Burnham Alpine ALP080 Bedienungsanleitung

• 95% AFUE – High Efﬁciency

• Seven Sizes: 80 – 500 MBH for

Residential & Commercial Applications

• Stainless Steel Heat Exchanger for use with

Natural or Propane Gas (up to 10,200 ft.)

• Multiple Venting Options

•CPVC/PVC venting (standard)

•Polypropylene concentric (optional)

•Stainless steel 2-pipe (optional)

• Fully Modulating Boiler Operating Controls

(5-to-1 turndown and includes outdoor reset)

• Modern, appliance-like design with

gas, water, & electric connections on left side

• Polypropylene Condensate Trap with

Integral Float Switch (patent pending)

• Stackable for Modular Applications

Gas-ﬁred, Condensing Stainless Steel Boiler

Alpine

Low

NOx

BURNHAM

FREE* 5-Year Winter

Warmth Assurance

Parts & Labor Plan

* For residential boilers under 300

MBH. Registration is required.

95%

HIGH EFFICIENCY

Peak Performance for Hydronic

and Radiant Heating

Introducing the Alpine from Burnham, a condensing boiler

with efﬁciency ratings of 95%. The Alpine utilizes a stainless

steel heat exchanger, designed to extract maximum heat from

the combustion process, along with a control system that

is designed to enhance boiler efﬁciency as well as system

efﬁciency. With 7 different models ranging in size from 80,000

BTUs – 500,000 BTUs, there’s a model for nearly every job from

small residential to light commercial installations. Intelligent

features are wrapped in a sleek, modern appliance-like jacket,

making the Alpine both attractive and smart.

Stainless steel heat exchanger

The heart of the Alpine boiler is the ASME-certiﬁed stainless

steel heat exchanger. Each heat exchanger is factory

hydrotested to insure quality and reliability.

Alpine Controls

The control system on the Alpine has several features that

maximize efﬁciency and comfort of the heating system:

• Full Modulation with 5-to-1 turndown

• Outdoor Reset

• Plug & Play Connections

• Domestic Hot Water Priority

• Stackable, with Built-in Provisions for External Staging

Controls. Built-in terminals can receive a 0-10V DC signal

from an external modulating control.

Natural or LP Gas

The Alpine is designed for easy ﬁeld conversion from natural

gas to LP gas with no kits or special tools required. The turn of

a screw is all it takes!

FREE 5-Year Parts & Labor Warranty

The unmatched protection of a FREE 5-year parts &

labor warranty is available with every Alpine boiler

under 300 MBH and used in a residential application.

This plan covers all Burnham-provided parts and

the associated labor costs on eligible Alpine boilers

for ﬁve years from the date of installation at no

additional cost! Alpine boiler registration is required

within 90 days from the installation date. Registratrion is fast

and simple, either by completing and mailing the registration

card provided with the Alpine boiler or via the web at

www.burnham.com/productregister.

Gas-ﬁred, Condensing Stainless Steel Boiler

Alpine

Stackable cabinets allow two Alpine boilers to ﬁt the footprint

of one. This feature is standard on every Alpine. When

stacked, 1000 MBH requires approximately six square feet!

BURNHAM

Simple Connections

All gas, water, and

electrical connections

are made from the left

side of the boiler

Smart Controls

Display panel shows

control status, settings

can be adjusted with

soft-touch buttons

Sealed Top Panel

The sealed top panel

protects boiler controls

from spills or leaks;

the components are

also isolated from the

lower jacket to protect

them from cold or moist

combustion air

Single Point Power

Boiler pump and DHW

pump are powered

directly from the Alpine

Negative Cabinet

Pressure

Lower portion of the

boiler cabinet operates

under a negative pressure,

creating an additional

layer of safety

Efﬁcient Combustion

Air and fuel are pre-mixed

in the blower assembly

for clean, balanced

combustion

Condensate

Protection

Unique polyproplyene

condensate trap (patent

pending) stands up to acidic

condensate, and features an

integral ﬂoat switch which

protects the heat exchanger

from back-up

Design Simplicity

Separate spark rod and

ﬂame sensor are used for

longevity and reliability

Control panel slides out

for easy servicing

American-Made Quality

Alpine boilers are designed

and assembled in Lancaster,

PA. Each Alpine is hydro-

tested and ﬁre-tested in

order to deliver safety,

efﬁciency, durability

and low emissions.

Long Lasting Comfort

Durable, efﬁcient stainless

steel heat exchanger

maximizes heat transfer

Burnham

Alliance SL™

Indirect-ﬁred Water

Heaters

The Alliance SL water heaters are

designed with an effective hydrastone lining that

offers superior corrosion resistance and outstanding

performance in a wide variety of water conditions.

