................................................................82
Fan Assembly Fault Indicators.....................................................................................................................................82
Fan Assembly Task Guide............................................................................................................................................ 82
Replacing a Fan Assembly (Hot-Swap)................................................................................................................... 82
Inserting a New Fan Assembly.................................................................................................................................83
Time and Items Required.............................................................................................................................................. 84
Recording Critical Information about the Fan Assembly.......................................................................................... 84
7850-Install-IG101
4
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Removing a Fan Assembly........................................................................................................................................... 84
Inserting a New Fan Assembly.....................................................................................................................................85
Verifying the Operation of the Fan Assemblies......................................................................................................... 86
Technical Specifications....................................................................................................................87
Regulatory Statements...................................................................................................................... 92
BSMI Statement (Taiwan)...............................................................................................................................................92
Canadian Requirements................................................................................................................................................ 92
CE Statement.................................................................................................................................................................. 92
FCC Warning (U.S. Only)...............................................................................................................................................92
KCC Statement (Republic of Korea)............................................................................................................................ 93
VCCI Statement...............................................................................................................................................................93
Regulatory Compliance................................................................................................................................................. 93
Cautions and Danger Notices...........................................................................................................95
Cautions...........................................................................................................................................................................95
Danger Notices............................................................................................................................................................... 97
Revision History............................................................................................................................... 101
Documentation Legal Notice.......................................................................................................... 102
7850-Install-IG101
5
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Introduction
This guide contains installation procedures and safety requirements for installing your switch into a rack system or as a
stand-alone device.
Also provided are steps to initially configure the Brocade® 7850 Extension Switch for operation, to verify and monitor
operation, to replace switch field-replaceable units (FRUs), and to install transceivers and cables. Complete technical
specifications for the switch are also included in this guide.
Supported Hardware and Software
The Brocade 7850 Extension Switch is introduced in the Fabric OS® 9.2.0 software release. The following tables list the
power supplies, the fan assemblies, and the rack mount kits supported on this device.
Table 1: Power Supply and Fan Assemblies
Part Number Description Quantity
XBR-650WPSAC-R 650W (maximum), AC/DC power supply FRU with nonport-side intake airflow 2
XBR-FAN-40-R Fan assembly FRU with nonport-side intake airflow 6
Table 2: Rack Mount Kits
Part Number Description
XBR-R000294 Universal two-post mid-mount or flush-mount rack kit
XBR-R000296 Universal four-post fixed flush-mount rack kit
Notes, Cautions, and Danger Notices
Notes, cautions, and danger statements may be used in this document.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related
information.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to
hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to
you. Safety labels are also attached directly to products to warn of these conditions or situations.
Contacting Technical Support for Your Brocade® Product
If you purchased Brocade® product support from a Broadcom® OEM or solution provider, contact your OEM or solution
provider for all your product support needs.
7850-Install-IG101
6
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
•OEM and solution providers are trained and certified by Broadcom to support Brocade products.
•Broadcom provides backline support for issues that cannot be resolved by the OEM or solution provider.
•Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade
expertise. For more information on this option, contact Broadcom or your OEM.
•For questions regarding service levels and response times, contact your OEM or solution provider.
If you purchased Brocade product support directly from Broadcom, use one of the following methods to contact the
Technical Assistance Center 24x7. For product support information and the latest information on contacting the Technical
Assistance Center, go to www.broadcom.com/support/fibre-channel-networking/contact-brocade-support.
Online Telephone
For nonurgent issues, the preferred method is to log on to the
Support portal at support.broadcom.com. (You must initially
register to gain access to the Support portal.) Once registered, log
on and then select Hardware > Brocade Storage Networking.
You can now navigate to any of the Brocade tools.
For Severity 1 (critical) issues, call Brocade Fibre Channel
Networking Global Support at one of the phone numbers listed at
www.broadcom.com/support/fibre-channel-networking/contact-
brocade-support.
Document Feedback
Quality is our first concern. We have made every effort to ensure the accuracy and completeness of this document.
However, if you find an error or an omission or if you think that a topic needs further development, we want to hear from
you. Send your feedback to [email protected]. Provide the publication title; topic heading; publication
number and page number (for PDF documents); URL (for HTML documents); and as much detail as possible.
7850-Install-IG101
7
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Device Overview
The Brocade 7850 Extension Switch is intended as a platform for Fibre Channel over IP (FCIP) and IP Extension. The
Brocade 7850 Extension Switch supports high performance, secure, and highly reliable transport of replication traffic over
distance, for replication traffic originating in either FC or IP.
The switch can operate independently or in a fabric containing multiple extension switches.
Brocade 7850 Extension Switch Software Features
The Brocade 7850 Extension Switch offers the following software features and capabilities:
•Multiple logical tunnels with a maximum tunnel bandwidth up to 50Gb/s allow for scalable connectivity between sites.
The Brocade 7850 Extension Switch supports connectivity to the Brocade SX6 Extension blade and the Brocade 7810
Extension switch. The Brocade 7850 Extension Switch does not support tunnel connectivity with any other products
including the Brocade 7800, 7840, and FX8-24.
•Extension Trunking allows multiple IP source and destination address pairs (defined as circuits) through multiple
1GbE, 10GbE, 25GbE, and 100GbE interfaces to provide high bandwidth tunnel and lossless failover resiliency. Each
FCIP circuit supports four QoS classes (Class-F, High, Medium, and Low Priority), each as a TCP connection. When
enabled for IP Extension, the tunnel supports up to seven QoS queues (Class-F, FC-High, FC-Medium, FC-Low, IP-
High, IP-Medium, and IP-Low).
