CalDigit VR2 Bedienungsanleitung

Getting Started

For more information visit www.caldigit.com

Apple, Apple Logo, Mac, the Mac logo and Macintosh are trademarks of Apple Inc.

Microsoft, Windows and Windows Logos are registered trademarks of the Microsoft Corporation.

All other trademarks are the property of their respective owners.

*Specications and package contents are subject to change without notice.

CalDigit VR2

RAID 1 PROTECTED

Contents

Introduction

General Use Warnings

Safety Warnings

Tech Specs

Package Contents

CalDigit VR2 Overview

CalDigit VR2 Front Panel

CalDigit VR2 Rear Panel

Installing the CalDigit VR2

LCD Menu Overview

LCD Display Information

CalDigit VR2 LCD Menu Tree Overview

RAID Tool Feature Overview

Conguring your RAID

Using the LCD Menu

Using RAID Tool

Accessories and Parts

Technical Support & Warranty Information

Technical Support

CalDigit Warranty Information

Thank you for choosing the CalDigit VR2. The CalDigit VR2 is the most complete two drive

RAID system on the market today. It oers unmatched performance, impressive connectivity

and superior quality all in a sleek and easily upgradeable enclosure that is both portable

and functional.

Please use the following quick installation instructions to setup your CalDigit VR2.

Introduction

Note: Please only use the CalDigit VR2 in places with cool and natural

ventilation. Please do not use the CalDigit VR2 under extremely hot or

cold environments to avoid possible data damage that can be caused by

extreme temperatures.

General Use Warnings

Please read the CalDigit VR2 manual thoroughly and become familiar with the product

before use.

Only use the CalDigit VR2 in an area with cool ventilation. Make sure that the fan is

not obstructed to ensure heat dissipation. Do not leave or use the VR2 near a heat

source such as a heater or direct sunlight.

Avoid using the VR2 in extremely hot and cold environments as it will increase the

likelihood of premature drive failure. A safe temperature range is between 40F – 95F.

Avoid using the VR2 in humid environments. Moisture and condensation can accumulate

in the drive and damage the electrical components, resulting in unit failure

and catastrophic data loss.

Only use the power adapter that has been supplied with the VR2 Drive. An excessive or

inadequate power supply can result in unstable performance or drive failure.

Make sure to transport your VR2 with care. Hard drives are sensitive to shock and

rough handling can result in degrading performance or disk failure.

Safety Warnings

Keep the VR2 away from liquids and moisture. Direct application of liquids on the VR2 can

result in electric shock, re hazard and damage the unit. If your VR2 gets wet while it is still

o, do not turn it on.

Do not tamper with or try to repair the VR2 unless you are a certied CalDigit technician.

Doing so can result in personal injury and damage the VR2. This will also void your

warranty. If you have any issues, contact CalDigit Technical Support.

Tech Specs

Size and Weight:

Height: 3.6 inches (92 mm)

Width: 5.3 inches (134 mm)

Depth: 8.5 inches (216 mm)

Weight: 6.6lbs (3.0 kgs)

Interface and Data Transfer:

1x SuperSpeed USB 3.0 Port up to 5Gbps

1x eSATA Port up to 3Gbps

2x FireWire 800 (IEEE 1394b) Ports up to 800Mbps

1x FireWire 400 (IEEE 1394a) Port up to 400Mbps

RAID Function:

Supports RAID 0, 1, Spanning, JBOD*

Automatic online fast disk rebuilding

Automatic disk failure detection

Hot swappable disks

*USB 3.0 & eSATA do not support JBOD

System Requirements:

Windows 2000, XP, Vista, 7 or later

Mac OS 10.4 or later

USB 3.0

Windows XP or later, Mac OS 10.5 or later

Notes:

Downloadable versions of the user manual & drivers are available on the CalDigit support page.

http://www.caldigit.com/support.asp

Burst transfer rates will vary from one computer to another. Depending on the host conguration, average speeds are usually lower.

Weight varies by conguration and manufacturing process.

IMPORTANT: Use of this product is subject to acceptance of the software license agreements included. Product contains electronic documentation.

1TB (Terabyte) = 1000GB. 1GB = 1,000,000,000 bytes. Total accessible capacity varies depending upon operating environment (typically 5-10% less).

