User’s Guide

PANTONE2728

Advanced User’s Guide

Safety and Legal

Basic User’s Guide

Using the

documentation 1

Please read this booklet before attempting to

operate the machine, or before attempting

any maintenance. Failure to follow these

instructions may result in an increased risk of

personal injury or damage to property,

including through fire, electrical shock, burns

or suffocation.

Read all of the instructions. Save them for

later reference.

Symbols and conventions

used in the documentation 1

The following symbols and conventions are

used throughout the documentation.

Follow all warnings and instructions marked

on the machine.

Note

The illustrations in this guide show the

MFC-J6710DW.

Safety and Legal 1

MFC-J6510DW/J6710DW

Bold Bold typeface identifies specific

keys on the machine’s control

panel, on the computer screen.

Italics Italicized typeface emphasizes

an important point or refers you

to a related topic.

Courier

New

Text in Courier New font

identifies messages on the

LCD of the machine.

WARNING

WARNING indicates a potentially

hazardous situation which, if not avoided,

could result in death or serious injuries.

CAUTION

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injuries.

IMPORTANT

IMPORTANT indicates a potentially

hazardous situation which, if not avoided,

may result in damage to property or loss of

product functionality.

Notes tell you how you should

respond to a situation that may arise

or give tips about how the operation

works with other features.

Electrical Hazard icons alert you to

possible electrical shock.

Improper Setup icons alert you to

devices and operations that are not

compatible with the machine.

Fire Hazard icons alert you to the

possibility of fire.

Version 0

USA/CAN

Compilation and Publication 1

Under the supervision of Brother Industries, Ltd., this manual has been compiled and published,

covering the latest product descriptions and specifications.

The contents of this manual and the specifications of this product are subject to change without

notice.

Brother reserves the right to make changes without notice in the specifications and materials

contained herein and shall not be responsible for any damages (including consequential) caused

by reliance on the materials presented, including but not limited to typographical and other errors

relating to the publication.

Choosing a location 1

Put your machine on a flat, level, stable surface that is free of vibration and shocks, such as a

desk. Put the machine near a telephone wall jack and a standard AC power outlet. Choose a

location where the temperature remains between 50°F and 95°F (10°C and 35°C) and the

humidity is between 20% to 80% (without condensation).

WARNING

DO NOT expose the machine to direct sunlight, excessive heat, open flames, salty or corrosive

gasses, moisture or dust. DO NOT place your machine on a carpet or rug, as this will expose it

to dust. Doing so may create a risk of an electrical short or fire. It may also damage the machine

and/or render it inoperable.

DO NOT place the machine near heaters, air conditioners, electrical fan, refrigerators, or water.

Doing so may create the risk of a short circuit or fire should water come into contact with the

machine (including condensation caused by heating/air conditioning/ventilation equipment).

DO NOT place the machine near chemicals. Should the chemicals come into contact with the

machine, there may be a risk of fire. The chemicals may also cause the machine to malfunction

or become discolored.

Plastic bags are used in the packing of your machine. Plastic bags are not toys. To avoid the

danger of suffocation, keep these bags away from babies and children and dispose of them

properly.

CAUTION

Avoid placing your machine in a high-traffic area. If you must place it in a high-traffic area,

ensure that the machine is in a safe location where it cannot be accidentally knocked-over,

which could cause injury to you and serious damage to the machine.

Ensure that cables and cords leading to the machine are secured so as not to pose a tripping

hazard.

DO NOT place this machine on an unstable or tilted cart, stand, or table. The machine is heavy

and may fall, causing injury to you and serious damage to the machine.

IMPORTANT

• DO NOT place your machine next to sources of interference, such as speakers or the base

units of non Brother cordless telephones. Doing so may interfere with the operation of the

machine's electronic components.

• DO NOT place the machine on any tilted/slanted surface. DO NOT tip the machine after the

ink cartridges are installed. Doing so may cause ink spillage and internal damage to the

machine.

• DO NOT connect your machine to an AC power outlet controlled by wall switches or automatic

timers. Disruption of power can delete information from the machine's memory, and repeated

cycling of the power can damage the machine.

To use the machine safely 1

WARNING

ELECTRICAL HAZARDS

Failure to follow the warnings in this section may create the risk of an electrical shock. In

addition, you could create an electrical short, which may create the risk of a fire.

There are high-voltage electrodes inside the machine. Before you access the inside of the

machine, including for routine maintenance such as cleaning, make sure you have unplugged

the power cord from the AC power outlet, as well as any telephone (RJ-11) or Ethernet (RJ-45)

cables from the machine.

DO NOT push objects of any kind into this machine through slots or openings in the cabinet, as

they may touch dangerous voltage points or short out parts.

