Cafection Encore VENTI Bedienungsanleitung
CLEANING GUIDE
for Key Holder
Cafection Encore Venti
2
Need Assistance?
Contact your service provider.
3
TABLE OF CONTENT
Important Notices 5
Daily Routine 6
Filling Up Ingredients...............................................................7
Performing a Rinse ..................................................................8
Emptying the Waste Bin ..........................................................9
Changing the Filter Paper (if Empty) ....................................10
Cleaning the Unit....................................................................11
Weekly Routine 12
Cleaning the Coffee Chute or Internal Waste Bin ...............13
Cleaning the Soluble Canisters Elbows ...............................14
4
5
Important Notices
This guide is designed to help you maintain your machine clean and in
good condition by suggesting simple and easy steps.
Do not perform advanced maintenance if you did
not receive an adequate technical training.
Parts are not dishwasher safe.
All parts in contact with food must be air dried completely before
reinstalling.*
RECOMMENDED TOOLS AND CLEANING MATERIAL:
• Small brush, suitable for food-contact surfaces and hot water
• Brush for coffee grounds, suitable for food-contact surfaces
• Scissors
• Water resistant and lint-free towel
• 100% cotton soft cloths
• Mild non-abrasive cleaner
• 16-ounce container (preferably reusable)
*Air drying is the only drying method approved by Cafection to prevent
contamination. In the event you use a towel, make sure to follow the
manufacturer cleaning instruction.
6
Daily Routine
BEGINNING OF THE DAY
FFill up the ingredient canisters and
condiments dispenser
DURING THE DAY, WHEN REQUIRED
FPerform a rinse
FEmpty the waste bin
FVerify the filter paper level and change the roll if empty
END OF THE DAY
FClean the unit
FEmpty and clean the drip tray and grill
FTidy up the coffee area
7
Filling Up Ingredients
Unlock and remove the hopper top
lid, then fill up the bean hoppers.
Make sure to avoid
cross-contamination.
Open the door and remove the plastic
hood. Remove lids of the soluble
ingredients canisters one at a time and
fill them up.
Access Service mode:
1. Open the door.
2. Press on the SW1 button (white) on the main board.
Access the Product Levels screen and adjust
the levels using the bean icon.
Exit Service mode. Reinstall the hood and
close the door.
Make sure your cup and condiment dispenser is full with stirrers,
sugars, cups, etc.
1
2
3
5
4
8
Performing a Rinse
Place an empty container under the
spout. Make sure it has a minimum
capacity of 16oz.
Access Service mode:
1. Open the door.
2. Press on the SW1 button (white) on the main board, then
close the door.
Perform an auto rinse.
Verify if your container is well positioned
and tap the “Rinse” button on the popup
window.
Wait until water has completely finished
dripping. Be careful, the water is VERY HOT.
Once the rinse is completed, exit Service mode.
Empty the container. Be careful, the water is
VERY HOT.
Do not drink this water.
1
16 oz
2
3
4
9
Emptying the Waste Bin
Open the brewer door and remove the brew
group protective panel.
Cut the filter paper 4inches
below the brew group with
scissors.
DO NOT YANK ON THE
PAPER!
MACHINE WITH COFFEE CHUTE
Change the bag of the waste bin under the
counter. Reinstall the protective panel and
close the brewer door.
MACHINE WITH INTERNAL WASTE BIN
Remove the internal waste bin from the
unit and empty it. Put the waste bin back
in the unit.
DO NOT USE A PLASTIC BAG.
Reinstall the protective panel and close the brewer door.
Access Service mode:
1. Open the door.
2. Press on the SW1 button (white) on the main board.
Reset the waste bin counter, then exit Service
mode.
1
2
3
4
10
Changing the Filter Paper (if Empty)
Access Service mode:
1. Open the door.
2. Press on the SW1 button (white) on the main board, then
close the door.
Tap “Filter Paper Install”.
Open the brewer door, remove the protection
panel and remove the empty filter paper roll.
Install the new roll. Feed the
paper under the left guide
bracket of the brew group,
under the brew chamber and
under the wheel guides by
gently lifting them using the
yoke. Then close the door.
Tap “OK” on the installation popup
window.
Choose “Yes” to the question “Did
you replace the filter paper roll with a
new full roll?”
Exit Service mode.
1
2
3
4
