caenrfid easy2read Slate R1260I Technisches Dokument
TECHNICAL INFORMATION MANUAL
Revision 0.1 – 14 December 2016
R1260UB
RFID UHF Desktop
Reader
Scope of Manual
The goal of this manual is to provide the basic information to work with the Slate R1260UB RFID UHF Desktop Reader.
Change Document Record
Date Revision Changes Pages
14 December 2016 0.1 Preliminary release -
Reference Document
[RD1] EPCglobal: EPC Radio-Frequency Identity Protocols Class-1 Generation-2 UHF RFID Protocol for
Communications at 860 MHz – 960 MHz, Version 1.1.0 (December 17, 2005).
CAEN RFID srl
Via Vetraia, 11 55049 Viareggio (LU) - ITALY
Tel. +39.0584.388.398 Fax +39.0584.388.959
www.caenrfid.com
© CAEN RFID srl – 2016
Disclaimer
No part of this manual may be reproduced in any form or by any means, electronic, mechanical, recording, or
otherwise, without the prior written permission of CAEN RFID.
The information contained herein has been carefully checked and is believed to be accurate; however, no responsibility
is assumed for inaccuracies. CAEN RFID reserves the right to modify its products specifications without giving any
notice; for up to date information please visit www.caenrfid.com.
Preliminary Product Information
This document contains information for a new product. CAEN RFID reserves the right to modify this product without
notice.
“Preliminary” product information describes products that are ready for production, but for which full characterization
data is not yet available. CAEN RFID believes that the information contained in this document is accurate and reliable.
However, the information is subject to change without notice and is provided “AS IS” without warranty of any kind
(Express or implied). You are advised to obtain the latest version of relevant information to verify, before placing
orders, that information being relied on is current and complete. All products are sold subject to the terms and
conditions of sale supplied at the time of order acknowledgement, including those pertaining to warranty, patent
infringement, and limitation of liability. No responsibility is assumed by CAEN RFID for the use of this information,
including use of this information as the basis for manufacture or sale of any items, or for infringement of patents or
other rights of third parties.
Disposal of the product
Do not dispose the product in municipal or household waste. Please check your local regulations for
disposal/recycle of electronic products.
3
Index …
Scope of Manual ...........................................................................................................................................................................2
Change Document Record ............................................................................................................................................................2
Reference Document ....................................................................................................................................................................2
Index … .......................................................................................................................................................................................... 3
List of Figures ................................................................................................................................................................................. 3
List of Tables .................................................................................................................................................................................. 3
1 INTRODUCTION ................................................................................................................................................................... 4
Product Description ......................................................................................................................................................................4
Accessories ...................................................................................................................................................................................5
Installation Notice ........................................................................................................................................................................5
2 FUNCTIONAL DESCRIPTION ................................................................................................................................................. 7
Main Features...............................................................................................................................................................................7
External Connection .....................................................................................................................................................................7
Front Panel LEDs ...........................................................................................................................................................................7
Serial Port Emulator .....................................................................................................................................................................8
Driver installation ............................................................................................................................................................8
Firmware Upgrade ......................................................................................................................................................................12
3 TECHNICAL SPECIFICATIONS .............................................................................................................................................. 13
Technical Specifications Table ....................................................................................................................................................13
Reader – Tag Link Profiles ...........................................................................................................................................................14
Radiation Patterns ......................................................................................................................................................................15
List of Figures
Fig. 1.1: Slate R1260UB RFID UHF Desktop Reader .................................................................................................................................4
Fig. 1.2: Slate R1260UB Technical drawings: top view ............................................................................................................................5
Fig. 1.3: Slate R1260UB Wall mounting ...................................................................................................................................................6
Fig. 3.1: Slate R1260UB Radiation pattern H plane ...............................................................................................................................15
Fig. 3.2: Slate R1260UB Radiation pattern V plane ................................................................................................................................15
List of Tables
Tab. 2.1: Slate R1260UB Front Panel LEDs...............................................................................................................................................7
Tab. 3.1: Slate R1260UB Technical Specifications .................................................................................................................................13
Tab. 3.2: Slate R1260UB Reader to tag link profiles ..............................................................................................................................14
INTRODUCTION - Slate R1260UB Technical Information Manual 4
1 INTRODUCTION
Product Description
The Slate (Model R1260UB), the new desktop reader of the easy2read© Family, is an UHF RFID reader with integrated
antenna for short range applications.
