Calixto-Telit GL86x GPRS MODEM

User Manual

system, or transmitted, in any form or by any means whether, ele troni , Me hani al, or otherwise

without the prior written permission of Calixto Systems. No warranty of a ura y is given on erning the

ontents of the information ontained in this publi ation. To the extent permitted by law no liability

(in luding liability to any person by reason of negligen e) will be a epted by Calixto Systems or

employees for any dire t or indire t loss or damage aused by omissions from or ina ura ies in this

do ument.

Calixto Systems reserves the right to hange details in this do ument without noti e. Produ t and

ompany names herein may be the trademarks of their respe tive owners.

#111, First Floor, 2H Main Road, Kasturi Nagar, Bangalore, India -560 043.

Web: www. alixtosystems. om Email: info@ alixto. o.in

_____________________________________________________________________________________

Revision History

Date

Revision

Remar s

20/02/2013

0.1

First version reated

07/05/2013

0.2

Added pin numbers for

expansion onne tor.

Table of Contents

Introdu tion ................................................................................................... 5

CST-GL86x-MODEM Features: ........................................................................ 5

2.1 General features: ...................................................................................................................... 5

Calixto CST-GL86x-MODEM ordering Info ...................................................... 6

3.1 Produ t Variants ....................................................................................................................... 6

Produ t details ............................................................................................... 6

Hardware Des ription .................................................................................... 7

5.1 Telit GL86x module: .................................................................................................................. 7

5.2 GPRS Antenna .......................................................................................................................... 7

5.3 Power Ja k ................................................................................................................................ 8

5.4 LED Indi ations ......................................................................................................................... 8

5.5 Battery onne tor ..................................................................................................................... 8

5.6 RS232-DB9 (J2) ......................................................................................................................... 8

5.7 Expansion Conne tor Slot (J7) ................................................................................................... 9

Electrical and Environmental Specification .................................................. 10

Communicating with Modem ....................................................................... 10

7.1 Serial Interfa e me hanism ..................................................................................................... 10

7.2 Communi ation Software ....................................................................................................... 11

Legal Noti e ................................................................................................. 12

8.1 Customer Support: ................................................................................................................. 12

8.2 Usage Restri tion: ................................................................................................................... 12

Warranty and Return Poli y ......................................................................... 12

9.1 Warranty Period: .................................................................................................................... 12

9.2 Warranty Coverage: ................................................................................................................ 12

9.3 Produ t Repair: ....................................................................................................................... 13

9.4 RMA (Return Mer handise Authorization) .............................................................................. 13

1. Introduction

This do ument talks about details of Calixto’s Telit GL86x based GPRS modem (CST-GL86x-MODEM and

CST-GL86x-MODEM-BC). These modems are optimum ready to use solution for ustomers of Ma hine to

Ma hine (M2M) appli ations. This module is based on Telit GL865 GSM/GPRS module. Calixto provides

optional battery harging feature for this modem (CST-GL86x-MODEM-BC).

Some key appli ation areas in lude:

• Industrial M2M ommuni ations

• Remote Monitoring and Control

• Point of Sale Terminals

• Metering

• Warehousing

• Logisti s and Freight Management

2. CST-GL86x-MODEM Features:

2.1 General features:

• Based on Telit GL86x GPRS module

o DUAL-Band EGSM 900 / 1800 MHz

o Embedded TCP/IP, FTP, SMTP

o Remote AT ommands

o Li ense free Python Engine

o Low power : 1.5mA @ Idle

• Wide power input range from 9 to 24 Volt

o Ideal for automotive appli ations.

• RS232 interfa e with DB9 onne tor

• Optional battery harger feature

o Ideal for remote monitoring

o Part number CST-GL86x-MODEM-BC

• Expansion onne tor with following interfa es of GL86x module

o Auxiliary UART

o 2 GPIOS

o 2 ANALOG inputs

o DAC Output

o Audio in and out signala

• Antenna onne tor options

o SMA and uFL options

• Dimension

o 47mm x 75 mm

3. Calixto CST-GL86x-MODEM ordering Info

3.1 Product Variants

There are two variants of the module available:

• Standard modem with Telit GL868 DUAL module: CST-GL868-MODEM

• CST-GL868-MODEM with battery harging interfa e: CST-GL868-MODEM-BC

Note: There is option for ustomers to order GL865 QUAD version of the modem. But, minimum order

quantity in this ase will be 100.

