Cadillac Prodigy One.2 Bedienungsanleitung
Prodigy One.2
Installation
TD-CADICTS-KIT
Manual
www.intraphex.com
support@intraphex.com
Support: 810.355.2266
Fax: 810-735-0175
Contacts
Dash Pad Bracket
Prodigy One.2
Monitor
Prodigy One Data Cable
CTS Radio T-Harness
AV input Cable
4 Pin Touch Cable
Multi Display PCB
& Connectors
Bag of Screws & Clips
Stereo Aux in Cable
Contents
Remove center console trim bezels. use hook tool to release panel from
rear. Place panels in safe locaon to assure they don’t get scratched.
Remove gear selector trim bezel. Use hook tool to release panel from
rear. Place panel in a safe locaon.
Place shier into “Neutral” (g A), pull gear selector trim bezel away from
radio dash bezel (g B),
Remove two 7mm screws at the lower le and right of the radio dash
bezel (g c).
Remove shown plasc trim. Use hook too to pull from noted area.
Remove shown plasc trim. Use hook tool to pull from noted area.
Use cauon not to break plasc tabs.
Remove radio dash bezel. Use cauon and unplug all connecons from
back of panel.
Remove four 7mm screws from front panel of disc changer.
Remove changer assembly and unplug all plugs from rear.
Install INTRAPHEX supplied “T-harness”, route wires as necessary to
ensure that changer assembly can be installed back into locaon.
Plug male end of INTRAPHEX supplied “T-harness” into rear of changer
assembly and reinstall antenna plugs.
Replace changer assembly and re-install four 7mm screws.
Please refer to wiring diagram in back of manual for reference
Connect 12 volt acc wire. Use Mul-meter to test. Located at BCM,
green plug PIN 6, pink wire.
Insert INTRAPHEX supplied T-nuts into empty locaons shown.
Next we will remove the OEM radio LCD, and preset buons.
Remove eight #1 screws securing the panel in place.
Gently pull the radio lcd away from dash bezel.
Remove four remaining #1 screws from lcd assembly
