User Guide

1. Check Box Contents

(i) Call Saint Nuisance Call Blocker

(ii) Call Saint Nuisance Call Blocker stand

(iii) Cable 1 (short cable): 15cm / RJ11 to BT socket adaptor

(iv) Cable 2 (long cable): 300cm / RJ11 to BT socket cable

The Call Saint Nuisance Call Blocker is powered by the phone line. No

plugs or batteries are required.

2. Plug In

Refer to the Quick Setup Guide (with images) or use the instructions below.

without ADSL Micro-filter…

Step 1

Plug the short cable supplied (RJ11 male to BT female) into the socket

marked “TO PHONE” (left socket) on the call blocker

Step 2

Unplug your telephone line cable from your telephone wall socket.

Step 3

Plug your telephone line cable into the other end of the short cable.

Step 4

Plug the long cable supplied (RJ11 male to BT male) into your telephone

wall socket.

Step 5

Plug the other end of the long cable into the socket marked “TO LINE”

(right socket) on the call blocker

Page | 2

User Guide

Step 6

Wait for your Call Saint Nuisance Call Blocker screen to turn on.

Step 7

Check you can hear a dial tone on your telephone (if you are using a

cordless telephone, press the green telephone button).

Your Call Saint Nuisance Call Blocker is now ready to use.

IMPORTANT:

The Call Saint Nuisance Call Blocker will only work if you subscribe to a

Caller ID service from your phone line provider.

with ADSL Micro-filter…

Step 1

Plug the short cable supplied (RJ11 male to BT female) into the socket

marked “TO PHONE” (left socket) on the call blocker

Step 2

Unplug your telephone line cable from your ADSL Microfilter (leave the

filter connected to the telephone socket on the wall)

Step 3

Plug your telephone line cable into the other end of the short cable.

Step 4

Plug the long cable supplied (RJ11 male to BT male) into your ADSL

Microfilter.

Step 5

Plug the other end of the long cable into the socket marked “TO LINE”

(right socket) on the call blocker

Step 6

Wait for your Call Saint Nuisance Call Blocker screen to turn on

Page | 3

User Guide

Step 7

Check you can hear a dial tone on your telephone (if you are using a

cordless telephone, press the green telephone button).

Your Call Saint Nuisance Call Blocker is now ready to use.

IMPORTANT:

The Call Saint Nuisance Call Blocker will only work if you subscribe to a

Caller ID service from your phone line provider.

3. Set Up

Setting the date and time

The date and time will set automatically after you receive your first call but you

will need to change the year manually. The instructions below explain how to

change the year, date and time manually.

Press “SET” on the call blocker. The screen will display “SET 1234567”

Pick up your telephone so you can hear a dial tone (if you are using a

cordless telephone, press the green telephone button)

Press “1” on your telephone

The screen on the call blocker will display “2012” and the third digit

will be flashing “2012”

Hang up your telephone

Press “SET” on the call blocker and the fourth digit will start flashing

“2012”

Use the and buttons on the call blocker to select the correct year

then press “SET”

The digit to the left of the letter “M” will start flashing.

Use the and buttons on the call blocker to select the correct

month (e.g 1=Jan, 2=Feb, 3=Mar, etc…) then press “SET”

The digit to the left of the letter “D” will start flashing

Page | 4

User Guide

Use the and buttons on the call blocker to select the correct day

of the month and then press “SET”

Use the and to set the hours of the time (24 hour format) then

press “SET”

Use the and to set the minutes of the time then press “SET”

You have now finished setting the year, date and time. The day of the

week will set automatically.

Adjusting the screen brightness

The default screen brightness level is set at 2.

Press “SET” on the call blocker. The screen will display “SET 1234567”

Pick up your telephone so you can hear a dial tone (if you are using a

cordless telephone, press the green telephone button)

Press “2” on your telephone

The screen on the call blocker will display “LCD 2”

Hang up your telephone

Use the and buttons on the call blocker to adjust the screen

brightness level between 1, 2, 3 and 4 then press “SET”

You have now finished adjusting the screen brightness.

