ADVANCED

USER’S GUIDE

DCP-J515W

DCP-J715W

Version 0

UK/IRE/GEN

User's Guides and where do I find it?

Which manual? What's in it? Where is it?

Safety and Legal Please read the Safety Instructions before you

set up your machine.

Printed / In the box

Quick Setup Guide Read this Guide first. Follow the instructions for

setting up your machine and installing the

drivers and software for the operating system

and connection type you are using.

Printed / In the box

Basic User's Guide Learn the basic Copy, Scan and PhotoCapture

Center™ operations and how to replace

consumables. See troubleshooting tips.

Printed / In the box

Advanced User's Guide Learn more advanced operations: Copy,

printing reports and performing routine

maintenance.

PDF file /

Documentation

CD-ROM

Software User's Guide Follow these instructions for Printing, Scanning,

Network Scanning, PhotoCapture Center™,

and using the Brother ControlCenter utility.

PDF file /

Documentation

CD-ROM

Network User's Guide This Guide provides more advanced

information for configuring the Ethernet and

Wireless network connections. In addition, find

information about network utilities, network

printing, troubleshooting tips and supported

network specifications.

PDF file /

Documentation

CD-ROM

Table of Contents

1 General setup 1

Memory storage.....................................................................................................1

Sleep Mode ...........................................................................................................1

LCD display ...........................................................................................................2

Changing LCD language .................................................................................2

Setting the Dim Timer for the backlight ...........................................................2

2 Printing reports 3

Reports ..................................................................................................................3

How to print a report ........................................................................................3

3 Making copies 4

Copy settings .........................................................................................................4

Stop copying.................................................................................................... 4

Changing copy speed and quality ...................................................................4

Enlarging or reducing the copied image..........................................................5

Making N in 1 copies or a poster (Page Layout) .............................................6

Sorting copies using the ADF (DCP-J715W only) ...........................................7

Adjusting Density.............................................................................................7

Ink Save Mode.................................................................................................8

Book Copy .......................................................................................................9

Watermark Copy..............................................................................................9

Setting your changes as a new default..........................................................11

Restoring all settings to the factory settings .................................................. 11

4 Printing photos from a memory card or

USB Flash memory drive 12

PhotoCapture Center™ operations .....................................................................12

Memory cards or a USB Flash memory drive folder structure.......................12

Movie printing ................................................................................................ 13

Print Images......................................................................................................... 13

Print Index (Thumbnails) ...............................................................................13

Printing Photos .............................................................................................. 14

Print All Photos .............................................................................................. 14

Enhance Photos ............................................................................................15

Search by Date .............................................................................................. 18

Slide show ..................................................................................................... 18

Trimming........................................................................................................19

DPOF printing................................................................................................ 19

iii

PhotoCapture Center™ print settings.................................................................. 20

Print Quality ................................................................................................... 20

Paper options ................................................................................................20

Adjusting Brightness, Contrast and Colour....................................................21

Cropping ........................................................................................................22

Borderless printing.........................................................................................23

Date Print.......................................................................................................23

Setting your changes as a new default..........................................................23

Restoring all settings to the factory settings ..................................................23

Scan to a memory card or USB Flash memory drive ..........................................24

Auto Crop ......................................................................................................24

How to set a new default ...............................................................................25

How to reset to factory settings .....................................................................25

5 Printing photos from a camera (DCP-J715W only) 26

Printing photos directly from a PictBridge camera...............................................26

PictBridge requirements ................................................................................26

Setting your digital camera ............................................................................26

Printing Images..............................................................................................27

DPOF printing ................................................................................................27

Printing photos directly from a digital camera (without PictBridge)......................28

Printing Images..............................................................................................28

A Routine maintenance 29

Cleaning and checking the machine....................................................................29

Cleaning the outside of the machine .............................................................29

Cleaning the machine’s printer platen ........................................................... 30

Checking the ink volume ...............................................................................30

Packing and shipping the machine ......................................................................31

B Glossary 33

C Index 34

Memory storage 1

Your menu settings are stored permanently,

and in the event of a power failure will not be

lost. If you have chosen Set New Default,

settings in the PHOTO CAPTURE mode will

not be lost. Temporary settings (for example,

Contrast) will be lost.

