Max bandwidth………………………………………….…………………………………225MHz
Max baud rate……………….…….………………….….……….………………………6.75Gbps
nput Video signal ………….…………………………...…………………….… 0.5~1.5Volts p-p
Output DDC signal ……………………………………………………………… 5Volts p-p (TT1L)
nput HDM cable distance..…... …………………....….…≤15m AWG26 HDM standard cable
Output HDM cable distance…………………..…..….…...≤20m AWG26 HDM standard cable
Max working current(TX)…………………………………………………………………...2000mA
Max working current(RX)………………………………………………..…………………...600mA
Power adapter format(TX)………….… nput:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/3A
Power adapter format(RX)…………… nput:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range……..…..………….……………..…………………… (0 to +40 )℃
Operating Humidity range………………………….….…..…….5 to 90%RH (No Condensation)
Dimension (TX) …………………………….…………….……………..………..205x74x26(mm)
Dimension (RX) …………………………….………………..……...…(82X44X22) (mm) X4pcs
Weight…..…………………………………………………..……..….……………………..……750g
.
Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the machine.
1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty,
Erosive, and oxidative environment.
2. All parts will be free from the strong shake, hit, fall.
3. Touching the power adaptor with the wet hands is prohibited.
4. Pls hold the power adaptor head and do not pull the power cord when cut off from the
socket.
5. Pls turn the power off when the machine is not used for long time.
6. Pls do not open the cover and do not touch the inside parts.
7. Pls use the original factory power adaptor.
