Brother MFC-7360N Bedienungsanleitung

User’s Guide

PANTONE2728

Advanced User’s Guide

Safety and Legal

Basic User’s Guide

Version 0

USA/CAN

Please read this booklet before attempting to operate the product, or before attempting any

maintenance. Failure to follow these instructions may result in an increased risk of personal injury

or damage to property, including through fire, electrical shock, burns or suffocation.

Symbols and

conventions used in

the documentation A

The following symbols and conventions are

used throughout the documentation.

Follow all warnings and instructions marked

on the product.

Note

The illustrations in this guide show the

HL-2240D and MFC-7860DW.

Safety and Legal A

(HL-2220 / HL-2230 / HL-2240 / HL-2240D /HL-2270DW / DCP-7060D /

DCP-7065DN / HL-2280DW / MFC-7360N / MFC-7460DN / MFC-7860DW)

Bold Bold typeface identifies specific

keys on the product’s control

panel, on the computer screen.

Italics Italicized typeface emphasizes

an important point or refers you

to a related topic.

Courier

New

Text in Courier New font

identifies messages on the

LCD of the product.

WARNING indicates a potentially

hazardous situation which, if not avoided,

could result in death or serious injuries.

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injuries.

IMPORTANT indicates a potentially

hazardous situation which, if not avoided,

may result in damage to property or loss of

product functionality.

WARNING

CAUTION

IMPORTANT

Notes tell you how you should

respond to a situation that may arise

or give tips about how the operation

works with other features.

Electrical Hazard icons alert you to

possible electrical shock.

Improper Setup icons alert you to

devices and operations that are not

compatible with the product.

Hot Surface icons warn you not to

touch product parts that are hot.

Compilation and Publication A

Under the supervision of Brother Industries, Ltd., this manual has been compiled and published,

covering the latest product descriptions and specifications.

The contents of this manual and the specifications of this product are subject to change without

notice.

Brother reserves the right to make changes without notice in the specifications and materials

contained herein and shall not be responsible for any damages (including consequential) caused

by reliance on the materials presented, including but not limited to typographical and other errors

relating to the publication.

Choosing a location A

Put your product on a flat, level, stable surface that is free of vibration and shocks, such as a desk.

Put the product near a telephone wall jack and a standard grounded AC power outlet. Choose a

location where the temperature remains between 50F and 90.5F (10C and 32.5C) and the

humidity is between 20% to 80% (without condensation).

WARNING

DO NOT expose the product to direct sunlight, excessive heat, open flames, corrosive gasses,

moisture or dust. Doing so may create a risk of an electrical short or fire. It may also damage

the product and/or render it inoperable.

DO NOT place the product near heaters, air conditioners, electrical fan, refrigerators, or water.

Doing so may create the risk of a short circuit or fire, should water come into contact with the

product (including condensation caused by heating/air conditioning/ventilation equipment).

DO NOT place the product near chemicals. Should the chemicals come into contact with the

product, there may be a risk of fire. The chemicals may also cause the product to malfunction

or become discolored.

DO NOT put the product in a location where any slot or opening in the product is obstructed or

blocked. These slots and openings are provided for ventilation. Blocking the product’s

ventilation could create a risk of overheating and/or fire.

Instead:

• Keep a gap of roughly 4 in. (100 mm) between the ventilation hole and the wall.

• Place the product on a solid surface, never on a bed, sofa, rug, or other similar soft surface.

• DO NOT place this product near or over a radiator or heater.

• DO NOT place this product in a “built-in” installation unless adequate ventilation is provided.

DO NOT put objects on top of the product. Doing so could increase the risk of overheating

and/or fire should the product malfunction.

DO install your product near an AC power outlet that is easily accessible. In the event of an

emergency, easy access to the plug and outlet will allow you to shut off power to the product

quickly and completely.

Plastic bags are used in the packing of your product and drum unit. Plastic bags are not toys.

To avoid the danger of suffocation, keep these bags away from babies and children and dispose

of them properly.

(MFC only)

To reduce the risk of shock or fire, use only a No. 26 AWG or larger telecommunication line cord.

(MFC only)

Use caution when installing or modifying telephone lines. Never touch telephone wires or

terminals that are not insulated unless the telephone line has been unplugged at the wall jack.

Never install telephone wiring during a lightning storm. Never install a telephone wall jack in a

wet location.

CAUTION

Avoid placing your product in a high-traffic area. If you must place it in a high-traffic area, ensure

that the product is in a safe location where it cannot be accidentally knocked-over, which could

cause injury to you and serious damage to the product. Also ensure that cords are secured so

as not to pose a tripping hazard. DO NOT place this product on an unstable cart, stand, or table.

The product is heavy and may fall, causing injury to you, and serious damage to the product.

DO NOT eat the Silica Pack. Please discard. If ingested seek medical attention immediately.

IMPORTANT

• DO NOT place your product next to devices that contain magnets or generate magnetic fields.

