Buffalo LinkStation HD-H120LAN Bedienungsanleitung

www.buffalotech.com

Network Storage Center – HD-H120LAN/HD-H160LAN/HD-H250LAN/HD-H300LAN

The 120, 160, 250, 300 GB LinkStation Network Storage Center from Buffalo

Technology offers an easy and economic solution to add 120, 160, 250, 300

GigaBytes of network-attached storage via wired or wireless connections.

Quick and simple installation allows you to instantly store and share your

music, videos, images and other files via a web browser from both PCs

and Macs. Offering a built-in print server, the LinkStation simplifies

network printing, and with two USB 2.0 ports, an additional hard drive

can be added for extra space or backups instantly. Simple setup and

maintenance, versatile usage, and a compact design make the LinkStation

the “must have” solution for storing and sharing files on your home or

small office network.

●●120, 160, 250, 300 GB Network Attached Storage

●●Memeo™Backup Software Included (30-Day Trial)

●●Quick and Easy Installation

●●Compatible with Windows, Mac and Linux Systems

●●Additional Drive Capacity via USB 2.0 Ports

●●Managed Backups over the network or via USB 2.0 to External Storage

●●Built-in Print Server

●●Built-in FTP Server (160, 250 and 300 GB models only)

●●Minimal Power Consumption and Scheduleable Auto-power Off

●●Compact, Aesthetic Design

●●Silent Internal Fan

●●Internal Power Supply

Buffalo

broadband

modem

Printer

DriveStation

USB 2.0 Hard Drive

PC Desktop

with Wireless Adapter

Macintosh

Wireless

Router

Notebook with

Wireless Adapter

LinkStation Network

Storage Center

HD-H120/160/250/300LAN

HD-H120LAN Awards

CNET Top 100 Products, Feb 2005

HD-H160LAN Award

HD-H250LAN Award

HD-H120LAN

HD-H160LAN

HD-H250LAN

HD-H300LAN

HD-HXXXLAN data sheet.qxd 9/29/05 3:05 PM Page 1

LAN Interface

Interface IEEE802.3 /IEEE802.U Standard

(100 BASE-TX /10BASE-T)

Transmission Speed 10/100 Mbps

Transmission Encoding Method 100 BASE-TX:4B5B, MLT-3

10 BASE-T:Manchester coding

Access Method CSMA/CD

Port /Connector RJ-45

Cable 100 BASE-TX:Category 5, 2, 4 UTP

10 BASE-T:Category 3, 4, 5, 2 UTP

Number of Ports 1

Transmission Distance 100 m

USB Interface

Interface USB 2.0

Hi-Speed (HS)

Full-Speed (FS)

Connector USB A

Number of Ports 2

Data Transmission Speed Max.: 480 Mbps (HS Mode)

Max.: 12 Mbps (FS Mode)

Others

Power Consumption 17w

Dimension 2.4 x 6.94 x 7.4 in. (60 x 173.5 x 185 mm)

Weight 3.08 lb. (1.3 Kg) to 4.05 lb. (1.84 Kg)

Operating Environment 5º - 35ºC, 20-80% humidity (non-condensing)

Technical Specifications

Network Storage Center – HD-H120LAN/HD-H160LAN/HD-H250LAN/HD-H300LAN

4030 W. Braker Lane #120

Austin, TX 78759

800-456-9799

www.buffalotech.com

Buffalo Technology (USA), Inc. is a leading

global provider of affordable, easy-to-use,

next-generation wired and wireless network

solutions for the consumer, SOHO and SMB

markets. With its expansion into the U.S.

retail market, Buffalo offers home users a

full suite of wireless home networking

solutions such as its award-winning line of

AirStation 54g products; its 125* High-

Speed Mode™ 802.11g products; and its

versatile line of 802.11a/b/g combo

products. Buffalo completes its offerings

with additional world-class networking

solutions that include memory, storage and

multimedia products – perfectly suited for

any wireless environment.

(USA), Inc. The names and logos of other companies mentioned herein belong to their respective owners.

HD-H120LAN

HD-H160LAN

HD-H250LAN

HD-H300LAN

LinkStation

™

HD-HXXXLAN data sheet.qxd 9/29/05 3:05 PM Page 2