Environment:

Operating Temperature: 41°F ~ 140°F (5°C ~ 60°C)

Storage Temperature: -40°F ~ 158°F (-40°C ~ 70°C)

Fan Module:

Size: 50(L) x 50(W) x 15(H) mm

Rated Voltage: DC 12V, 1.08W

Speed: 3400 R.P.M. ± 10%

Airow: 10.2 CFM (ft3/min)

Noise Level: 22 dB(A)

Power Supply Adapter:

Full range AC Input: 100V-240V ~ 50/60Hz Max 2A

DC Output: 12V/3.5A, 5V/4A

In the Box:

1x CalDigit VR2

1x eSATA Cable

1x FireWire 800 Cable

1x AC Adapter

1x AC Power Cord

2x Keys

1x Driver & Manual CD

Tech Specs

Package Contents:

1. (One) CalDigit VR2

2. (Two) CalDigit drive modules

3. (One) FireWire 800 cable

4. (One) eSATA cable

5. (Two) drive module keys

6. CalDigit Driver & Manual CD

7. (One) Power supply kit

Please contact your CalDigit reseller for any faulty or missing parts.

Congratulations on your purchase of this CalDigit product!

To make the most of your storage investment you can purchase the

CalDigit Extended Warranty. You'll extend the already great CalDigit

warranty to 3 years. If the product is discontinued during the

warranty period, you'll be eligible for equal or greater value upgrade

(if the product cannot be xed). In addition, you'll get one-way

shipping costs covered by CalDigit, plus get an exclusive warranty

case number to CalDigit's tech support team.

The extended warranty must be purchased within 90 days of purchase date.

Visit the CalDigit Online Store for more information www.caldigit.com

CalDigit VR2

RAID 1 PROTECTED

CalDigit VR2 Overview

CalDigit VR2 Front Panel

*Security lock (lock is not included)

Use a standard computer lock to secure the CalDigit VR2 and prevent theft.

Power Button

Ventilation Holes

Security Lock*

FireWire

USB 3.0

Power

Smart Fan

CalDigit VR2 Rear Panel

Right ButtonLeft Button

LCD Screen

LED Status Lights

eSATA

Drive Module A0

Drive Module A1

Drive Key Hole

Installing the CalDigit VR2

The CalDigit VR2 is ready to use out of the box.

Select the desired interface, FireWire 400, FireWire 800, USB 3.0 or eSATA. A FireWire 800

and eSATA cable are included.

Connect the power supply to the CalDigit VR2, then connect the desired interface cable.

Press the CalDigit VR2's power button. The CalDigit VR2 will boot. You should see the

CalDigit VR2 mount and it's ready to use.

To change the RAID level or to customize your CalDigit VR2 use the LCD or CalDigit’s RAID

Tool software. For further instructions see the Conguring your RAID section of this manual.

Note: If you would like to connect the CalDigit VR2 with eSATA, there are several

options. If you already have an eSATA controller card or port, simply connect the

provided eSATA cable. If you have a Mac or PC workstation that has internal SATA

port (late model Mac Pros) you can use an eSATA extender (available from

CalDigit). You can also purchase one of CalDigit's eSATA controller cards which

provide additional features (FASTA-2ex, FASTA-2e or FASTA-4e).

Note: If you would like to connect the CalDigit VR2 with USB 3.0 and do not have

a built in USB 3.0 port, you can purchase one of CalDigit’s USB 3.0 cards (CalDigit

SuperSpeed ExpressCard for Laptop, CalDigit SuperSpeed PCI Express Card or the

FASTA-6GU3). CalDigit's USB 3.0 cards work with both the Mac under OS X and

Windows.

For more information visit www.caldigit.com.

LCD Display Information

The CalDigit VR2 LCD displays information in the following order:

System Prole - will display the status of 8 features

RAID status

Displays the current RAID status.

Serial number

Displays the CalDigit VR2 serial number.

Firmware version

Current CalDigit VR2 rmware version.

System temp

Displays the current system temperature.

Disk 1 temp

Displays temperature of the top hard drive.

Disk 2 temp

Displays temperature of the bottom hard drive.

Beeper status, LCD cong status

Provides beep alarm status, provides LCD menu conguration status.

Access LED status, Auto rebuild status

Provides LED access status, provides auto rebuild status.

Create RAID - 3 dierent RAID levels can be set

Create RAID 0

Data is written onto two hard drives at a time for maximum speed.

Create RAID 1

Identical data is written onto two hard drives with maximum protection.

Create SPAN

Combine two hard drives into one volume, data will be accessed from the rst

hard drive until full, then the second hard drive will be used.

Create JBOD

“Just a Bunch of Disks” Creates 2 independent volumes, one from the disk 1 and

the second from disk 2. This mode can also be used to read a single drive from a

RAID 1 mirror, however once used the RAID 1 mirror cannot be restored.

Clear RAID Info

Clears the RAID table information on the CalDigit VR2 and both drives.

LCD Menu Overview

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

2.1

2.2

2.3

2.4

2.5
