Installation manual

For Handi-Lift ML7

Original Version

Handi

Lift ML7

Page

Version

Table of content

1 Introduction .............................................................................................. 3

1.1 Check the parts and drawing .................................................................. 3

1.2 Electrical installation ............................................................................. 3

Forces on the building ................................................................................ 4

Install the tower ........................................................................................ 4

3.1 Tower positioning ................................................................................. 4

Installing the lift unit .................................................................................. 7

4.1 Attach the back frame to the tower ......................................................... 7

4.2 Connect the electrical ........................................................................... 8

4.3 Connect the platform to the back frame ................................................... 9

4.4 Connect the power ............................................................................. 10

4.5 Load cell adjustment ........................................................................... 11

4.6 Handicap symbol ................................................................................ 12

Filling oil ................................................................................................ 12

Final touch ............................................................................................. 13

Install the gate ........................................................................................ 14

Installation test certificate ......................................................................... 17

Declaration A .......................................................................................... 18

Handi

Lift ML7

Page

Version

1 Introduction

1.1 Check the parts and drawing

Before you start installing please read this installation manual.

Check the received parts for transport damage.

Next, study carefully the installation drawing that comes with the lift to ensure that all

dimensions are correct and corresponds to the installation site.

1.2 Electrical installation

If the drawing does not show where to install the Control boxes, please sort out where

they all go. Make sure that the electrical supply and electrical wiring for the Handi-Lift

are there before installing the tower and lift.

You need 1x230V with earth, 3x1,5 mm². The installation must be protected by a 10

Amp fuse and RCCB 30 mA. We recommend that you make a measurement of the

earth connection.

We recommend that you make a measurement of the earth connection.

Fig. 1

Handi

Lift ML7

Page

Version

Forces on the building

LOAD &

FORCES

2946N

1129N

2300mm.

770N

2000mm.

870N

1800mm.

960N

1700mm.

1050N

1500mm.

1120N

1450mm.

1190N

Fig. 2

The tower is fixed to the floor and to the wall with M10x90mm (Class 8.8) Glue bolts.

Two bolts in the wall and three in the floor.

The given load forces applies for the total force when two bolts are used both places.

Please make sure the wall and floor materials can withstand the given loads.

Install the tower

3.1 Tower positioning

The tower is the first component to install. Dependent on the quality and straightness

of the wall- and ground material, the tower placement may need corrections.

Handi

Lift ML7

Page

Version

Place the tower on the floor against the

wall.

Adjust the tower to be perpendicular to

the wall of the landing. (see fig. 3)

The distance between the centre of the

tower and the landing wall is given on the

installation drawing. You will also find the

distance labelled on the bottom face of

the tower.

The centre of the tower is clearly marked

with a “V” in the baseplate next to the

label (see fig. 3).

Fig. 3

Make sure the tower is in level (see fig. 4).

Fig. 4

Handi

Lift ML7

Page

Version

Finally, adjust the tower to be vertical in both directions before fixing

to the wall

and the floor, so the landing fits.

Mount the bolts in the wall with glue as described on the glue package.

Fasten the nuts.

Handi

Lift ML7

Page

Version

Installing the lift unit

4.1 Attach the back frame to the tower

Place the ba

ck frame of the lift on the floor

in front of the tower.

Fig.

Connectors and cables are put through the hole on both sides.

Fig. 6

Handi

Lift ML7

Page

Version

Position the back frame to the mounting holes of the carriage.

Fasten the back frame using the four screws and washers.

Fig. 7

4.2 Connect the electrical

Leave the lift carriage and back frame in the lower position of the tower. Place the

platform on the floor in front of the back frame.

Pull the cables and mount the connectors as shown below.

Fig.

left

Fig.

right

Handi

Lift ML7

Page

Version

Fig. 9a Fig. 9b

4.3 Connect the platform to the back frame

Mount the platform to the back

frame using

the two screws and nuts

(M12x160/M12x180).

If necessary, adjust the lower position of

the platform using the set screws.

Fig.

Plug the remote lead into the control board. Press the re-set button in order to start

up the system.

Fig. 11

Handi

Lift ML7

Page

Version

Now install the control boxes

Adjust the limit switches, as shown in the photo:

Fig. 12

4.4 Connect the power

Fig. 13

The wires are connected to the safety cut-out as follows:

L1 is connected to terminal 2
