Calyx AL Bedienungsanleitung
User’s Manual
www.calyxamp.com
※ This manual may have some differences depending on the version of the product.
Calyx AL
2-Way Powered
Speaker System
for Music lovers like you
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -2-
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -3-
CONTENTS
1. INTRODUCTION .............................................................4
2. UNPACKING ...................................................................5
3. IMPORTANT SAFETY INSTRUCTIONS ........................6
4. INSTALLATION ..............................................................7
6. TROUBLE-SHOOTING .................................................12
7. SPECIFICATIONS .........................................................13
8. WARRANTY ..................................................................14
BACK VIEW
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -4-
1. Introduction
Music is the most important messenger of human emotion as well as a meaning of its expression
since human beings appeared on this earth. Music created by amazing inspiration of many gifted
composers makes people moved and our normal lives enriched.
The absolute sound and real music performed in real space like concert halls are the most important
experience that makes people get to the musical essence. Besides, audio products re-producing
music are a way of modern civilization making our lives better.
Since 1999, the year of establishment, Digital & Analog Co., Ltd. (as known as D&A) has been
providing class-D I.C.s to various audio OEM companies. And D&A started to make its own high-end
audio products since 2008 and as a result, we succeeded to build audio products with excellent
measured performance which any other amplifiers were not able to reach so far. Calyx is the by-
product of such an effort based on D&A’s many experiences like designing, manufacturing and selling
of class-D ICs and supporting its customers to make their audio products using D&A’s I.C.s. Calyx
has been tested subjectively as well as objectively under a lot of test circumstances.
A great Chinese poet ‘Bai Ju Yi’ of the Tang Dynasty expressed sound as followings in on of his book;
“A poem has passion as its root, words as its buds, sound as its flower and meanings as its fruits”
So we named our products as Calyx, in the meaning of corolla of music described as flower by the
renowned poet.
Calyx will enrich your life as a strong support of musical flower. This coincides exactly with our
slogan;
“Technology making the world affluent.”
Calyx is high-end products, which you can be proud of possessing it.
Digital & Analog Co., Ltd.has developed class-D amplification technology with many patents on the
technology.
From now on, we provide high-end audio products to music lovers like you
Thanks and enjoy the music.
Seungmok Yi
CEO/President
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -5-
2. Unpacking
You will find in Calyx AL Speaker System Box :
<Calyx AL>
<RCA Cable> <Speaker Cable>
<AC Power Cord>
<Manual>
<High-density foam protector / Sonic isolation pads>
If, when you open the Calyx AL Speaker System Box, the item is damaged or missed, please contact
your dealer. (The AC power cord you see might be different to the real one.)
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -6-
3. Important Safety Instructions
Please take a moment to read these notes before installing your Calyx Speaker System, as they will
enable you to get the best performance and prolong the life of the unit.
As our engineers are striving for the constant research and development to develop the quality of products,
shape or structure of our model can be changed without previous notice.
※We advise you follow all instructions, heed all warnings and keep the instructions for future reference.
This symbol indicates that dangerous voltage
which can cause electric shock is present inside
this unit.
This symbol alerts you to important operating
and maintenance instructions accompanying the
unit.
This symbol means that this unit is doubled insulated. An earth connection is not required.
Do not overload outlets, extension cords or integral
convenience receptacles.
▶This can result in a risk of fire or electric shock.
Never touch the power cords or the unit with wet hands.
▶This can result electric shock.
Never use the frayed or damaged or cracked or broken
power cords.
▶This can result in a risk of fire or electric shock.
Do not expose the unit to rain or moisture. Do not use this
product near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement, near a swimming pool, or
anywhere else that water or moisture are present
▶This can result in a risk of fire or electric shock..
Do not expose the unit to direct sun radiation. Do not
install near any heat sources, such as radiators, heat
registers, stoves or other apparatus that produce heat.
▶This could lead to overheating and malfunction of the
unit.
During thunderstorms, disconnect the power cords from
the wall outlet.
▶Voltage peaks due to lightning could damage the unit.
Do not put any objects on top of the unit.
▶If the objects fall, it may cause harm to the user.