View list of calls made (last 50 calls made)

Press “OUT” on the call blocker

Use the and buttons on the call blocker to view the list of calls

made

The call blocker will display the number dialled

The duration of the call will appear above the number dialled

The number displayed in the top right of the screen shows the number

of calls made

Page | 5

User Guide

Press “REMOVE” on the call blocker if you want to delete the number

from the list (to remove all numbers from the list press “REMOVE” on

the call blocker and keep it pressed until the screen displays “NO

CODE”)

“NO CODE” will appear if no calls have been made

“-END-“ will appear when you have viewed the complete list of calls

made

Press “SET” to exit viewing the list of calls made

block a number from the calls made list…

Press “OUT” on the call blocker

Use the and buttons on the call blocker to view the list of calls

made

The call blocker will display the number dialled

Press “BLACKLIST” on the call blocker if you want to block the number

The screen will display “SAVE” and then “SUCCEED”

Use the and buttons on the call blocker to continue viewing the

list of calls made

Block outgoing calls (up to 100 numbers)

Press “SET” on the call blocker. The screen will display “SET 1234567”

Pick up your telephone so you can hear a dial tone (if you are using a

cordless telephone, press the green telephone button)

Press “3” on your telephone

The screen on the call blocker will display the last outgoing number

that was blocked. If no outgoing numbers have been blocked no

number will appear

Press “*” (star button) on your telephone (ignore any messages you

hear on your telephone)

Page | 6

User Guide

Enter the number you want to block on your telephone. The number

will be displayed on the call blocker screen

Press the button on the call blocker to save the number

The screen will display “SAVE” and then “SUCCEED”

Hang up your telephone and press “SET” on the call blocker if you

have finished or you can add another number

add another number…

Press “*” (star button) on your telephone

Enter the number you want to block on your telephone. The number

will be displayed on the call blocker screen

Press the button on the call blocker to save the number

The screen will display “SAVE” and then “SUCCEED”

Hang up your telephone and press “SET” on the call blocker if you

have finished or you can add another number

Unblock outgoing calls

Press “BLACKLIST” on the call blocker and keep it pressed until the

screen displays the last outgoing number that was blocked

Use the and buttons on the call blocker to find the number you

want to unblock

Press “REMOVE” on the call blocker

The screen will display “DEL”

The number is removed from the blocked caller list

Page | 7

User Guide

unblock all numbers from the blocked outgoing caller list…

Press “BLACKLIST” on the call blocker and keep it pressed until the

screen displays the last outgoing number that was blocked

Press “REMOVE” on the call blocker and keep it pressed until the

screen displays “PASS” –you will be required to enter your PIN (the

default PIN is “0000”)

All numbers will be removed from the blocked caller list

Press “SET” on the blocker to exit unblocking outgoing calls

View list of calls received (last 100 calls received)

“NEW” will flash on the call blocker screen after you have received a

call

Use the and buttons on the call blocker to view the list of calls

received

The call blocker will display the caller’s telephone number, the date

and the time they called. The number displayed in the top right of the

screen shows the number of calls received

Press “REMOVE” on the call blocker if you want to delete the number

from the list (to remove all numbers from the list press “REMOVE” on

the call blocker and keep it pressed until the screen displays “NO

CODE”)

“NO CODE” will appear if no calls have been received

“NEW” will appear above the caller’s telephone number if it is a new

caller

“REP” will appear above the caller’s telephone number if the caller has

called before

“ “ (padlock icon) will appear above the caller’s telephone number if

the telephone number is on your blocked caller list

“- -P- -“ will appear for a caller who withholds their number

Page | 8

User Guide

“-END-“ will appear when you have viewed the complete list of calls

received

Press “SET” to exit viewing the list of calls received

Block incoming calls (up to 1200 numbers)

One-Touch Call Blocking: block a number from the calls received list…

One-Touch Call Blocking cannot be used to block withheld numbers.

Details on how to block withheld numbers can be found further on in the

User Guide.

Use the and buttons on the call blocker to view the list of calls

received

The call blocker will display the caller’s telephone number, the date

and the time they called

Press “BLACKLIST” on the call blocker if you want to block the number

The screen will display “SAVE” and then “SUCCEED”

Use the and buttons on the call blocker to continue viewing the

list of calls received

One-Touch Call Blocking: block a number without answering the

telephone…

One-Touch Call Blocking cannot be used to block withheld numbers.