Sleep Mode 1

You can choose how long the machine must

be idle (from 1 to 60 minutes) before it goes

into sleep mode. The timer will restart if any

operation is carried out on the machine.

aPress Menu.

bPress aor bto choose

General Setup.

Press OK.

cPress aor bto choose Sleep Mode.

dPress dor cto choose 1Min, 2Mins,

3Mins, 5Mins, 10Mins, 30Mins or

60Mins which is the length of time the

machine is idle before entering sleep

mode.

Press OK.

ePress Stop/Exit.

General setup 1

Chapter 1

LCD display 1

Changing LCD language 1

You can change the LCD language.

aPress Menu.

bPress aor bto choose

Initial Setup.

Press OK.

cPress aor bto choose

Local Language.

Press OK.

dPress aor bto choose your language.

Press OK.

ePress Stop/Exit.

Setting the Dim Timer for the

backlight 1

You can set how long the LCD backlight stays

on after you go back to the Ready screen.

aPress Menu.

bPress aor bto choose

General Setup.

Press OK.

cPress aor bto choose LCD Settings.

Press OK.

dPress aor bto choose Dim Timer.

ePress dor cto choose 10Secs,

20Secs, 30Secs or Off.

Press OK.

fPress Stop/Exit.

Reports 2

The following reports are available:

Help List

A help list showing how to program your

machine.

User Settings

Lists your settings.

Network Config

Lists your Network settings.

WLAN Report

Prints a WLAN connection report.

How to print a report 2

aPress Menu.

bPress aor bto choose

Print Reports.

Press OK.

cPress aor bto choose the report you

want.

Press OK.

dPress Mono Start.

ePress Stop/Exit.

Printing reports 2

Copy settings 3

You can change the copy settings temporarily

for multiple copies.

The machine returns to its default settings

after 1 minute.

To change a setting, press aor bto scroll

through the copy settings. When the setting

you want is highlighted, press OK.

When you are finished choosing settings,

press Mono Start or Colour Start.

Note

You can save some of the settings that

you use most often by setting them as

default. These settings will stay until you

change them again. (See Setting your

changes as a new default on page 11.)

Stop copying 3

To stop copying, press Stop/Exit.

Changing copy speed and

quality 3

You can choose the copy quality. The factory

setting is Normal.

aLoad your document.

bEnter the number of copies you want.

cPress aor bto choose Quality.

dPress dor cto choose Fast, Normal or

Best.

Press OK.

eIf you do not want to change additional

settings, press Mono Start or

Colour Start.

Making copies 3

Fast Fast copy speed and lowest

amount of ink used. Use this

setting to save time (documents to

be proof read, large documents or

many copies).

Even if you set this option the copy

speed will be slower with

Ink Save Mode, Book Copy or

Watermark Copy turned on.

Normal Recommended setting for ordinary

print outs. Good copy quality with

adequate copy speed.

Best Use this setting to copy precise

images such as photographs. The

highest resolution and slowest

speed.

Making copies

Enlarging or reducing the

copied image 3

You can choose an enlargement or reduction

ratio. If you choose Fit to Page, your

machine will adjust the size automatically to

the paper size you set.

aLoad your document.

bEnter the number of copies you want.

cPress aor bto choose

Enlarge/Reduce.

dPress dor cto choose 100%, Enlarge,

Reduce, Fit to Page,

Custom(25-400%).

eDo one of the following:

If you choose Enlarge or Reduce

press OK and press dor cto choose

the enlargement or reduction ratio

you want. Press OK and go to

step f.

If you choose Custom(25-400%),

press OK, and then press c.

Press a, b, dor cto select a number,

and then press OK repeatedly until

you complete to enter the number.

Press a, b, dor cto select ,

and press OK.

Go to step f.

If you choose 100% or

Fit to Page, press OK. Go to

step f.

fIf you do not want to change additional

settings, press Mono Start or

Colour Start.

Note

•Page Layout is not available with

Enlarge/Reduce.

•Page Layout, Book Copy, Sort and

Watermark Copy are not available with

Fit to Page.