The Slate Reader is powered and controlled directly by an USB cable, thus allowing to read EPC Class 1 Gen 2 UHF RFID
tags in an easy desktop environment.
Thanks to its low profile (15 mm) and its size (approximately an A4 page), the Slate reader is the perfect choice for
various applications such as point-of-sales, document tracking, RFID programming stations, access control and so on. It
can be used as a building block for smart shelves and smart displays.
The core component of the Slate is the new CAEN RFID Quark module, the smallest and lowest power consuming
module available on the market.
Fig. 1.1: Slate R1260UB RFID UHF Desktop Reader
INTRODUCTION - Slate R1260UB Technical Information Manual 5
Accessories
Check for the supplied accessories below:
No.2 wall hooks
No. 4 rubber feet
No.2 rawlplugs (ø 4 mm) +screws
No. 2 small screws (ø 3 mm)
Installation Notice
The Slate R1260UB can be easily placed on a table for desktop applications or it is possible to hang it on the wall.
Fig. 1.2: Slate R1260UB Technical drawings: top view
INTRODUCTION - Slate R1260UB Technical Information Manual 6
Horizontal Installation:
The Slate can be easily placed on a table for desktop applications affixing the 4 rubber feet to the bottom of the Slate
R1260UB to prevent it from sliding.
Vertical Installation:
The Slate can be hanged on the wall (see Fig. 1.3: Slate R1260UB Wall mounting).
First of all, use the two small screws (ø 3 mm) to fix the 2 hooks on the Slate.
Then, to hang the Slate on the wall, fix the hooks to the wall using the 2 rawlplugs (ø 4 mm) + screws at a distance of
146 mm each others.
If you want to hang the Slate on a wood panelling, fix the hooks to the wall just using the 2 screws.
Fig. 1.3: Slate R1260UB Wall mounting
FUNCTIONAL DESCRIPTION - Slate R1260UB Technical Information Manual 7
2 FUNCTIONAL DESCRIPTION
Main Features
FCC part 15 compliant
SRRC RFID national standards compliant
EPC C1 G2/ISO18000-6C compliant
Integrated circular polarized antenna
Programmable output RF power
Powered by USB
Low profile
External Connection
The external connection is via USB port.
The USB cable is located in the back side of the Slate. You can pass the USB cable through the opening at the bottom or
at the top of the Slate back side. The mechanical specification of the USB Port is as follows:
USB Port: USB Type A plug connector
The Slate R1260UB is powered through the USB host.
Front Panel LEDs
The Slate R1260UB front panel houses the following LEDs (see Fig. 1.2: Slate R1260UB Technical drawings: top view):
LEDS FUNCTION TYPE
POWER Power ON Green LED
TAG-ID Tag detection Blinking Red LED
TX/RX USB communication activity Blinking Yellow LED
Tab. 2.1: Slate R1260UB Front Panel LEDs
FUNCTIONAL DESCRIPTION - Slate R1260UB Technical Information Manual 8
Serial Port Emulator
The SLATE R1260UB can be connected to a PC via USB connection. The RFID reader emulates a serial port. In the next
paragraph the procedure to install the required driver is presented.
Driver installation
The procedure to install the USB driver is presented below:
1. Verify that the USB cable is correctly plugged into the PC.
2. If the USB to Serial driver is not installed on the PC the following pop-up window is displayed.
3. Insert the CD provided together with the SLATE R1260UB. Select “No, not this time” and click on next.
4. Select “Install from a list or specific location and click on next.
FUNCTIONAL DESCRIPTION - Slate R1260UB Technical Information Manual 9
5. Select “Search removable media” and click on next.
6. When the installation is successfully terminated, press on Finish.
FUNCTIONAL DESCRIPTION - Slate R1260UB Technical Information Manual 10
7. Now the driver installation procedure is completed. Open the System properties (right click on “My computer”
icon) → Hardware → Device Manager.
8. See the emulated serial port in the “USB serial port(COM X)”, in the case below COM4.