•Adaptive Rate Limiting (ARL) provides a minimum bandwidth guarantee for each tunnel while making the full utilization
of the available network bandwidth without adverse throughput performance impact at high traffic load. ARL also
ensures that the Brocade 7850 Extension Switch can be a good citizen on shared WAN connections, preserving
prescribed bandwidth for other workloads when they are active.
•Hardware-based compression delivers the ability to maximize throughput over lower bandwidth links in the wide area
network, optimizing the cost efficiencies of FCIP. The Brocade 7850 Extension Switch compresses FC frames before
they are encapsulated into FCIP packets. The IP Extension traffic cannot be compressed using hardware-based
compression. Only FC traffic over a tunnel can be compressed using hardware-based compression.
•Key protocol features are enabled in the implementation to optimize performance of Extension over IP networks,
including WAN Optimized TCP (WO-TCP), 9K jumbo frame, and end-to-end Path MTU auto discovery.
•Hardware-based IPsec supports a mix of secure and non-secure tunnels on the same Ethernet port, jumbo frames,
and VLAN tagged connections. The Brocade 7850 Extension Switch IPsec function is capable of supporting both IPv4
and IPv6.
•FastWrite, Open Systems Tape Pipelining, and Advanced Accelerator for FICON (included with the mainframe SKU)
mitigate the latency effect of a long distance FCIP distance connection over IP WAN.
•eHCL (Extension Hot Code Load) provides In-service firmware upgrade for supporting 24/7 non-stop business
operations.
•Built-in WAN link tester generates traffic over an IP connection to test for maximum throughput, congestion, loss
percentage, out of order deliver, latency, and other network conditions. The built-in WAN link tester helps determine the
health of a WAN link before deploying it for use.
•Fabric Vision advanced monitoring provides the following functions:
–Policy-based monitoring monitors Extension connectivity and WAN anomalies using multi-layer metrics.
–Flow monitoring reports IOPS and data rate of individual I/O flows of inter-DC replication and tape backup
operations.
–Flow generator generates FC frames for a defined flow with default or custom size and pattern and sent across an
Extension tunnel to help validate end-to-end network setup and configuration.
•Brocade Fabric OS delivers distributed intelligence throughout the network and enables a wide range of value-added
applications.
7850-Install-IG101
8
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
Brocade 7850 Extension Switch Hardware Features
The Brocade 7850 Extension Switch provides the following hardware features:
•Rack-mountable 1U chassis
•Eight SFP-DD ports and eight SFP+ ports
–The switch offers 16 physical Fibre Channel ports, 8 of which are SFP-DD-capable ports, and 8 of which are SFP+
ports. Together, these 16 physical ports provide a total of 24 Fibre Channel ports with link speeds of 8, 16, 32, and
64Gb/s.
–8G requires a 32G optical transceiver
•16 1/10/25GbE ports, compatible with short reach (SR) and long reach (LR) SFP/SFP+ transceivers
–1G speed is not supported for LR. The only optic that supports 1G speed is the 10GbE SR optic.
–The 25GbE LR optic supports both 25G and 10G speeds.
–40GbE is supported through 4x 10GbE breakout using the SFP Ethernet ports. We do not support 40GbE interfaces
on the Brocade 7850 Extension Switch; however, we do support connecting to 40GbE ports on core routers or WAN
routers. The 40GbE port is connected at the core router or WAN router end, with breakout to 4x 10GbE interfaces
on the Brocade 7850 Extension Switch.
•Two 100GbE ports, compatible with short reach (SR) QSFP transceivers
NOTE
The SFPs and QSFPs are hot-swappable.
•One RJ-45 Ethernet management port with 1000-Mb/s autonegotiating capability
•One USB port that provides storage for firmware updates, output of the supportSave command, and storage for
configuration uploads and downloads
•Two redundant, hot-swappable 650W AC/DC power supply units (PSUs)
•Six nonport-side intake fan FRUs
DANGER
Batteries that are used for RTC/NVRAM backup are not in operator-access areas. There is a risk of
explosion if a battery is replaced by an incorrect type. Dispose of used components containing batteries
according to the local ordinance and regulations.
Brocade 7850 Extension Switch Configurations
The Brocade 7850 Extension Switch has two product configurations, Open Systems and Mainframe/FICON, which ship
with all ports enabled and full bandwidth.
The Brocade 7850 Extension Switch provides the following configurations:
Open Systems SKU Mainframe/FICON SKU
FC Ports 24x 8/16/32/64G 24x 8/16/32/64G
Ethernet Ports 16x 1/10/25GbE 16x 1/10/25GbE
QSFP Ports 2x 100GbE 2x 100GbE
Optics SFP SWLs SFP LWLs
Factory-loaded Functionality Enterprise Bundle Enterprise Bundle
FICON CUP
Advanced Accelerator for FICON
7850-Install-IG101
9
7850-Install-IG101 Installation Guide Brocade® 7850 Extension Switch Hardware Installation Guide
NOTE
•8G requires a 32G optical transceiver.
•ELWL requires a 64G ELWL Fibre Channel optical transceiver.
•40GbE is supported through 4x 10GbE breakout using the SFP Ethernet ports. Where the 40GbE ports are
on the core router or WAN router and the 4x 10GbE breakout is on the Brocade 7850 Extension Switch.
Port-Side View of the Device
The following figure shows the port-side view of the Brocade 7850 Extension Switch.
Figure 1: Port-Side View
1. System Power LED
2. System Status LED
3. USB Port for Service
4. UART RJ-45 Serial Console Port
5. Management Ethernet Port
6. 8 SFP-DD FC ports (FC Ports 0–15)
7. 8 SFP+ FC ports (FC Ports 16–23)
8. 16 1/10/25G Ethernet ports (GbE Ports 0–15)
9. 2 100G Ethernet QSFP ports (GbE Ports 16–17)
7850-Install-IG101
10
