Unpack the machine and check the components

NOTE:

•Manuals in Spanish for this model are available on the Brother Solutions Center.

(USA only): solutions.brother.com/manuals

Los manuales en español de este modelo están disponibles en el Brother

Solutions Center. (Solamente en los Estados Unidos):

solutions.brother.com/manuals

•The available connection interfaces vary depending on the model.

•You must purchase the correct interface cable for the interface you want to use.

USB cable

We recommend using a USB 2.0 cable (Type A/B) that is no more than

6 feet (2 meters) long.

Network cable

Use a straight-through Category 5 (or greater) twisted-pair cable.

•The illustrations in this Quick Setup Guide show the MFC-L6800DW.

Remove the packing materials and install the drum unit and toner cartridge assembly

Load paper in the paper tray

Connect the power cord and turn on the

machine

Select your language

(if needed)

Drum Unit and Toner

Cartridge Assembly

(pre-installed)

AC Power Cord Telephone Line Cord

(For MFC models)

Quick Setup Guide Product Safety Guide Basic User's Guide

(only for certain models)

Installation CD‑ROM

1. On the machine’s Touchscreen, press

[Settings] > [All Settings] >

[Initial Setup] >

[Local Language].

2. Press your language.

3. Press .

Adjust the paper

guides.

Back Front

Discard the

silica gel pack.

Remove the orange part.

Connect the telephone line cord

(for MFC models only)

If you do not plan to use the fax feature on this machine, go to step .

Configure the machine for faxing (for MFC models only)

If you do not plan to use the fax feature on this machine, go to step .

A. Set the date and time

Press [Settings] >

[All Settings] >

[Initial Setup] >

[Date & Time].

Date

1. Press [Date].

2. Enter the last two digits for the

year using the Touchscreen,

and then press [OK].

3. Enter the two digits for the

month using the Touchscreen,

and then press [OK].

4. Enter the two digits for the day

using the Touchscreen, and

then press [OK].

Clock Type

1. Press [Clock Type].

2. Press [12h Clock] or

[24h Clock].

Time

1. Press [Time].

2. Enter the time using the

Touchscreen.

12h Clock only

Press [AM/PM] to

select [AM] or [PM].

3. Press [OK].

4. Press .

B. Set the Station ID

Press [Settings] > [All Settings] >

[Initial Setup] > [Station ID].

Fax number

1. Press [Fax].

2. Enter your fax number (up to 20 digits) using

the Touchscreen, and then press [OK].

Telephone number

1. Press [Tel].

2. Enter your telephone number (up to 20 digits)

using the Touchscreen, and then press [OK].

Name

1. Press [Name].

2. Enter your name (up to 20 characters) using

the Touchscreen, and then press [OK].

3. Press .

Quick Setup Guide

DCP‑L5500DN / DCP‑L5600DN / DCP‑L5650DN /

MFC‑L5700DW / MFC‑L5800DW / MFC‑L5850DW /

MFC‑L5900DW / MFC‑L6700DW / MFC‑L6800DW

Read the Product Safety Guide first, then read this Quick

Setup Guide for the correct installation procedure.

Not all models are available in all countries.

The latest manuals are available at the Brother Solutions

Center: solutions.brother.com/manuals.

Watch our Video FAQs for

help with setting up your

Brother machine:

solutions.brother.com/videos.

D01GT2001-00

USA/CAN

Version C

Finish

Connect your machine and install software

Macintosh/Windows®computer without CD‑ROM drive

Download the full driver and software package from

the Brother Solutions Center.

(Macintosh) solutions.brother.com/mac

(Windows®) solutions.brother.com/windows

Finish

Follow the on-screen instructions

to continue installation.

Print and scan using your mobile device

If using a wireless network connection:

When the Wireless Device Setup screen

appears, select Setup without a USB cable

(Recommended).

NOTE:

•When finished, restart your computer.

•If connection is unsuccessful, see Cannot set up

your machine? below.

Download “Brother iPrint&Scan” to start using your machine with mobile devices.

solutions.brother.com/ips

NOTE:

If the Brother screen does not appear automatically,

click (Start) > Computer (My Computer).

(For Windows®8: click the (File Explorer) icon

on the taskbar, and then go to Computer (This

PC).)

Double-click the CD-ROM icon, and then

double-click start.exe.

Windows®computer with CD‑ROM drive

Choose your Connection Type:

AirPrint is available for OS X and iOS users.

For more information, see the AirPrint Guide on your model’s

Manuals web page.

solutions.brother.com/manuals

Follow the on-screen instructions

to continue installation.

When instructed, go to your machine’s LCD. Follow the on-screen instructions

to continue installation.

Before printing from your mobile device, your machine must be configured according to step or Alternate wireless configuration method (Setup Wizard).

NOTE:

If the LCD screen is blank, press to wake up the device.

Alternate wireless configuration method (Setup Wizard)

Press > [Setup Wizard] > [Yes].Select the SSID.

Enter the Network key.

To use with your computer, follow Step until the Select Machine

screen appears, listing all machines in your network.

If you cannot find this information, ask your network

administrator or wireless access point/router

manufacturer.

The LCD displays

[Connected].

Find your

SSID: XXXXXXX

Network key: XXXX

To use with your mobile device, go to Print and scan using your mobile device.

Follow the on-screen instructions

to continue installation.

Select your machine. Finish

NOTE:

•When finished, restart your computer.

•If connection is unsuccessful, see Cannot set up

your machine? below.

Restart your wireless access point/router.

Cannot set up your machine?

Wired network

USB

Wireless network

Disconnect the cable. Restart your machine,

computer and/or mobile

device.

Repeat .

Go to Alternate wireless

configuration method (Setup Wizard).

NOTE:

If you repeat these steps and connection is still unsuccessful, please visit the Brother Solutions Center at: http://support.brother.com.

a. Press the WiFi icon on

the LCD.

b. Press [WLAN

Assistant].

Brother regularly updates firmware to add features and fix identified problems.

To check for the latest firmware, visit solutions.brother.com/up1.

For Network Users: Important Notice for Network Security

The default Web Based Management password is located on the back of the machine and marked “Pwd”.

We recommend immediately changing the default password to use network tools/utilities securely and to

protect your machine from unauthorized access.

Brother support website http://support.brother.com
