PC208W DATALOGGER SUPPORT SOFTWARE

INSTRUCTION MANUAL

REVISION: 4/01

This is a blank page.

License for Use

This software is protected by both United States copyright law and

international copyright treaty provisions. The installation and use of this

software constitutes an agreement to abide by the provisions of this license

agreement.

You may copy this software onto a computer to be used and you may make

archival copies of the software for the sole purpose of backing-up CAMPBELL

SCIENTIFIC, INC. software and protecting your investment from loss. This

software may not be sold, included or redistributed in any other software, or

altered in any way without prior written permission from Campbell Scientific.

All copyright notices and labeling must be left intact.

This software may be used by any number of people, and may be freely moved

from one computer location to another, so long as there is not a possibility of it

being used at one location while it's being used at another. The software, under

the terms of this license, cannot be used by two different people in two

different places at the same time.

Limited Warranty

CAMPBELL SCIENTIFIC, INC. warrants that the installation media on which

the accompanying computer software is recorded and the documentation

provided with it are free from physical defects in materials and workmanship

under normal use. CAMPBELL SCIENTIFIC, INC. warrants that the

computer software itself will perform substantially in accordance with the

specifications set forth in the instruction manual published by CAMPBELL

SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. warrants that the

software is compatible with computers running Microsoft Windows 3.1, 95, 98,

NT and 2000.

CAMPBELL SCIENTIFIC, INC. will either replace or correct any software

that does not perform substantially according to the specifications set forth in

the instruction manual with a corrected copy of the software or corrective code.

In the case of significant error in the installation media or documentation,

CAMPBELL SCIENTIFIC, INC. will correct errors without charge by

providing new media, addenda or substitute pages.

If CAMPBELL SCIENTIFIC, INC. is unable to replace defective media or

documentation, or if CAMPBELL SCIENTIFIC, INC. is unable to provide

corrected software or corrected documentation within a reasonable time,

CAMPBELL SCIENTIFIC, INC. will either replace the software with a

functionally similar program or refund the purchase price paid for the software.

The above warranties are made for ninety (90) days from the date of original

shipment.

CAMPBELL SCIENTIFIC, INC. does not warrant that the software will meet

licensee’s requirements or that the software or documentation are error free or

that the operation of the software will be uninterrupted. The warranty does not

cover any diskette or documentation that has been damaged or abused. The

software warranty does not cover any software that has been altered or changed

in any way by anyone other than CAMPBELL SCIENTIFIC, INC.

CAMPBELL SCIENTIFIC, INC. is not responsible for problems caused by

computer hardware, computer operating systems or the use of CAMPBELL

SCIENTIFIC, INC.’s software with non-CAMPBELL SCIENTIFIC, INC.

software.

ALL WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE ARE DISCLAIMED AND EXCLUDED.

CAMPBELL SCIENTIFIC, INC. SHALL NOT IN ANY CASE BE LIABLE

FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL, INDIRECT, OR

OTHER SIMILAR DAMAGES EVEN IF CAMPBELL SCIENTIFIC HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

CAMPBELL SCIENTIFIC, INC. IS NOT RESPONSIBLE FOR ANY COSTS

INCURRED AS A RESULT OF LOST PROFITS OR REVENUE, LOSS OF

USE OF THE SOFTWARE, LOSS OF DATA, COST OF RE-CREATING

LOST DATA, THE COST OF ANY SUBSTITUTE PROGRAM, CLAIMS

BY ANY PARTY OTHER THAN LICENSEE, OR FOR OTHER SIMILAR

COSTS.

LICENSEE’S SOLE AND EXCLUSIVE REMEDY IS SET FORTH IN THIS

LIMITED WARRANTY. CAMPBELL SCIENTIFIC, INC.’S AGGREGATE

LIABILITY ARISING FROM OR RELATING TO THIS AGREEMENT OR

THE SOFTWARE OR DOCUMENTATION (REGARDLESS OF THE

FORM OF ACTION; E.G., CONTRACT, TORT, COMPUTER

MALPRACTICE, FRAUD AND/OR OTHERWISE) IS LIMITED TO THE

PURCHASE PRICE PAID BY THE LICENSEE.

815 W. 1800 N.

Logan, UT 84321-1784

USA

Phone (435) 753-2342

FAX (435) 750-9540

www.campbellsci.com

Campbell Scientific Canada Corp.

11564 -149th Street

Edmonton, Alberta T5M 1W7

CANADA

Phone (780) 454-2505

FAX (780) 454-2655

Campbell Scientific Ltd.

Campbell Park

80 Hathern Road

Shepshed, Loughborough

LE12 9GX, U.K.