Water heaters are available in ﬁve sizes and come

with a unique 10/2/1 warranty – 10 years on the

tank and coil, 2 years labor and 1 year on parts.

Venting

Easy To Move

and Install

Jacket sides are equipped

with ﬂush mounted carry

handles. Jacket bottom

features nylon glides

An optional European-standard

Polyproplyene Concentric

Vent System is also available.

The Alpine can also be vented

with an optional two pipe system

using stainless steel (AL29-4C)

vent matierial.

Alpine comes standard with a CPVC/PVC

vent kit. This ETL-approved material consists of a

30” CPVC starter pipe and one 90° CPVC elbow.

ALSO AVAILABLE

Phone: 1-888-432-8887

www.burnham.com

Printed in the U.S.A.

Pub. HYDL04081-25Ms

www.burnham.com

Alpine

16-11/16”

LLow Voltage

Knockouts (24V)

Line Voltage

Knockouts (115V)

One handle on

ALP80 & 105, Two

handles on all

other models

(Return tapping)

(Gas valve inlet)

(Supply tapping)

3/4” FPT

relief/drain

tapping

(Condensate

trap drain)

DCE

Model

No.

(in.)

ALP080 12-9/16 5-5/8 7-5/16 9-5/16 5-15/16 1/2 1 1 * 8 32-3/16 16-11/16 12-1/2 4-3/4

ALP105 14 5-13/16 7-5/16 10-3/4 5-15/16 1/2 1 1 * 8 32-3/16 16-11/16 12-1/2 4-3/4

ALP150 19-11/16 5-13/16 7-5/16 16-7/16 5-15/16 1/2 1 1 * 8 32-3/16 16-11/16 12-1/2 4-3/4

ALP210 23-15/16 5-13/16 7-5/16 17-1/8 5-15/16 1/2 1 1 * 8 32-3/16 16-11/16 12-1/2 4-3/4

ALP285 21-13/16 7-5/16 14-1/8 18 12-1/4 3/4 1-1/4 1-1/4 * 8-5/16 43-7/16 17-5/16 12-3/16 4-3/4

ALP399 28-7/8 6-3/16 13-1/16 23-3/4 15-13/16 1 1-1/2 1-1/2 * 8-5/16 43-7/16 17-5/16 12-3/16 4-3/4

*Factory provided socket end compression pipe joining clamp for 3/4” schedule 40 PVC pipe

Model No.

Input (MBH)

Output

(MBH)

Net

I=B=R

(MBH)

AFUE

(%)

Boiler Water

Volume

(gallons)

Heat Trans.

Area

(sq. ft.)

Shipping

Weight

(pounds)

Minimum Maximum

to 2k ft. 2-7k ft. 0-7k ft.

ALP080 16 27 80 73 63 95 0.6 0.6 137

ALP105 21 35 105 96 83 95 0.7 0.7 155

ALP150 30 50 150 137 119 95 1.3 1.3 182

ALP210 42 70 210 193 168 95 1.7 1.7 206

ALP285 57 57 285 263 229 95 2.4 2.4 256

ALP399 80 80 399 377* 328 94.1/94.5** 3.4 3.4 304

ALP500 – Call for product availability and additional information –

Alpine Speciﬁcations

Alpine Dimensions

NOTES: DOE Heating Capacity (ALP080 through ALP285); Gross Output (ALP399)

Maximum Working Pressure - Water: ALP080-285=30PSI; ALP399=50PSI; 80PSI optional on all models

Maximum Allowable Temperature = 210˚ F

Boilers shipped set for natural gas; ﬁeld adjustment for LP (see instruction manual)

For elevations above 2000 feet, reduce ratings four percent (4%) per 1000 feet above sea level

Model

No.

Intake

Size

Vent

Size

Max

Length

ALP080 3” 3” 60’

ALP105 3” 3’ 60’

ALP150 4” 3” 60’

ALP210 4” 3” 60’

ALP285 4” 4” 60’

ALP399 4” 4” 60’

Alpine Intake / Vent Sizes

Max length in equivalent feet for each run is 60

equivalent feet of intake & 60 equivalent feet

vent length

# of 90° Elbows 2 4 6 8 10 12

Combined Intake/Vent - Feet of Pipe 110’ 100’ 90’ 80’ 70’ 60’

Maximum Vent Lengths

NOTE: Snorkels are approved for use with PVC venting.

Intake & vent lengths combined. 90° = 5 equivalent feet.

Terminals do not count towards vent feet length

** Thermal/combustion efﬁciency

*Gross output