Do not move the unit, while it is powered on.
▶This can cause harm to the unit
Do not place the unit on an unstable surface or shelf.
▶If the unit falls, it may cause harm to the unit or to the
user.
Do not use attachments not recommended by your dealer
▶This may cause harm to the unit
To clean the unit, please follow next instructions.
▶Wipe its case with a dry, lint-free cloth.
Do not use any cleaning fluids containing alcohol,
ammonia or abrasives.
Do not spray an aerosol at or near the product.
Unplug this product from the wall outlet before
cleaning.
Do not listen to loud music for a long time.
▶This may cause harm to user’s hearing ability
Only Use attachments or accessories specified by the
manufacturer.
Do not block any ventilation openings. Install in accordance
with the manufacturer instructions. To ensure reliable
operation of the product and to protect it from Please
ensure there is ample ventilation. For example, do not place
the product on a bed, sofa, or similar surface that may block
the ventilation openings. Do not put it in a built-in system,
such as a bookcase or a cabinet that may keep air from
flowing through its ventilation openings.
Use proper power sources. Plug the product into a proper
power source, as described in the operating instructions or
as marked on the product.
Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
Servicing is required when the apparatus has been
damaged in any way such as power supply cord or plug is
damaged ; liquid has been spilled or objects have fallen into
the important safety instructions apparatus ; the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped. Do not attempt to service
this product yourself. Opening or removing covers may
expose you to dangerous voltages or other hazards.
※ If the product needs to repair, please contact the calyx service center.
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -7-
4. Installation
Before you begin installation, you should not make any connections to the Calyx AL Speaker system
or to any other component in your system whilst the AC power supply is connected and switched on.
<FRONT>
<REAR>
RIGHT SPEAKER
RIGHT SPEAKER
POWER LED
VOLUME
LEFT SPEAKER
OUT TO RIGHT
SPEAKER
SUB OUT
RCA INPUT
POWER
5V DC CHARGE
FOR iPOD
AC IN
LEFT SPEAKER
STEREO IN
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -8-
◆Connection
Step 1. SPEAKER WIRE CONNECTION
Connect the RED (+) and BLACK (-) terminals from the left speaker to the corresponding terminals
on the right speaker using a speaker wire. Be sure to match the red-colored side of the speaker wire
with the RED (+) terminals and the black-colored side to the BLACK (-) terminals on each speaker.
Note : As the Calyx AL Speaker system is self-powered, do not connect the speaker terminals to the
speaker outputs of a stereo receiver.
Detailed procedure :
●Remove the pre-cut insulation on the end of the speaker wire and twist the exposed wire strands
2-3times.
●Use your thumb and finger to unscrew the binding post connector.
●Insert each speaker wire into the holes on the side of binding post connector.
●Retighten the binding posts. The stripped wire portion should be secured firmly in the connector.
●Repeat the procedure to connect the other end of the speaker wire to the other speaker. Be sure
to match the wire color to the same terminal color on each speaker. Also make sure that none of
the speaker wire strands have come in contact with an adjoining terminal.
Step 2. POWER CABLE CONNECTION
Verify that the voltage selector switch is set to the proper voltage for your area.
Connect the power cord into the left speaker and the other end into the wall outlet.
Step 1
Step 2
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -9-
◆Configuration A (for use with iPod or portable players) :
A1. For charging your iPod (or the portable players) while playing, connect the 30-pin cable from the
iPod (or the portable players) to USB jack on the Combo port. Use a USB extender cable if extra
cable length is needed (for use on a desktop, for example).
A2. Connect the long 1/8”mini-jack audio cable from iPod (or the portable players) headphone jack
to the STEREO IN jack on the Combo port.
A1 A2
STEREO IN
USB CHARGE
BACK VIEW
Calyx AL 2-Way Powered Speaker System
Digital & Analog Co., Ltd. (Rev. 1.0) -10-
◆Configuration B (RCA outputs)
B1. Connect RCA INPUT L/R from any audio source with RCA L/R audio outputs.
B1
AUDIO OUTPUT
BACK VIEW
RCA INPUT
DVD
TV
CD / MP3 Player
