BCO-1000-J1900 lUser’s Manual
10
1.1.1 Key Features
⚫Intel® Celeron® processor J1900, up to 2.0GHz
⚫1x 204-pin DDR3L SODIMM. max up to 8GB
⚫Dual independent display supported by 1x DVI-I (BCO-1000, BCO-1010, BCO-1010B, BCO-1010U,
and BCO-1020D Only)
⚫Dual independent display supported by 1x DVI-I and 1x DisplayPort
⚫2x Intel® GbE supporting Wake-on-LAN and PXE
⚫1x mSATA (BCO-1000 Only)
⚫1x 2.5” SATA HDD bay, 1x mSATA
⚫2x full-size mini PCIe for communication or expansion modules, 1x SIM socket
⚫2x RS-232/422/485, 1x USB 3.0, 3x USB 2.0
⚫2x RS-232/422/485, 1x USB 3.0, 7x USB 2.0 (BCO-1010U Only)
⚫4x RS-232/422/485, 1x USB 3.0, 3x USB 2.0 (BCO-1010B and BCO-1020C Only)
⚫6x RS-232/422/485, 1x USB 3.0, 3x USB 2.0 (BCO-1020D and BCO-1030 Only)
⚫4x DI + 4x DO with isolation (BCO-1010A, BCO-1020C, and BCO-1030 Only)
⚫9 to 30VDC wide range power input supporting AT/ATX mode
⚫-20°C to 50°C extended operating temperature
1.1 Overview
BCO-1000 series powered by Intel® Celeron® Processor J1900 2.0GHz SoC, which delivers increased performance by up to
150% compared to previous Atom® platforms and low power consumption. The BCO-1000 series is compatible for
applications that need a basic and simple but dependable solution. It is an ideal preference as an economical entry-level for
diverse applications in computing functionality such as market application in industrial automation, industrial control, Kiosk &
retail and digital signage.
This price-friendly fanless embedded system supports system memory up to 8 GB with one DDR3L-1066/1333 SO-DIMM
socket and features an onboard DVI-I display interface to provide further VGA/DVI-D connection to deliver Ultra HD smooth
visual display. The BCO-1000 series is equipped with one internal 2.5” SATA HDD bays and one mSATA (shared by 1x Mini PCI
Express) to provide sufficient storage. It also comes with one full-size mini PCIe socket with USIM socket (PCIe + USB + SATA)
that satisfy customized needs. Its rich I/O connectors (up to 6x COM, 2x LAN, 8x USB) provide versatile I/O expandability.
In addition to its efficient CPU computing performance, the BCO-1000 series can be configured through its two antenna for
wireless communication. It adopts a wide range power input from 9V to 30V DC, increasing the reliability of the whole system
dramatically. Furthermore, the BCO-1000 series is designed to operate dependably in critical conditions with its anti-vibration,
anti-shock and wide operating ranging from -20°C to 50°C temperature range features. The built-in over voltage protection
(OVP) makes the BCO-1000 series a safe and secure system for all industrial applications.
The BCO-1000 series is housed in a sturdy and rugged housing that makes it feel exceptionally solid. By complying with
military grade endurance (MIL-STD-810G), the BCO-1000 series is designed to withstand significant shock, constant vibration,
and sealed to survive the harshest environments or conditions. The neat and compact design facilitates easy integration,
effortless expansion and trouble-free maintenance.
The BCO-1000 series is very competitive with its affordable price, but without compromising on performance. It is an optimal
solution to fit in various type of interface and variety of applications that requires low cost high performance fanless
computing. Aside from its rich I/O capabilities, the robust package of BCO-1000 series makes it an ideal choice for a cost-
effective, high performance fanless embedded system.
Chapter 1: Product Introductions
BCO-1000 BCO-1010
BCO-1010A
BCO-1010B
BCO-1010U
BCO-1020C
BCO-1020D BCO-1030