Doing so may interfere with the operation of the product, causing print quality problems.

• DO NOT place your product next to sources of interference, such as speakers or the base units

of non Brother cordless telephones. Doing so may interfere with the operation of the product’s

electronic components.

• DO NOT connect your product to an AC power outlet controlled by wall switches or automatic

timers. Disruption of power can delete information from the product’s memory.

• DO NOT connect your product to an AC power outlet on the same circuit as large appliances

or other equipment that requires a significant amount of electricity to operate. Operating this

product in conjunction with the other product(s) could create an overvoltage, tripping your

circuit breaker or blowing your fuse.

To use the product safely A

Please keep these instructions for later reference and read them before attempting any

maintenance. If you do not follow these safety instructions, there is a possibility of a fire, electrical

shock, burn or suffocation.

WARNING

ELECTRICAL HAZARDS

Failure to follow the warnings in this section may create the risk of an electrical shock. In

addition, you could create an electrical short, which may create the risk of a fire.

There are high voltage electrodes inside the product. Before you access the inside of the

product, including for routine maintenance such as cleaning, make sure you have unplugged the

telephone line cord first (MFC only) and then the power cord from the AC power outlet, as well

as any telephone (RJ-11) or Ethernet (RJ-45) cables (network model only) from the product.

Never push objects of any kind into this product through cabinet slots, since they may touch

dangerous voltage points or short out parts.

DO NOT handle the plug with wet hands.

Always make sure the plug is fully inserted. DO NOT use the product or handle the cord if the

cord has become worn or frayed.

DO NOT use this product during an electrical storm.

DO NOT allow this product to come into contact with water. This product should not be used

around standing water including a bathtub, sink, or swimming pool, around appliances

containing water including a refrigerator, or in a wet basement.

This product should be connected to an AC power source within the range indicated on the

rating label. DO NOT connect it to a DC power source or inverter. If you are not sure what kind

of power source you have, contact a qualified electrician.

Always disconnect all cables from the wall outlet before servicing, modifying or installing the

equipment.

Power Cord Safety:

• This product is equipped with a 3-wire grounded plug. This plug will only fit into a grounded

power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, call

your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded

plug.

• Use only the power cord supplied with this product.

• DO NOT allow anything to rest on the power cord. DO NOT place this product where people

can walk on the cord. DO NOT place this product in a position where the cord is stretched or

strain is otherwise put on the cord. Doing so may cause the cord to become worn or fray.

• If an extension cord is used with this product, make sure that the total ampere ratings on the

products plugged into the extension cord. DO NOT exceed the extension cord ampere rating.

Also, make sure that the total of all products plugged into the AC power outlet does not

exceed 15 amperes.

• The power cord, including extensions, should be no longer than 16.5 feet (5 meters).

FIRE HAZARDS

DO NOT use flammable substances, any type of spray, or an organic solvent/liquid that

containing alcohol or ammonia to clean the inside or outside of the product. Doing so could

cause a fire. Instead, use only a dry, lint-free cloth. See Routine Maintenance in the User's

Guide/Advanced User's Guide for more information on how to clean the product.

DO NOT attempt to operate this product with a paper jam or with stray pieces of paper inside

the product. Prolonged contact of the paper with the drum unit could cause a fire.

DO NOT use a vacuum cleaner to clean up scattered toner. Doing this might cause the toner

dust to ignite inside the vacuum cleaner, potentially starting a fire. Please carefully clean the

toner dust with a dry, lint-free soft cloth and dispose of it according to local regulations.

DO NOT use this product in the vicinity of a gas leak or combustible dust.

(MFC only)

When using your telephone equipment, basic safety precautions should always be followed to

reduce the risk of fire, electrical shock and injury to people, including the following:

1 DO NOT use this product near water, for example, near a bath tub, wash bowl, kitchen sink

or washing product, in a wet basement or near a swimming pool.

2 Avoid using this product during an electrical storm. There may be a remote risk of electric

shock from lightning.

3 DO NOT use this product to report a gas leak in the vicinity of the leak.

4 Use only the power cord provided with the product.

SAVE THESE INSTRUCTIONS

HOT SURFACE

After you have just used the product, some internal parts will be extremely hot. To prevent injury,

DO NOT touch the shaded parts shown in the illustration, when you open the front or back cover

(back output tray).

CAUTION

(MFC and DCP only)

When you move the machine, grasp the side handholds that are under the scanner. DO NOT

carry the machine by holding it at the bottom.

Inside the product

(Front View)

Inside the product

(Front View)

Inside the product

(Back View)

(MFC and DCP only)

DO NOT put your hands on the edge of the product under the scanner as shown in the

illustrations. Doing this may cause injury to your fingers by pinching them.

(MFC and DCP only)

DO NOT put your fingers in the areas shown in the illustrations. Doing this may cause injury to

your fingers by pinching them.