•Fit to Page does not work properly if

the document on the scanner glass is

skewed by more than 3 degrees. Using

the document guidelines on the left and

top, place your document in the upper left

hand corner, with the document face down

on the scanner glass.

• (DCP-J715W only)

Fit to Page is not available when

using the ADF.

198% 10x15cmiA4

186% 10x15cmiLTR

142% A5iA4

100%

97% LTRiA4

93% A4iLTR

(DCP-J515W)

83%

(DCP-J715W)

83% LGLiA4

69% A4iA5

47% A4i10x15cm

Fit to Page

Custom(25-400%)

Chapter 3

Making N in 1 copies or a

poster (Page Layout) 3

The N in 1 copy feature can help you save

paper by letting you copy two or four pages

onto one printed page.

You can also produce a poster. When you

use the poster feature your machine divides

your document into sections, then enlarges

the sections so you can assemble them into a

poster. If you want to print a poster, use the

scanner glass.

IMPORTANT

• Make sure the paper size is set to A4 or

Letter.

• You cannot use the Enlarge/Reduce

and Stack/Sort settings (DCP-J715W)

with the N in 1 and Poster features.

• If you are producing multiple colour

copies, N in 1 copy is not available.

•(P) means Portrait and (L) means

Landscape.

• You can only make one poster copy at a

time.

Note

Watermark Copy, Book Copy,

Ink Save Mode, Stack/Sort and

Enlarge/Reduce are not available with

Page Layout.

aLoad your document.

bEnter the number of copies you want.

cPress aor bto choose Page Layout.

dPress dor cto choose Off(1 in 1),

2in1(P), 2in1(L),

4in1(P), 4in1(L)or

Poster(3 x 3).

Press OK.

eIf you do not want to change additional

settings, press Mono Start or

Colour Start to scan the page.

If you are making a poster the machine

scans the pages and starts printing.

Go to step f.

If you placed the document in the ADF

(DCP-J715W) or are making a poster,

the machine scans the pages and starts

printing.

If you are using the scanner glass, go

to step f.

fAfter the machine scans the page, press

+(Yes) to scan the next page.

gPlace the next page on the scanner

glass.

Press OK.

Repeat steps fand gfor each page of

the layout.

hAfter all the pages have been scanned,

press -(No) to finish.

Note

If photo paper has been chosen in the

Paper Type setting for N in 1 copies, the

machine will print the images as if plain

paper had been chosen.

Andere Handbücher für DCP-J515W

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Brother Drucker Handbücher

Brother

Brother HL-7050 Series Bedienungsanleitung

Brother

Brother HL-1030 Bedienungsanleitung

Brother

Brother DCP-J1200W Technisches Handbuch

Brother

Brother HL-B2000D Bedienungsanleitung

Brother

Brother DCP-155C Bedienungsanleitung

Brother

Brother HL-1650/1670N Bedienungsanleitung

Brother

Brother GT-3 Series Bedienungsanleitung

Brother

Brother MFC-J410 Bedienungs- und Wartungshandbuch

Brother

Brother HL-3400CN Series Bedienungsanleitung

Brother

Brother HL-1070 - B/W Laser Printer Gebrauchs- und Pflegehandbuch

Brother

Brother HL-6050 Bedienungsanleitung

Brother

Brother HL-8050N Bedienungsanleitung

Brother

Brother PocketJet PJ-523 Bedienungsanleitung

Brother

Brother PT-2430PC - P-Touch 2430PC B/W Thermal Transfer... Kurzanleitung

Brother

Brother DCP-T226 Technisches Handbuch

Brother

Brother P-Touch 2300 Bedienungsanleitung

Brother

Brother LASER PRINTER HL-2140 Bedienungsanleitung

Brother

Brother HL 1850 - B/W Laser Printer Bedienungsanleitung

Brother

Brother DCP-L2500D Bedienungsanleitung

Brother

Brother HL-3160CDW Bedienungsanleitung

Brother

Brother HS-5000 - Color Solid Ink Printer Bedienungsanleitung

Brother

Brother PT-E550W Montageanleitung

Brother

Brother TD-2020 Bedienungsanleitung

Brother

Brother MFC 990cw - Color Inkjet - All-in-One Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