Details on how to block withheld numbers can be found further on in the

User Guide.

When you receive a call, the screen on the call blocker will display the

number of the caller

To block the caller without answering your telephone, press

“BLACKLIST” on the call blocker

The screen will display “SAVE” and then “SUCCEED”

The caller is disconnected and their number is blocked

Page | 9

User Guide

Block a number during a call using your telephone…

This feature allows you to block a number during a call using your

telephone. This feature cannot be used to block withheld numbers.

Details on how to block withheld numbers can be found further on in the

User Guide.

To block a caller during a call, press “*” (star button) on your

telephone

Hang up your telephone

The call blocker screen will display “SAVE” and then “SUCCEED”

The caller’s number is blocked

add numbers yourself to the blocked caller list…

Press “SET” on the call blocker. The screen will display “SET 1234567”

Pick up your telephone so you can hear a dial tone (if you are using a

cordless telephone, press the green telephone button)

Press “4” on your telephone

The screen on the call blocker will display the last incoming number

that was blocked. If no incoming numbers have been blocked no

number will appear

Press “*” (star button) on your telephone (ignore any messages you

hear on your telephone)

Enter the number you want to block on your telephone. The number

will be displayed on the call blocker screen

Press the button on the call blocker to save the number

The screen will display “SAVE” and then “SUCCEED”

Hang up your telephone and press “SET” on the call blocker if you

have finished or you can add another number

Page | 10

User Guide

add another number…

Press “*” (star button) on your telephone

Enter the number you want to block on your telephone. The number

will be displayed on the call blocker screen

Press the button on the call blocker to save the number

The screen will display “SAVE” and then “SUCCEED”

Hang up your telephone and press “SET” on the call blocker if you

have finished or you can add another number

Unblock incoming calls

Press “BLACKLIST” on the call blocker. The screen will display the last

number that was blocked

Hang up your telephone

Use the and buttons on the call blocker to find the number you

want to unblock

Press “REMOVE” on the call blocker

The screen will display “DEL”

The number is removed from the blocked caller list

unblock all numbers from the blocked incoming caller list…

Press “BLACKLIST” on the call blocker. The screen will display the last

number that was blocked

Press “REMOVE” on the call blocker and keep it pressed until the

screen displays “PASS” –you will be required to enter your PIN (the

default PIN is “0000”)

All numbers will be removed from the blocked caller list

Press “SET” on the blocker to exit unblocking outgoing calls

Inhaltsverzeichnis

Andere Call Saint Telefonzubehör Handbücher

Call Saint

Call Saint TM-PA009B Bedienungsanleitung

Beliebte Telefonzubehör Handbücher anderer Marken

IAI

IAI CON-T Bedienungsanleitung

BT DIVERSE 5400 Bedienungsanleitung

Tadiran Telecom

Tadiran Telecom EMERALD ICE Bedienungsanleitung

Musicam

Musicam FieldFone II Bedienungsanleitung

Polycom

Polycom KIRK KIRK 4040 Technisches Datenblatt

TIPTEL

TIPTEL DECT Set 50 Bedienungsanleitung

Panasonic

Panasonic KX-UDS124 Bedienungsanleitung

BT BT7600 Technisches Datenblatt

Panasonic

Panasonic KX-TVP100E Bedienungsanleitung

View

View VP-PC Bedienungsanleitung

Baldwin Boxall

Baldwin Boxall BT8 Bedienungsanleitung

SMC Networks

SMC Networks SMCDPCR-AP Bedienungsanleitung

SkyLink

SkyLink SD-001 Bedienungsanleitung

Nera

Nera ISDN Bedienungsanleitung

MCheeta

MCheeta CT-CID803 Plus Bedienungsanleitung

YASKAWA

YASKAWA YRC1000 Bedienungsanleitung

Intellitouch

Intellitouch MOH-500E Bedienungsanleitung

Viking

Viking SQRG-12 Gebrauchsanweisung