DO NOT handle the plug with wet hands.

Always make sure the plug is fully inserted.

DO NOT use the machine or handle the cord if the cord has become worn or frayed. If

unplugging your machine, DO NOT touch the damaged/frayed part.

DO NOT continue using the machine if it has been dropped or the cabinet has been damaged.

Instead, unplug the machine from the power outlet and contact Brother Authorized Service

Personnel.

If water, other liquids, or metal objects get inside the machine, immediately unplug the machine

from the AC power outlet and contact Brother Authorized Service Personnel.

DO NOT connect it to a DC power source or inverter. If you are not sure what kind of power

source you have, contact a qualified electrician.

Power Cord Safety:

• DO NOT pull on the middle of the AC power cord; pulling on the middle may cause the cord

to separate from the plug. Doing this might cause an electrical shock.

• DO NOT allow anything to rest on the power cord.

• DO NOT place this machine where people can walk on the cord.

• DO NOT place this machine in a position where the cord is stretched or strain is otherwise

put on the cord, as it may become worn or fray.

• If an extension cord is used with this machine, make sure that the total ampere ratings on

the machines plugged into the extension cord DO NOT exceed the extension cord ampere

rating. Also, make sure that the total of all machines plugged into the AC power outlet does

not exceed 15 amperes (USA only).

Never touch telephone wires or terminals that are not insulated unless the telephone line has

been unplugged at the wall jack. Never install telephone wiring during a lightning storm. Never

install a telephone wall jack in a wet location.

FIRE HAZARDS

Failure to follow the warnings in this section may create the risk of a fire.

DO NOT use flammable substances, any type of spray or an organic solvent/liquid that contains

alcohol or ammonia to clean the inside or outside of the machine. Doing this may also cause an

electrical shock.

DO NOT use this product in the vicinity of combustible dust.

CAUTION

DO NOT sit or stand on the machine or use it for any purpose beyond its intended purpose.

If the machine becomes hot, releases smoke, or generates any strong smells, immediately

unplug the machine from the AC power outlet. Call Brother Customer Service.

Wait until pages have exited the machine before picking them up. Doing this may cause injury

to your fingers by trapping them in a roller.

DO NOT put your hands on the edge of the machine. Doing this may cause injury to your fingers

by pinching them.

DO NOT touch the area shaded in the illustration. Doing this may cause injury to your fingers by

cutting them on the edge of the machine.

DO NOT carry the machine by holding the scanner cover or the Jam Clear Cover. Doing this

may cause the machine to slip out of your hands. Only carry the machine by placing your hands

under the entire machine.

(MFC-J6710DW)

To prevent injuries when moving or lifting this machine, make sure to use at least two people.

Be careful not to pinch your fingers when you set the machine back down.

(MFC-J6510DW) 1

IMPORTANT

• Disruption of power can wipe out information in the machine's memory.

• DO NOT put objects on top of the machine.

• DO NOT place anything in front of the machine that will block received faxes. DO NOT place

anything in the path of received faxes.

• If the machine does not operate normally when the operating instructions are followed, adjust

only those controls that are covered by the operating instructions. Improper adjustment of other

controls may result in damage or minor exposure to electromagnetic waves and will often

require extensive work by a qualified technician to restore the machine to normal operation.

• A distinct change in the machine’s performance may, indicate a need for service.

• The power cord, including extensions, should be no longer than 16.5 feet (5 meters).

DO NOT connect your machine to an AC power outlet on the same circuit as large appliances

or other equipment that requires a significant amount of electricity to operate. Doing this may

cause an overvoltage, tripping your circuit breaker or blowing your fuse. If you cannot avoid

using the machine with these appliances, we recommend that you use a voltage transformer

or a high-frequency noise filter. Use a voltage regulator if the power source is not stable.

• Lightning and power surges can damage this machine. We recommend that you use a quality

surge protection device on the AC power line and any telephone (RJ-11) or Ethernet (RJ-45)

cable plugged into the machine, or that you unplug the cords during a lightning storm.

Important safety instructions 1

1 DO NOT attempt to service this machine yourself because opening or removing covers may

expose you to dangerous voltage points and other risks and may void your warranty. Refer all

servicing to a Brother Authorized Service Center. For the location of your nearest Brother

Authorized Service Center, please call:

In USA: 1-877-BROTHER (1-877-276-8437)

In Canada: 1-877-BROTHER

2 Unplug this machine from the power outlet and refer all servicing to Brother Authorized Service

Personnel under the following conditions:

When the power cord is damaged or frayed.

If liquid has been spilled into the machine.

If the machine has been exposed to rain or water.

