Buhler Fram King FK372 Programmierhandbuch

Series 1 Rotary Cutter

TABLE OF CONTENTS

DESCRIPTION PAGE

Warranty.....................................................................1

Introduction................................................................2

SAFETY.......................................................................3

Safety................................................................3

General Safety..................................................4

Start Up Safety..................................................4

Operation Safety...............................................4

Transport Safety................................................4

Service & Maintenance Safety..........................5

Storage Safety ..................................................5

Safety Signs......................................................5

Safety Sign Installation......................................5

ASSEMBLY.................................................................7

Assembly Instructions.......................................7

Chain Kit Assembly Instructions........................7

OPERATION ...............................................................8

Operating Instructions.......................................8

Theory of Operation..........................................9

MAINTENANCE ..........................................................10

Service..............................................................10

Bolt Torque .......................................................11

PARTS LISTS

4’ & 5’ Series 1 Rotary Cutter Drawing..............12

4’ & 5’ Series 1 Rotary Cutter Parts List............13

Series 1 Rotary Cutter Chain Kit.......................15

Rotary Cutter PTO Shaft...................................16

Model #410 Series 1

Rotary Cutter Gearbox Drawing.............17

Model #410 Series 1

Rotary Cutter Gearbox Parts List ...........18

Model #510 Rotary Cutter Gearbox Drawing....19

Model #510 Rotary Cutter Gearbox Parts List ..20

SHIPPING KIT AND BUNDLE NUMBERS.................21

Series 1 Rotary Cutter

WARRANTY POLICY

Buhler Manufacturing products are warranted for a period of twelve (12) months (90 days for

commercial application) from original date of purchase, by original purchaser, to be free from

defects in material and workmanship under correct, normal agricultural use and proper

applications.

Buhler Manufacturing’s obligations under this warranty shall be limited to the repair or

exchange, at Buhler Manufacturing’s option, of any Buhler Manufacturing product or part which

proves to be defective as provided. Buhler Manufacturing reserves the right to either inspect

the product at the buyer’s location or have it returned to the factory for inspection.

The above warranty does not extend to goods damaged or subject to accident, abuse or misuse

after shipment from Buhler Manufacturing’s factory, nor to goods altered or repaired by anyone

other than an authorized Buhler Manufacturing representative.

Buhler Manufacturing makes no Express Warranties other than those, which are specifically

described. Any description of goods, including any references and specifications in catalogues,

circulars and other written material published, is for the sole purpose of identifying goods and

shall conform to such descriptions. Any sample or model is for illustrative purposes only and

does not create an Express Warranty that the goods conform to sample or model shown.

The purchaser is solely responsible for determining suitability of goods sold. This warranty is

expressly in lieu of all other warranties expressed or implied. Buhler Manufacturing will in no

event be liable for any incidental or consequential damages whatsoever. Nor for any sum in

excess of the price received for the goods for which liability is claimed.

WARRANTY CLAIMS:

Warranty requests must be prepared on Buhler Manufacturing Warranty Claim Forms with all

requested information properly completed. Warranty Claims must be submitted within a thirty

(30) day period from date of failure repair.

WARRANTY LABOR:

Any labor subject to warranty must be authorized by Buhler Manufacturing. The labor rate for

replacing defective parts, where applicable, will be credited at 100% of the dealer’s posted shop

rate. Defective parts will receive an extra 10% discount to assist with freight or other incidental

costs.

GOVERNMENT LEGISLATION:

Warranty terms and conditions are subject to Provincial or State legislation.

IMPORTANT FACTS:

Buckets and Bucket Tines Carry No Warranty

Bent Spears Carry No Warranty

Snowblower Fan Shafts Carry No Warranty

Mower Blades Carry No Warranty

Portable Auger Parts Have Two (2) Year Warranty

Loader Parts Have Two (2) Year Warranty

IMPORTANT NOTE: This warranty does not apply to rentals

Series 1 Rotary Cutter

INTRODUCTION

The Buhler Farm King Series 1 Rotary cutter available in 48” and 60” and is equipped

with a 3-point hitch. The 3-point hitch is Buhler Quick Hitch compatible so it is easy to

attach and unhook. 3-point hitch models include a single solid rubber training wheel.