Phone +44 (0) 1509 601141

FAX +44 (0) 1509 601091

What's New!

PC208W 3.3 is being released to enhance Edlogw's programming capabilities

by adding new instructions:

•Instruction 126, Data Transfer to HDR GOES (CR510, CR10X, CR23X) -

Communication and control for our SAT HDR GOES transmitter.

•Instruction 127, HDR GOES Status (CR510, CR10X, CR23X) -

Diagnostic tool for SAT HDR GOES transmitter communication.

•Instruction 137, Pulse Width Modulation (CR23X) - Instruction to

generate a continuous pulse width on a control port.

In addition to these new instructions, an issue has been resolved that was seen

when using call-back over telephone modems. Some modems require a longer

power-down period after a call-back attempt to reset and return to a call-

waiting state. An improvement has been made in PC208W 3.3 to increase this

power-down period to help ensure that most modems will be reset properly

after call-back.

Note for Windows ME Users: Microsoft has confirmed a problem with its

Windows ME Internet Protocol Helper API component (Iphlpapi.dll) that can

result in an error message when a 16-bit program makes a call to the Winsock

connect() function. This problem affects PC208W. Refer to Microsoft's web

site at http://support.microsoft.com/support/kb/articles/Q279/8/66.ASP to

download a fix for this problem prior to running PC208W.

For Users Upgrading from PC208W 2.3 or earlier

If you are upgrading from PC208W 2.3 or earlier, you may also be interested

in some of the new features and improvements which were implemented in

PC208W 3.0, 3.1, and 3.2.

Changes in PC208W 3.2

PC208W 3.2 implements the ability to use TCP/IP communication protocol to

communicate with Campbell Scientific dataloggers. This version of software is

required to communicate with a datalogger over an Ethernet network (Internet

or Intranet) using Campbell Scientific's NL100/105 Network Link Interface.

Changes in PC208W 3.1

Setup

Scheduled data collection has been improved to better handle instances of

failed calls. Retry attempts are now synchronized with the original Calling

Interval to help prevent drift when in retry mode. This new feature is important

to those who have a critical time window during which calls should be made,

such as cell phone users who power their communication equipment only

during certain times of the day.

Connect

PC208W has been updated to include the improved telecommunications

commands supported by newer datalogger operating systems (see Note below).

These commands help to prevent ports or flags from being inadvertently

toggled to another state because of noisy communication links.

When PC208W connects to a datalogger, a command is sent to determine the

operating system in the datalogger. PC208W then sends the appropriate

commands for the datalogger's communications protocol. Integrity measures

with this newer protocol include error-checking of input locations and setting

ports and flags high or low (rather than toggling the ports or flags between

states as in older operating systems).

Edlog

Instructions have been added in support of some of the newer devices available

from Campbell Scientific: TDR100 Time Domain Reflectometer, SDM-CAN

CAN-bus interface, and the LI-COR 7500 Gas Analyzer.

Support has been added to the measurement instructions for the newer

datalogger operating systems which take advantage of Autoranging (see Note

below). With Autoranging, the datalogger tests and determines the correct

voltage range for the sensor being measured. Note that Autoranging can

significantly increase program execution time; therefore, it should be used with

caution. Refer to the Edlog help file or the datalogger User's Manual for

additional information.

Report

The runtime version of Split (Splitr) can now be run minimized from a

command line using the /H switch.

Storage Module Communication

Support has been added to SMS for the new 4M (SM4M) and 16M (SM16M)

storage modules. These modules store 2 million and 8 million data points,

respectively, and take advantage of Flash memory technology.

SMS now uses View to take a quick look at data stored on the module. Using

View, the user can print quick reports and select up to two elements for

graphing.

The features are available only in the following operating

systems:

CR10X Default OS Revision 10 and greater

CR10X Modbus OS Revision 06 and greater

CR10X Alert OS Revision 03 and greater

CR10X Toro OS Revision 03 and greater

CR510X OS (all options) Revision 03 and greater

CR23X OS (all options) Revision 07 and greater

Refer to the datalogger operator's manual for information on

accessing the *B mode to determine the datalogger's OS version

and revision number. Contact Campbell Scientific for upgrade

information if your datalogger does not support the required

features.

Changes in PC208W 3.0

Setup

Improved Modem Communication - Setting up remote communications is

easier with PC208W's new modem configurations. PC208W uses hardware

flow control, verbose result codes (looking for “CONNECT” back from the

modem rather than a number), and error correction which is consistent with the

newer, faster modems. Just pick your modem from a list, and you should be

ready to communicate. If your modem is not in the list, the default modem

will work in most instances.

If you used a custom modem string in a previous version of

PC208W, please refer to the special upgrade information

provided in Section 1.4, Installation.

