Bunker Hill Security 62240 Montageanleitung

Page 2 For technical questions, please call 1-888-866-5797. Item 62240

Specifications

Overall Dimensions 9" L x 6-3/4" W x 6-5/8" H

Batteries 4 - AA (sold separately)

IMPORTANT SAFETY INFORMATION

Installation Precautions

1. Verify that installation surface has no hidden

utility lines before drilling or driving screws.

2. Wear ANSI-approved safety

goggles during installation.

3. Mount securely before use.

4. Install only according to these instructions.

Improper installation can create hazards.

5. Keep installation area clean and well lit.

6. Keep bystanders out of the area during installation.

7. Do not install when tired or when under the

influence of alcohol, drugs or medication.

8. Place the Safe on correct surface.

Only use this Safe on a stable, level, clean and dry

surface that is capable of sustaining the load.

Use Precautions

1. Keep closed and locked whenever unattended.

RISK OF CHILD ENTRAPMENT AND

SUFFOCATION.

Check inside before closing.

Do not allow children to play with or near safe.

Keep keys and codes away from children.

2. Keep clear of door when closing.

3. Position batteries in proper polarity and

do not install batteries of different types,

charge levels, or capacities together.

4. Use as intended only.

5. Inspect before every use; do not use

if parts are loose or damaged.

6. Maintain product labels and nameplates.

These carry important safety information.

If unreadable or missing, contact

Harbor Freight Tools for a replacement.

7. Do not store Keys inside of the Safe.

Place the emergency keys in a location

outside of the safe making sure they are

in a secure location that you can find.

8. Warning: The brass components of this

product contain lead, a chemical known

to the State of California to cause birth

defects (or other reproductive harm).

(California Health & Safety code § 25249.5, et seq.)

9. The warnings, cautions, and instructions discussed

in this instruction manual cannot cover all possible

conditions and situations that may occur. It must

be understood by the operator that common sense

and caution are factors which cannot be built into

this product, but must be supplied by the operator.

10. The Safe is not fireproof.

NOTE: Harbor Freight Tools is not responsible

for the loss of any property stored within this safe

due to theft, fire, or any other circumstance.

Page 3For technical questions, please call 1-888-866-5797.Item 62240

Mounting the Safe

1. To mount the Safe to a wall or surface, use

a drill to set the path for each Sheet Metal

Screw. Make certain that the drilling

path is clear and free of obstacles such

as wires, cables and electrical lines.

2. Use wall anchors (not included) as necessary.

3. Insert the Screws (included) through each

drilled hole and into a stud to secure

the Safe to the desired surface.

Page 4 For technical questions, please call 1-888-866-5797. Item 62240

Operation

Read the entire Important Safety Information section at the beginning of this document including all

text under subheadings therein before set up or use of this product.

Opening with Code

Note: The Safe comes preset with a code of 1 5 9

1. Press the numbers 1 5 9 on the Key Pad,

then press either the Aor BKey.

Note: The Yellow Light will illuminate each time a key

is pressed. If it does not, open the safe with the key,

see below, and replace the batteries (see Figure E).

2. Once the Green light is on:

a. turn the Knob clockwise, and

b. pull the Door open.

Note: Three wrong entries will disable the Key Pad

for 20 seconds. Three additional wrong entries

will disable the Key Pad for 5 minutes.

Yellow Light

“Proceed”

Green Light

“Ready”

Red Light

“Low Battery”

Knob

Key

Pad

A Key B Key

Key Hole

Figure A

Opening with Key

Note: The Manual Override Key is used to open the safe

if you forget your PIN, if the batteries are not installed in

the safe, or if the batteries are dead.

Do not store keys in safe!

1. At the center of the Safe door is the Key Hole

for the Override Key, covered by a Keyhole

Guard. Remove the Keyhole Guard.

2. Insert Override Key into the lock and

turn counterclockwise. Then:

a. turn the Knob clockwise, and

b. pull the Door open. Override

Key

Knob

Figure B

Changing the Code

Note: The Safe comes preset with a code of 1 5 9

1. Follow the instructions for opening

the Safe to open the door.

2. Make sure that the Override Key is

available before changing the code.

3. Keep door open during the entire procedure

of changing the code.

On the inside of the Door near the hinge,

there is the small, red, Code Reset Button.

Code

Reset

Button

Figure C

4. User Code:

a. Press the Code Reset Button until the Yellow Light

on the Front Control Panel lights up.

b. Input your new Code (3 to 8 digits) into the

Key Pad, followed by the Aor B Key. A

beep will sound for every digit entered.

c. The green light will go on to confirm

that the Code has been changed.

Page 5For technical questions, please call 1-888-866-5797.Item 62240

Important: The knob on the door must be turned

within 5 seconds of the green light coming on, or the

code will be rejected, and must be entered again.

5. With the door still open, test the new code.

a. First extend the door lock latch to the locked

position by turning the Knob counterclockwise.

b. Once the latch is in the locked position,

use the new Code to open the latch

and ensure that it works.

Note: If desired, make a note of the

new Code and store it in a safe place.

Closing

Keep closed and locked whenever unattended.

Check inside before closing.

Do not allow children to play with or near safe. Keep keys and codes away from children.

1. Close the door and turn the Knob counterclockwise.

2. Pull on the door to make certain it is properly locked.

Knob

Figure D

Page 6 For technical questions, please call 1-888-866-5797. Item 62240

Maintenance

1. Protect the Safe from moist or wet conditions.

Moisture may cause electronic damage in

the keypad or corrosion of the steel.

2. Occasionally wipe the safe and keypad

clean with a soft dry cloth or brush.

3. Occasionally apply a small amount of light

oil or lock lubricant to the mechanical lock

mechanism. Be careful not to get any oil or other

liquids on or near the electronic mechanism.

Page 7For technical questions, please call 1-888-866-5797.Item 62240

Replacing the Batteries

1. If the Red Light illuminates, the

Batteries need to be changed.

2. Follow the instructions for opening the Safe.

Battery

Cover

Figure E

3. The Battery Compartment is located on

the inside of the Door. Unsnap the Battery

Cover from the Battery Compartment.

4. Remove used batteries.

Dispose of them properly or recycle them.

open

Battery

Battery box

Code

Reset

Button

Back of the Safe Door

Battery box cover

Figure F

5. Insert four new “AA” Batteries in their

place. Position batteries in proper polarity

and do not install batteries of different types,

charge levels, or capacities together.

6. Reinstall battery cover by placing it low against the

Battery Compartment and snapping it into place.

7. After changing the batteries, test the Code and

change it as needed before closing the Door.

Limited 90 Day Warranty

Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,

and warrants to the original purchaser that this product is free from defects in materials and workmanship for the

period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,

to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper

installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries

to persons or property, or for incidental, contingent, special or consequential damages arising from the use of

our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the

above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transportation charges

prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.

If our inspection verifies the defect, we will either repair or replace the product at our election or we may

elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will

return repaired products at our expense, but if we determine there is no defect, or that the defect resulted

from causes not within the scope of our warranty, then you must bear the cost of returning the product.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797

Record Serial Number Here:

Note: If product has no serial number, record

month and year of purchase instead.

Note: Replacement parts are not available for this item.
