Camon C6 Bedienungsanleitung
Rotavators
Models
C6 ·C8 ·C10 ·C13
with PowerSafe®Clutch
Operating Instructions
Before commissioning the machine, read operating instructions
and observe warning and safety instructions.
CAMON Rotavators
Page 2 PSR/AM/0912
Contents
Page 3 Safety
Page 4 Controls Diagrams - C6/C8 & C10
Page 5 Controls Diagrams - C13
Controls Description
Page 6 Assembly Instructions
Page 7 How to Start Petrol Engine
How to Start Diesel Engine
Page 8 Operation
How to Stop Engine
Page 9 Operating Hints
Page 10 Maintenance Guide
Page 11 Maintenance Programme
Page 12 Service Information
Page 14 Troubleshooting Guide
Page 15 Risk Assessment
Page 16 Service Record
Page 17 Warranty Registration
No liability will be accepted for any damage caused to persons or property
through failure to observe the operating and safety instructions.
!
IMPORTANT READ CAREFULLY
CAMON Rotavators
PSR/AM/0912 Page 3
Safety
ALWAYS start the engine in the open air
DO NOT smoke when refuelling
DO NOT mix OIL with the fuel
ALWAYS stop the engine before making any adjustments, refuelling, moving or
cleaning, or when the unit is unattended
USE ONLY fuel from containers designed for this purpose - refuel outdoors only and
replace the tank cap securely
IN CASE of petrol spillage move the machine away from the area of spillage and allow
the petrol vapours to dissipate before starting the engine
DO NOT remove any safety guards that are tted
DO NOT touch any moving parts or attempt any maintenance whilst the machine is
running - KEEP HANDS AND FEET AWAY
BEFORE starting work clear the work area of any objects that could damage the
machine
DO NOT allow children or anyone uninstructed to operate the machine - KEEP
ANIMALS AWAY
DO NOT use on slopes or banks of more than 20o
ALWAYS wear suitable clothing to give personal protection including footwear that
offers a good grip
AVOID wearing loose garments that may catch in moving parts
KNOW how to stop the machine in an emergency
NEVER interfere with any control settings on the engine
NEVER select reverse gear with your back to a wall or other immovable object
IF A FAULT develops DO NOT attempt any repair - immediately contact the supplier
from whom the machine was obtained
VISUALLY INSPECT the machine before use - ensure all tines, nuts and bolts are tight
and not worn or damaged and replace tines if necessary
KEEP IN MIND the operator is responsible for accidents or hazards occurring to people
or property
CAMON Rotavators
Page 4 PSR/AM/0912
Controls
A
C
B
N
F
E
D
G/H
A
C
B
N
F
E
D
G
H
L
M
C10
C6 & C8
CAMON Rotavators
PSR/AM/0912 Page 5
Controls
L
A
C
B
N
F
E
D
G
H
M
O
P
C13
(A) MACHINE STOP LEVER (red lever that stops the machine when released)
(B) ENGINE STOP LEVER
(C) CLUTCH CONTROL LEVER
(D) GEAR LEVER (the location of different gears are shown on the selector)
(E) PTO LEVER (there is a safety device that prevents engagement with reverse gear)
(F) THROTTLE LEVER
(G) HANDLEBAR HEIGHT ADJUSTMENT LEVER
(H) STEERING COLUMN SWIVEL LEVER
(L) FORWARD/REVERSE LEVER (always engage the clutch before engaging this lever)
(M) DIFFERENTIAL LOCK LEVER
(N) PARKING BRAKE LEVER
(O) RIGHT BRAKE LEVER
(P) LEFT BRAKE LEVER
Controls Description
CAMON Rotavators
Page 6 PSR/AM/0912
1. Remove the machine from its packing case.
2. Rotatethehandlebarstemtotheoperatingpositionandtthehandlebars-checkoperationand
routing of cables.
3. Fit the wheels, ensuring the correct rotation (see diagram A below) and check the tyre pressures
(20psi).
4. Fit the gearbox dipstick.
5. Assembletherearaponthediggingunitensuringthestickerlabelsareontheoutside(see
diagram B below) and attach the unit to the machine.
6. Check the engine oil level.
7. Follow the instructions in this Owner’s Manual to run the machine.
Assembly Instructions
Diagram A
Diagram B
CAMON Rotavators
PSR/AM/0912 Page 7
To Start Petrol Engine
Using the dipstick provided, check the engine oil level. Top up with 10w/40 oil if necessary.