User-determined FSA 2 Data File Names - PC208W now lets you specify

different names for data files from Final Storage Areas 1 and 2.

New Clock Offset - A clock offset feature has been added to make it easier to

set the datalogger time for different time zones or daylight savings.

Updated Scheduling Capability - Datalogger schedules can now be copied to

one or more datalogger stations. When you have one station's schedule set up,

simply click a button to apply those settings to other stations. This helps you

set up your data collection schedules in less time and with less effort.

Datalogger Call-back - If you use call-back with your dataloggers, you’ll

notice that PC208W automatically tries to initialize the COM port. Check the

Help on “Call-back” for details on properly setting up the network.

Connect

New Numeric Monitor - The Numeric Monitor is now a stand-alone window

that is opened separately from the other Connect screen views. This 17-column

NOTE

by 15-cell display has room for assigning 254 input locations. It can be sized to

view one to four columns (up to 60 input locations) at one time. This new

design allows you to monitor your real-time data with a small screen while

minimizing the rest of PC208W so you can work on other tasks.

Enhanced Graphing Capability - You can now save any of the three real-

time graphs to disk in a WMF (Windows metafile) format for printing or

importing into other programs.

View

New Graphing Capability - View now plots up to two array elements on one

graph. This is especially useful to quickly identify potential problems in your

data (or sensors) either in the field or office. Use the zoom feature for a closer

look at the graph, or click on a data point to display its numeric value.

Enhanced Ease of Use - Graphical icons have been added to the user interface

for easier and more efficient use of the program. For instance, you can view

your data in comma separated, columnar, or hexadecimal format just by

clicking a button.

Enhanced Printing Capability - You can now preview your data or graph

before printing. Headings have been added to the printed page for quicker

identification of printed data. Margins can be adjusted by entering numerical

values or by simply "dragging" them in Print Preview mode.

Report

Start Offsets - A negative value can now be entered as an offset on the Input

File tab. This directs Split to begin reading X bytes from the end of the file

(positive values begin reading from the beginning of the file). This makes

using the time sync functions to process the tail end of a data file much faster

when that data file is very large.

SplitR - Multiple copies of SplitR, the command-line version of Split, can be

run at once using the /M switch.

New Start-up Feature!

Command Line Capabilities - Command line arguments can be entered from

a Windows command prompt or Windows short cut to open PC208W and

perform a specific task automatically. Collecting data, setting the clock,

invoking the Numeric Monitor or graphs, and toggling ports or flags can all be

accomplished using command line arguments. Administrators can set up

complex tasks for associates to run without training them on the entire

package.

You can find a comprehensive list of these command line entries in the Help

(search for “command line”) and in Section 1.5 of this manual.

Inhaltsverzeichnis

Andere Campbell Software Handbücher

Campbell

Campbell PC208 Bedienungsanleitung

Campbell

Campbell BMP5 Direct SDK Bedienungsanleitung

Campbell

Campbell PONDVIEW 4.0 Bedienungsanleitung

Campbell

Campbell PC400 Bedienungsanleitung

Campbell

Campbell LoggerNet Bedienungsanleitung

Campbell

Campbell Baler Bedienungsanleitung

Campbell

Campbell CSIOPC Bedienungsanleitung

Campbell

Campbell RTDM Bedienungsanleitung

Campbell

Campbell PCCONNECTCE Bedienungsanleitung

Beliebte Software Handbücher anderer Marken

COMPRO

COMPRO COMPROFM Bedienungsanleitung

Muratec

Muratec OFFICEBRIDGE ONLINE Bedienungsanleitung

Oracle

Oracle Contact Center Anywhere 8.1 Bedienungsanleitung

Adobe

Adobe 65007312 - Photoshop Lightroom Handbuch

Avaya

Avaya NULL One-X for RIM Blackberry Bedienungsanleitung

HP ProLiant BL420c Bedienungsanleitung

PS Audio

PS Audio PowerPlay Betriebsanleitung

Brady

Brady LOCKOUT PRO 3.0 Service-Handbuch

Avaya

Avaya Interaction Center Bedienungsanleitung

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Handbuch

Novell

Novell GROUPWISE 8 - INTERNET AGENT Bedienungsanleitung

Oracle

Oracle Application 9i Bedienungsanleitung

Acer

Acer RDM Bedienungsanleitung

Canon

Canon Vixia HF21 Bedienungsanleitung

Canon

Canon ZR950 Bedienungsanleitung

Samsung

Samsung Auto Backup Bedienungsanleitung

Polycom

Polycom Vortex EF2201 Montage- und Bedienungsanleitung

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Bedienungsanleitung