4. Product details

The figures below shows pi tures of CST-GL868-MODEM-BC with important omponents marked. SIM ard

holder is in the other side of the board as in se ond pi ture

5. Hardware Description

5.1 Telit GL86x module:

This modem implements all the fun tionalities in luding Digital/Analog out using Telit’s GL86x series of

GSM/GPRS module. Default version of the module is GL868 DUAL. For orders more than 100 lots, ustomers

have opportunity to order different versions of GL86x modules. This do ument is not in luding any details of

GL86x module. Customer an get more information from Telit web site for more information.

http://www.telit. om/en/produ ts/gsm-gprs.php?p_id=12&p_a =show&p=93

http://www.telit. om/en/produ ts/gsm-gprs.php?p_id=12&p_a =show&p=127

http://www.telit. om/en/produ ts/gsm-gprs.php?p_id=12&p_a =show&p=110

5.2 GPRS Antenna

Antenna onne tor allows transmission of radio frequen y (RF) signals between the modem and an external

ustomer-supplied antenna. Calixto provides option one of the two antenna onne tor options. One is uFL

and other one is 5050ΩFME male oaxial ja k. As an option Calixto provides WIP Antenna with 50ΩFME male

oaxial ja k onne tor.

5.3 Power Jac

The power Ja k supported is 2mm DC power ja k with lo king option. The figure below shows the power ja k

used in the modem.

5.4 LED Indications

There are two LEDs in the CST-GL868-MODEM. LED1 (at D1) is power LED and LED2 (at D6) is GPRS status LED.

For CST-GL868-MODEM-BC, there is an additional Charging Indi ator LED (D2).

5.5 Battery connector

CST-GL868-MODEM-BC modem has additional battery onne tor. This is a 2 pin Relimate onne tor (lo ation

B1).

5.6 RS232-DB9 (J2)

This DB9 onne tor has main UART of the GSM/GPRS module in RS232 level.

Pin No PIN Name Pin Type Signal Type Description

1 NC Not Conne ted

2 TXD O RS232 Transmit Data of RS232

3 RxD I RS232 Re eption Data for UART

4 NC Not Conne ted

5 GND Gnd Ground

6 NC Not Conne ted

7 CTS O RS232 Clear to Send

8 RTS I Request to Send

9 NC Not Conne ted

5.7 Expansion Connector Slot (J7)

Pin No PIN Name Pin Type Signal Type Description

VCC_3V8D

Power

3.8V supply (to use outside)

2 VCC_3V8D Power 3.8V Supply (to use outside)

GSM_EAR-

AO Audio Earphone Signal out, Phase-

GSM_EAR+

AO Audio Earphone Signal Out, Phase+

ADC1

ADC ADC Input1

ADC2

AI ADC ADC Input2

GSM_MIC-

Audio

Mi Signal In, Phase-

GSM_MIC+

Audio Mi Signal In, Phase+

DAC_OUT

AO D/A Digital to Analog onverter from

module

10 GSM_GPIO_7

I/O CMOS 2.8V GPIO 7 or Buzzer from GL86x

GSM_GPIO_6

I/O CMOS 2.8V GPIO 6 or ALARM from GL86x

AUX_UART_TXD

O CMOS 2.8V Module Aux UART transmit(

AUX_UART_RXD

I CMOS 2.8V Not Conne ted

GND

Gnd Digital Ground

6. Electrical and Environmental Specification

Parameter

Min

Max

Input Power Supply

Operating Temperature

+70

Relative humidity

Operational

10%

90%

7. Communicating with Modem

7.1 Serial Interface mechanism

Customers an interfa e the modem through main (DB9 Conne tor). Following are the serial interfa e format

used in Calixto GL86x modem in below figure:

The CST-GL868-MODEM is built around Telit GL86x module. Customers an follow all the programing

me hanism suggested by Telit.
