Bryte Study Bedienungsanleitung
Q1
Bryte Study Tablet PC
Bryte Kids Tab
User Manual
Bryte www.brytestore.com
1
Important safety information
Your tablet should be treated with care. The information below has been provided in the interest of safety and will help you to enjoy this product and the benefits it brings for
many
years.
•
Keep the product and all of its part out of the reach of children.
•
This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they
have been given
supervision or instruction concerning the use of the appliance by a person responsible for their safety.
•
Keep it dry, Avoid exposure to precipitation, humidity and liquids which could all affect the product circuitry.
•
DO NOT
leave it in high temperatures as
electronic devices and plastic parts may warp in
heat.
•
DO NOT
leave it in low temperatures as moisture can form inside the product, which may damage the circuit board.
•
DO NOT
block or cover slots, holes or openings on the product by placing on soft furnishings such
as carpets, rugs or beds as these are provided
for functionality and/or
ventilation to ensure safe
operation of the product.
•
DO NOT expose the tablet to direct sunlight.
•
Disconnect your tablet from the mains power
supply during thunderstorms.
•
Avoid any heavy impacts caused by collisions or dropping your tablet as this may damage the product.
•
Where the mains power plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
•
DO NOT store in dusty or dirty areas.
•
DO NOT use harsh chemicals, cleaning solvents or detergents to clean the product. Wipe with a dry soft cloth or tissue paper to clean.
•
DO NOT attempt to open the product. This product does not contain any user serviceable parts. Unauthorized handling of the device may damage it and will void
your warranty.
•
Keep the device away from magnets or magnetic fields.
•
NEVER use the tablet near emergency/ intensive care medical equipment, if you have a pacemaker fitted or during an electrical storm.
•
The underneath and sides of the product may become warm after a long period of use. This is normal.
User Manual
Bryte www.brytestore.com
2
Know your Device
Check the package contents
The package contains:
-1 pcs of Bryte Tablet
-1 x USB Charging Cable
-1 x User Manual
- 1x OTG Cable
Charging your tablet
Your battery has been partially charged by the manufacturer, but you may need to recharge it before you can switch the tablet on for the first time.
Note: It is recommended to charge the battery of the tablet fully before turning on for the first time.
Important: Use only the approved chargers with this tablet .
1. Plug the charger into a wall outlet
2. Connect the charger to your tablet via the Micro-B Type USB connector port.
When the battery is full, disconnect the charger from the tablet, then from the wall outlet.
Note: You don’t need to charge the tablet for specific length of time, and you can use the tablet while it is charging.
Note: If the battery is completely discharged, it may take several minutes before the tablet can be used.
Rechargeable Lithium-Ion battery
Your tablet has an internal Lithium-ion polymer battery which should last the lifetime of the product.
If you suspect that the battery is dead, try charging it several times and follow the steps for charging your tablet.
User Manual
Bryte www.brytestore.com
3
•Do NOT attempt to change the battery yourself.
•CAUTION: Danger of explosion may occur if batteries are incorrectly replaced.
•NEVER use or charge the battery if it appears to be leaking, discolored, deformed or in any way abnormal.
•NEVER expose the battery to any liquid.
•NEVER expose the battery to excessive heat such as direct sunlight or fire.
•NEVER throw batteries in a fire or attempt to open the outer casing.
•Batteries are harmful if swallowed, so keep away from and out of reach of infants and young children.
Getting Started
Turning your tablet On
To turn your tablet on, press and hold the Power/ Sleep button until the power indicator LED turns on and the tablet will begin to power up.
Putting your tablet into Sleep mode
To put your tablet into Sleep mode, press the Power/ Sleep button once. The screen should switch off and your tablet will be in Sleep mode.
To wake the tablet from Sleep mode, press the Power/Sleep button once. The screen should wake up and display the lock-screen.
Turning your tablet Off
To turn your tablet off, press and hold the Power/ Sleep button until you are prompted with the ‘Slide to shut down your PC’ message. Slide and drag your finger
down the screen to begin the shutdown process and turn off your tablet.
