SmartSwitch 9000

9T122-08

Token Ring Module

User’s Guide

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9031359-02

SPECTRUM

Remote LANVIEW

and

LANVIEW

are registered trademarks and

SmartSwitch

and

MicroLAN

are trademarks of Cabletron Systems, Inc.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

VCCI Notice

This equipment is in the 1st Class Category (information equipment to be used in commercial and/or

industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference

by Information Technology Equipment (VCCI) aimed at preventing radio interference in commercial

and/or industrial areas.

Consequently, when used in a residential area or in an adjacent area thereto, radio interference may be

caused to radios and TV receivers, etc.

Read the instructions for correct handling.

iii

Notice

DOC Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique

édicté par le ministère des Communications du Canada.

Notice

Contents

Chapter 1 Introduction

Features........................................................................................................................... 1-1

Related Manuals............................................................................................................ 1-4

Getting Help .................................................................................................................. 1-4

Chapter 2 Installing the SmartSwitch 9000 Module

Unpacking the Module................................................................................................. 2-1

Installing an TPIM ........................................................................................................ 2-1

User Accessible Components ...................................................................................... 2-3

Setting the Module Card DIP Switch ......................................................................... 2-4

Ring Speed ..................................................................................................................... 2-6

Installing the Module into the SmartSwitch 9000 Chassis...................................... 2-6

The Reset Switch ........................................................................................................... 2-8

Chapter 3 Operation

Bridging.......................................................................................................................... 3-1

Transparent Bridging (Provided Between all Three Interfaces)...................... 3-2

Source Route Bridging (Provided Only Between Front Panel Rings)............ 3-3

SR-TB Bridging (Front Panel Token Ring to FNB)............................................ 3-3

Spanning Tree Algorithm...................................................................................... 3-4

Flexible Network Bus (FNB)........................................................................................ 3-4

System Management Buses ......................................................................................... 3-4

SMB-1 Bus ............................................................................................................... 3-4

SMB-10 Bus ............................................................................................................. 3-5

System Diagnostic Controller...................................................................................... 3-5

DC/DC Converter ........................................................................................................ 3-5

FNB Interface................................................................................................................. 3-5

i960 Core......................................................................................................................... 3-6

Chapter 4 LANVIEW LEDs

Chapter 5 Speciﬁcations

Safety............................................................................................................................... 5-1

Service............................................................................................................................. 5-1

Physical........................................................................................................................... 5-2

Dimensions: ............................................................................................................ 5-2

Weight:..................................................................................................................... 5-2

Electrical ......................................................................................................................... 5-2

Contents

Appendix A TPIM Speciﬁcations

TPIM-T1............................................................................................................................. 1

TPIM-T2 and TPIM-T4 .................................................................................................... 3

TPIM-F2 ............................................................................................................................. 4

TPIM-F3 ............................................................................................................................. 5

1-1

Chapter 1

Introduction

The 9T122-08 MicroLAN™ Switch Extension Module, shown in Figure 1-1, is a

three port Token Ring switch module. This module supports two separate Token

Rings with four lobe connections each, and an interface to the FNB backplane.

Each front panel Token Ring also supports Ring-in/Ring-out connections by

using plug-in Token Ring Port Interface modules (TPIMs).

Features

Processor

The 9T122-08 is equipped with an advanced Intel i960 microprocessor. This

microprocessor provides a platform for all management functions within a

scalable RISC-based architecture.

System Management

Interfaces to the two System Management Buses (SMB-1 and SMB-10) for

intermodule management.

Connectivity

The 9T122-08 provides four RJ-45 Trunk Coupling Unit (TCU) lobe connectors for

each of the two front panel Token Rings. Each front panel Token Ring has sockets

for TPIMs, allowing for Ring-in/Ring-out connections

SRT Packet Switching

SRT Bridging between the front panel Token Ring connections and SR-TB

bridging to any other module in the chassis via FNB -1 or FNB -2 of the FNB bus.

The module is capable of Transparent Bridging and/or Source Route Bridging.

IEEE 802.1d Spanning Tree Protocol is supported in all bridging functions.

Translational bridging between Source Routing and Transparent Frames types is

also performed for packets destined for the FNB.

Introduction

1-2

Management Information Base (MIB) Support

The 9T122-08 module provides MIB support including:

• IETF MIB II (RFC 1213)

• IETF Bridge MIBs (RFC 1493 and 1525)

• IEEE 802.5 Token Ring MIB (RFC 1231)

• Cabletron Enterprise MIBs

Ring Security

Ring Security prevents unauthorized stations from attaching to the ring. Using

Local or Remote Management, the module may be conﬁgured as to which MAC

addresses are allowed to operate on the ring.

Telnet

A telnet session can be set up with the module to provide access to the Local

Management screens.

LANVIEW LEDs

The 9T122-08 uses LANVIEW – the Cabletron Systems built-in visual diagnostic

and status monitoring system. With LANVIEW LEDs, you can quickly identify

the device, port, and physical layer status at a glance.

Hot Swapping

The 9T122-08 can be installed or removed from the chassis while the SmartSwitch

9000 is powered up without affecting the operation of the remaining modules in

the chassis.

For a complete list of supported MIBs, refer to the release notes provided in the

module package.

NOTE