Buhler Farm King Rotary Cutters are built tough and made to last. The blades are heat-

treated to enhance rigidity and the heavy-duty gearbox is designed to be rugged and

durable. The access panel on the deck makes it easy to inspect or replace the blades.

An optional chain kit minimizes the possibility of flying debris.

Keep this manual handy for frequent reference. All new operators or owners must

review the manual before using the equipment and at least annually thereafter. Contact

your Buhler Dealer if you need assistance, information, or additional copies of the

manual. Visit our website at www.buhler.com for a complete list of dealers in your area.

The directions left, right, front and rear, as mentioned throughout this manual, are as

seen facing in the direction of travel of the implement.

Series 1 Rotary Cutter

SAFETY

Remember, YOU are the key to safety. Good safety practices not only protect you, but

also the people around you. Make these practices a working part of your safety

program. Be certain that everyone operating this equipment is familiar with the

recommended operating and maintenance procedures and follows all the safety

precautions. Most accidents can be prevented. Do not risk injury or death by ignoring

good safety practices.

The alert symbol is used throughout this manual. It indicates attention is required and

identifies hazards. Follow the recommended precautions.

he safety alert symbol means…

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

CAUTION

The caution symbol indicates a potentially hazardous situation that, if not

avoided, may result in minor or moderate injury. It may also be used to

alert against unsafe practices.

WARNING

The Warning Symbol indicates a potentially hazardous situation that, if

not avoided, could result in death or serious injury, and includes hazards

that are exposed when guards are removed. It may also be used to alert

against unsafe practices.

DANGER

The Danger Symbol indicates an imminently hazardous situation that, if

not avoided will result in death or serious injury. This signal word is to be

limited to the most extreme situations, typically for machine components

that, for functional purposes, cannot be guarded.

Series 1 Rotary Cutter

GENERAL SAFETY INSTRUCTIONS

Have a first-aid kit available for use and know how to use it. Have a fire extinguisher

available, stored in a highly visible location, and know how to use it. Wear appropriate

protective gear. This list may include but is not limited to:

- hard hat

- protective shoes with slip resistant soles

- protective glasses or goggles

- heavy gloves

- wet weather gear

- hearing protection

- respirator or filter mask

Read and understand the Operator’s Manual and all safety signs before operating,

servicing, adjusting, repairing, or unplugging the equipment. Do not attempt any

unauthorized modifications to your Buhler product as this could affect function or safety,

and could affect the life of the equipment. Inspect and clean the working area before

operating. Ensure bystanders are clear of the area before operating.

START UP SAFETY

Do not let inexperienced operators or children run this equipment.

Place all tractor and machine controls in neutral before starting.

Operate only with ROPS and seatbelt equipped tractors.

Do not operate inside a building unless there is adequate ventilation.

Ensure all shields are in place and in good condition before operating.

Stay clear of PTO shaft and machine when engaging PTO.

OPERATION SAFETY

Do not permit riders.

Do not wear loose fitting clothing during operation.

Never operate over 540 rpm PTO speed.

Never operate the equipment in the raised position.

TRANSPORT SAFETY

Review Transport Safety instructions in tractor manual before moving.

Check with local authorities regarding transport on public roads. Obey all applicable

laws and regulations.

Make sure the SMV (Slow Moving Vehicle) emblem and all the lights and reflectors that

are required by the local highway and transport authorities are in place, are clean, and

can be seen clearly by all overtaking and oncoming traffic.

Never have the equipment in operation during transport.

Always travel at a safe speed.

Inflate transport tires to recommended pressure.

Series 1 Rotary Cutter

SERVICE AND MAINTENANCE SAFETY

Stop engine, set brake, remove ignition key, and wait for all moving parts to stop before

servicing, adjusting, repairing, or unplugging.

Support the equipment with blocks or safety stands before working beneath it.

Follow good shop practices including:

- keep service area clean and dry

- be sure electrical outlets and tools are properly grounded

- use adequate light for the job

Use only tools, jacks, and hoists of sufficient capacity for the job.

Replace and secure all shields removed during serving before operating.

Use heavy leather gloves to handle sharp objects.

Check hydraulics regularly for leaks. Use cardboard to look for leaks, and use hand

and eye protection.