Checkfuellevel.Onlyuseunleadedpetrolfromacleancontainer.Neverre-fuelwhentheengineis
hot or running. Leave 1” air space in the fuel tank.
Turn the fuel tap to ‘ON’ position, if the engine is cold set the choke lever to ‘ON’ position.
Beforestartingtheengineensurethegearlever(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply half throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Pull the recoil start handle gently until it engages then give it a good strong pull to start the engine.
When the engine has started, release the choke lever after a few seconds and return the throttle
lever (F) to idle position.
Lombardini Diesel Engines
Using the dipstick provided, check the engine oil
level. Top up with 10w/40 oil if necessary.
Check fuel level. Only use diesel from a clean
container.Neverre-fuelwhentheengineishot
or running.
Before starting the engine ensure the gear lever
(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply ¾ throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Pull the recoil start handle gently until it
engages then give it a good strong pull to start
the engine.
Once the engine has started return the throttle
lever (F) to idle position.
Yanmar Diesel Engines
Using the dipstick provided, check the engine oil
level. Top up with 10w/40 oil if necessary.
Check fuel level. Only use diesel from a clean
container.Neverre-fuelwhentheengineishot
or running.
Before starting the engine ensure the gear lever
(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply ¾ throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Press and hold the decompression lever on top
of the engine.
Pull recoil start handle gently until it engages
then, keeping the decompression lever
depressed,slowlypulltheengineover2-3times
to prime the engine.
Release the decompression lever and gently pull
over the engine until compression is felt.
Press, but do not hold, the decompression lever
and give the starter handle a good strong pull to
start the engine.
Once the engine has started return the throttle
lever (F) to idle position.
To Start Diesel Engines
CAMON Rotavators
Page 8 PSR/AM/0912
Operation
Use handlebar adjuster (G) to set handlebar height.
Hold the handlebar and pull up the clutch lever (C).
Depress the red stop lever (A) and select working speed 1 (D). NEVER select a higher wheel speed
for work.
Ensure forward/reverse lever is in forward position (L).
Engage drive to the digging knives by pushing the PTO lever (E) forward.
Release clutch lever (C) slowly and fully, keeping the red machine stop lever depressed as the
machine will stop if released.
Commence work.
Close the throttle (F).
Engage clutch lever (C).
Locate gear lever (D) in neutral position.
Disengage drive to the digging knives by pulling the PTO lever (E) backwards.
Release clutch lever (C).
Release the machine stop lever (A) completely.
Move the engine stop lever (B) to position O ‘STOP’.
WARNING: THE EXHAUST COVER MAY BE HOT - DO NOT TOUCH.
To Stop Engine
CAMON Rotavators
PSR/AM/0912 Page 9
Operating Hints
LET THE MACHINE DO THE WORK.
Excessive downward pressure on the handlebars may cause the machine to jump. Apply gentle
pressureandthemachinewillnditsowndiggingdepthaccordingtothetypeofground.Ifthe
ground is hard, position the depth adjuster centre knife on the top hole and make several passes
until the desired depth is achieved.
If the speed or digging knives lever does not engage immediately, release clutch lever slightly and
‘feelin’withtheengineontick-over.
Always pull in the clutch lever before engaging any gear, digging unit or changing forward/
reverse.
The clutch lever must be fully released when working. Do not operate the machine with the clutch
lever partially engaged as serious damage may occur.
DO NOT WORK ON SLOPES MORE THAN 20°
If working on a slope, work across the slope pointing the machine slightly uphill.
DO NOT ATTEMPT CULTIVATION ON:
(i) Frozen or waterlogged ground as this will destroy the soil structure resulting in poor future
drainage.
(ii) Ground that is covered with thick foliage or high grass. Remove it by cutting down.
CAMON Rotavators
Page 10 PSR/AM/0912
For engine maintenance please refer to engine manufacturers manual.
After every hour of operation stop the engine and remove the spark plug cap. Check engine oil
level (recommended oil SAE 10w/40).
Remove all foreign matter from the digging knives assembly e.g. wire, string, grass etc.
Replace the spark plug cap.
Do not turn the machine on its side for cleaning.
Before checking the oil level ensure the machine is level.
Remove the digging unit oil level plug and ensure the oil level is within 1½” of the hole, if
necessary top up with EP90 gear oil.
Remove the gearbox unit dipstick and ensure the oil reaches the top level mark, if necessary top
upwithAPIGL-580w/90gearoil(seepage13).
Maintenance Guide