Regulation 1

WARNING

When using your telephone equipment, basic safety precautions should always be followed to

reduce the risk of fire, electrical shock and injury to people, including the following:

• DO NOT use this product near water, for example, near a bath tub, wash bowl, kitchen sink

or washing machine, in a wet basement or near a swimming pool.

• Avoid using this product during an electrical storm. There may be a remote risk of electric

shock from lightning.

• DO NOT use this product to report a gas leak in the vicinity of the leak.

To reduce the risk of fire, electrical shock and injury to people;

• Use only a No. 26 AWG or larger telecommunication line cord.

This product must be installed near an AC power outlet that is easily accessible. In case of an

emergency, you must unplug the power cord from the AC power outlet to shut off the power

completely.

Standard telephone and FCC notices 1

These notices are in effect on models sold and used in the United States only.

When programming emergency numbers or making test calls to emergency numbers:

Remain on the line and briefly explain to the dispatcher the reason for the call before hanging

up.

Perform these activities in the off-peak hours, such as early morning or late evening.

This equipment complies with Part 68 of the FCC rules and the requirements adopted by the

ACTA. On the backside of this equipment is a label that contains, among other information, a

product identifier in the format US: AAAEQ##TXXXX. If requested, this number must be provided

to the telephone company.

You may safely connect this equipment to the telephone line by means of a standard modular jack,

USOC RJ11C.

A plug and jack used to connect this equipment to the premises wiring and telephone network

must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA.

A compliant telephone cord and modular plug is provided with this product. It is designed to be

connected to a compatible modular jack that is also compliant. See installation instructions for

details.

Andere Handbücher für MFC-J6510DW

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Brother Multifunktionsdrucker Handbücher

Brother

Brother MFC 990cw - Color Inkjet - All-in-One Kurzanleitung

Brother

Brother DCP-115C Bedienungsanleitung

Brother

Brother MFC-J4310DW Bedienungsanleitung

Brother

Brother DCP-9010CN Bedienungsanleitung

Brother

Brother DCP-J125 Bedienungsanleitung

Brother

Brother MFC-210C Bedienungsanleitung

Brother

Brother DCP-9010CN Montageanleitung

Brother

Brother DCP-375CW Kurzanleitung

Brother

Brother MFC 6490CW - Color Inkjet - All-in-One Bedienungsanleitung

Brother

Brother MFC-J625DW Programmierhandbuch

Brother

Brother HL-L2300D Betriebsanleitung

Brother

Brother MFC-J425W Sicherheitsleitfaden

Brother

Brother MFC-7360N Bedienungsanleitung

Brother

Brother MFC 3360C - Color Inkjet - All-in-One Bedienungsanleitung

Brother

Brother DCP-8080DN Sicherheitsleitfaden

Brother

Brother MFC-J4410DW Bedienungsanleitung

Brother

Brother DCP 8060 Sicherheitsleitfaden

Brother

Brother MFC-8640D Bedienungsanleitung

Brother

Brother 4820c - MFC Color Inkjet Bedienungsanleitung

Brother

Brother DCP-J125 Bedienungsanleitung

Brother

Brother MFC-J245 Bedienungsanleitung

Brother

Brother MFC-760 Bedienungsanleitung

Brother

Brother MFC-J5730DW Bedienungsanleitung

Brother

Brother MFC-9330CDW Bedienungs- und Wartungshandbuch

Beliebte Multifunktionsdrucker Handbücher anderer Marken

Triumph Adler

Triumph Adler DC 2016 Handbuch

Epson

Epson WorkForce WF-2510 Benutzerhandbuch

Epson

Epson Stylus Scan 2000 Installations- und Betriebshandbuch

Epson

Epson PictureMate Snap PM 240 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub C35 Bedienungsanleitung

Konica Minolta

Konica Minolta BIZHUB 558 Bedienungsanleitung

Lexmark

Lexmark MX710 Series Handbuch

Lexmark

Lexmark XC8155 Bedienungsanleitung

Lexmark

Lexmark X642E Bedienungsanleitung

Sharp

Sharp MX-2310U Leitfaden

Aficio

Aficio 200 Bedienungsanleitung

Canon

Canon ImageCLASS 2300 Handbuch

Ricoh

Ricoh Pro C900 Bedienungsanleitung

Lexmark

Lexmark X925 Bedienungsanleitung

Epson

Epson Stylus CX8400 Series Bedienungsanleitung

Oce

Oce VarioLink 5022 Bedienungsanleitung

Copystar

Copystar CS 4551ci Bedienungsanleitung

Konica Minolta

Konica Minolta Magicolor 4650EN Bedienungsanleitung