Relieve pressure on hydraulic system before repairing or adjusting.

Failure to follow proper procedures when mounting a tire on a wheel or rim can produce

an explosion, which may result in serious injury or death.

STORAGE SAFETY

Store the unit in an area away from human activity.

Do not permit children to play on or around the stored machine.

Support the frame on stands and blocks to provide a secure base.

SAFETY SIGNS

The following illustration shows the approximate location and detail of safety signs.

Keep all safety signs clean and legible and replace any that are damaged or missing.

When original parts are replaced, any safety signs affixed to those parts should be

replaced as well. Replacement safety signs are available from your local dealer.

INSTALLATION

To install safety signs, ensure the installation area is clean and dry. Decide on the

exact position before you remove the backing paper. Remove the smallest portion of

the split backing paper and align over the specified area. Carefully press in place.

Slowly peel back the remaining paper and smooth the remaining portion in place. Small

air pockets can be pierced with a pin and smoothed out.

Series 1 Rotary Cutter

SERIES 1 ROTARY CUTTER SAFETY SIGNS

Replace safety sign immediately should it become damaged, torn or illegible. Obtain

replacements from your authorized dealer using the part numbers shown.

#1 #4

#2 #3

Series 1 Rotary Cutter

ASSEMBLY INSTRUCTIONS

1. Raise the hitch arms (#4) and the hitch supports (#5) from the deck. Remove the

bolt holding on the top link (#6). Line up the end holes on the hitch supports with

the holes on the outside of the hitch arms where you just removed the bolt. Bolt

the hitch arms, hitch supports and top link together with the bolt you just removed

using two flat washers and a lock nut.

2. Connect the PTO shaft to the gearbox. A snap ring holds on the PTO shaft with

a shear pin. Make sure the PTO guard (#3) is bolted in place.

3. Re-check all the fasteners. There should be free movement of all pieces held

together by a bolt and lock nut.

CHAIN KIT - ASSEMBLY INSTRUCTIONS

All cutters have the required holes for mounting the chain kit. The use of this chain kit

will help reduce the possibility of injury to persons or property by stopping many thrown

objects.

1. Bolt the front chain holder (#1) to the front of the cutter using 3/8” x 1" hex bolts,

lock washers, flat washers and hex nuts.

2. Use ¼” x 5 link chains (#8) at the front. A chain is pushed through each slot from

underneath and a 3/8" rod is threaded through the top link of each chain. Hold

rods in place using the cotter pins supplied. See parts list for correct length of

rods.

3. Bolt the rear center (#3) and rear side (#4 & #5) chain holders to the rear of the

cutter. Use ¼” x 5 link chains (#8) along all rear edges. Thread rods as in front

using lengths as shown in parts list.

Inhaltsverzeichnis

Andere Buhler Freischneider Handbücher

Buhler

Buhler Rotary Cutter Y410lS Bedienungsanleitung

Beliebte Freischneider Handbücher anderer Marken

Echo

Echo SRM-265ES Series Montageanleitung

Victus

Victus VB 260 L Bedienungsanleitung

Solo

Solo 128L Bedienungsanleitung

Stihl

Stihl FS 410 C-M Bedienungsanleitung

CanyCom

CanyCom CMX 253 Bedienungsanleitung

Makita

Makita EBH340U Bedienungsanleitung

Echo

Echo SRM-210AE Bedienungsanleitung

EGO

EGO BCA1220 Bedienungsanleitung

VARO

VARO Powerplus POWXG3016 Bedienungsanleitung

Stihl

Stihl FS 510 C Bedienungsanleitung

Lawn-King

Lawn-King FW35E Bedienungs- und Montageanleitung

Husqvarna

Husqvarna 553RBX Bedienungsanleitung

Ryobi

Ryobi RBC430SBS Bedienungsanleitung

RedMax

RedMax EXtreme EXZ2401S-BC Betriebsanleitung

Vito Agro

Vito Agro VIR43E Bedienungsanleitung

Black & Decker

Black & Decker 82267 Bedienungsanleitung

Agrimate

Agrimate AM-3000-BC-2S-WC-PRO Bedienungsanleitung

Echo

Echo SRM-410ES Bedienungsanleitung