Emergency reboot
User Manual
Bryte www.brytestore.com
4
To reboot your tablet if the screen becomes unresponsive, press and hold the Power/Sleep button for 10 seconds until the screen turns off.
Note: Leave the tablet for 15 seconds before trying to reboot the tablet.
Caution: Avoid powering the tablet down by using the emergency reboot where possible. Always try to shut down your tablet using the correct shut down method
to avoid loss or damage to data.
Increasing and decreasing the volume
To increase the volume level on your device, press the Volume up button. Repeatedly press the Volume up button until the desired volume is reached.
To decrease the volume level on your device, press the Volume down button. Repeatedly press the Volume down button until the desired volume is reached.
Using headphones with your tablet
You can connect headphones with a 3.5mm plug (not included) to your tablet. The headphone socket can be found on the top of the device highlighted with .
When you have headphones connected the tablet speaker is switched off and all sound is via the headphones.
Installing a Micro SD card
Your tablet supports Micro SD cards (not included) for additional storage of data and files.
User Manual
Bryte www.brytestore.com
5
Important: Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and may cause corrupt
data stored on the card.
To install a Micro SD memory card:
1. Locate the Micro SD card slot on the tablet.
2. Insert the Micro SD card into the slot with the gold contacts facing down, carefully slide the memory card into the slot, pushing gently until it clicks into place.
Instructions for Use
1. Preparing
1.1 Keys Function Description：
Power button
Short press to sleep/wake up, long press to startup and shutdown.
Volume +(up)
increase the volume
Volume -(down)
decrease the volume
HOME button (home)
Click it in any interface will return to main interface.
Back button(back)
click it in any interface will return to previous menu
Menu button
This button will display in menu interface.
Setting button
display recently browsed history
User Manual
Bryte www.brytestore.com
6
1.2 Startup and Shutdown
Startup Long press POWER key for three seconds, you can enter into startup picture. The system enters into screen lock status, please unlock it.
Shutdown
1．Long press POWER, it will popup shutdown window.
2．Shutdown window contains mute mode, airplane mode, reboot mode and shutdown four options.
3．Click Shutdown is the last step.
1.3 Open and Close of the Screen
Screen will be closed on its own when no operation happens.
1. Screen will be closed on its own if no operation happens for some time to save battery power
2. When screen is open, press POWER key, the screen will be closed immediately.
Open the screen when it is closed.
If the screen is I sleep mode, short press POWER to open the screen. The screen will be locked open it, it will show the picture as below picture, left slide
to unlock and enter into camera, right slide the unlock icon to unlock the screen.
User Manual
Bryte www.brytestore.com
7
2. Status and Reminder
Reminder Icons
When some remind message appears in your reminder window, please click column and slip the screen to open the reminder list. Choose the menu you need,
and confirm the information. Then you can close the reminder window through clicking the column to slide up. Please refer to below status icons:
USB connected
USB debugging connected
Return button
Downloading
Display recently-used application
Home button
Current electric volume
WIFI connected, internet is available
3. Operating Details
User Manual
Bryte www.brytestore.com
8
3.1 Audio Player
In the main menu or desktop, click on the audio player icon into the audio playing.
* When the audio player not in the list of music files, the system open audio player, will automatically load the music files on the card to the playlist (the
machine is supported audio file formats: mp3, wav, midi, wma) . As shown in Figure playlist.
User Manual
Bryte www.brytestore.com
9
Playlist Add songs Loop playing Shuffle playing
Previous Search Pause Next
3.2 Video Player
In the main menu or on the desktop,click on the video icon to enter the video player interface, file storage, depending on your situation, open the
corresponding folder, double-click on your favorite movie to play.
* Support video formats: MKV, AVI, RM, RMVB, MP4, MOV, VOB, DAT, FLV, 3GP
* When there is no file in the video playlist, the system will add the files in the insert card automatically.
* drag the playback progress bar , you can adjust the video's playback progress
* Video Player Button Description
* when the video play you can click button, to clear bookmarks, playback mode, etc.
