CIC60

Reverse Action

User Instructions

05651181 25/6/01 8:32 pm Page 1

Safety reminders

User’s manual. This machine should only

be used for its intended purpose as

described in this manual. Ensure that it is

fully understood before operating.

Installation. This machine should not be

installed in a bathroom or shower room.

Never install the dryer against curtains

and be sure to prevent items from falling

behind or collecting beneath the dryer. If

the floor is carpeted stand the machine on

a piece of hardboard.

Ventilation. Check regularly that the air

flowing through the dryer is not restricted:

Check the fluff filter after use, and clean,

if necessary.

The inlets and outlets should be kept free

from obstructions.

If the dryer is used frequently the period

between checks should be reduced

accordingly.

Water container. Empty the container

after every drying cycle. Use both hands

when carrying a full water container.

Dryness. Clothes should be spin dried or

thoroughly wrung before they are put into

the tumble dryer. Clothes that are dripping

wet should NOT be put into the dryer.

Lighters and matches must not be left in

pockets and NEVER use flammable

liquids near the machine.

Foam plastic, foam rubber and rubber-

like material are not suitable for tumble

drying. Articles made from these

materials MUST NOT be placed in the

dryer.

Glass fibre curtains should never be put

in this machine. Skin irritation may occur

if other garments are contaminated with

the glass fibres.

Garments treated with flammable

cleaning sprays or liquids such as petrol,

must not be put in this machine.

Lint or fluff must not be allowed to

collect on the floor around the outside or

beneath the machine.

Cool down period. The drum inside may

be very hot. Always allow the dryer to

complete the cool down period before

removing the laundry.

Faults. Do not continue to use this

machine if it appears to be faulty.

After use. Remove the plug from the

electricity supply. Always remove the

plug before cleaning the appliance.

Supply cord. If the supply cord on this

appliance is damaged, it must be replaced

by a special cord which is only available

from GIAS Service or an authorised

Dealer.

GIAS Service. To ensure the continued

safe and efficient operation of this

appliance we recommend that any

servicing or repairs are only carried out

by an authorised GIAS service engineer.

05651181 25/6/01 8:33 pm Page 2

Installation

Before using the tumble dryer for the

first time:

●please read this instruction book

thoroughly.

●remove all items packed inside drum.

●wipe the inside of the drum and door

with a damp cloth to remove any dust

which may have settled in transit.

IMPORTANT: This dryer must only be

used for drying household textiles and

garments where a water solution has

been used for the cleaning process.

DO NOT tumble dry fabrics treated

with dry cleaning fluids.

Electrical requirements

This appliance is fitted with a moulded-on

non-rewireable plug (in the UK fitted with

a 13 Amp fuse).

The plug should be accessible for

disconnection after the appliance has been

installed.

WARNING!

ELECTRICITY CAN BE

EXTREMELY DANGEROUS.

THIS APPLIANCE MUST BE

EARTHED.

IMPORTANT: The wires in the mains

lead are coloured in accordance with the

following code:

Blue - NEUTRAL

Brown - LIVE

Green-and-yellow - EARTH

If the supply cord on this appliance is

damaged, it must be replaced by a special

cord which is only available from GIAS

Service or an authorised Dealer.

Contents

Safety reminder 2

Electrical requirements 3

Installation requirements 4

Preparing the load 4

Clothes preparation 4

Maximum drying weight 4

Sorting the load 4

Do not tumble dry 5

Energy saving 5

Opening the door 5

Filter 6

Water container 6

Condenser 7

Drying guide 8

Controls & indicators 8

Operation 9

Cleaning the dryer 10

Technical specifications 10

Troubleshooting 11

05651181 25/6/01 8:33 pm Page 3

Installation

Installation requirements

IMPORTANT: This dryer must be

installed such that the air inlets and

outlets are not restricted (fig. 1).

There should be a gap of at least 12mm

(0.5 inches) between the sides rear and base

of the machine and the surrounding walls,

cabinets and floor.

To ensure adequate ventilation the space

between the bottom of the machine and the

floor must not be obstructed.

NEVER install the dryer up against

curtains.

Prevent items from falling or collecting

behind and beneath the dryer as these may

obstruct the air inlets and outlets.

Preparing the load

Before using the dryer for the first time

wipe the inside of the drum and door with a

damp cloth.

Make sure that the laundry you are going to

dry is suitable for drying in a tumble dryer,

as shown by the care symbols on each item.

Clothes preparation

Check that all fastenings are closed and that

pockets are empty. Turn the articles inside

out. Place clothes loosely in the drum to

make sure that they don’t get tangled.

Do not overload the drum, particularly

when drying large items, otherwise, the

laundry may stick to the drum and not dry

evenly.

Maximum drying weight

●Cottons Max. 6 kg

●Synthetics Max. 3 kg

Sort the load as follows:

A) By care symbols

On the collar or inside seam:

Suitable for tumble drying.

Tumble drying at high temperature.

Tumble drying at low temperature only.

Do not tumble dry.

B) By amount and thickness

Whenever the load is bigger than the

dryer capacity, separate clothes

according to thickness (e.g. towels from

thin underwear).

C) By type of fabric

Cottons/linen: Towels, cotton jersey,

bed and table linen.

AIR INLET

VENTS

SUPPLY CORD

AIR OUTLETS

IN BASE

Preparing the load

05651181 25/6/01 8:33 pm Page 4

Synthetics: Blouses, shirts, overalls, etc.

made of polyester or polyamid, as well

as for cotton/synthetic mixes.

D) By drying level

●Sort into: iron dry, cupboard dry, etc.

●For delicate articles press the ‘HEAT

SETTING’ button to select low drying

temperature.

Do not tumble dry:

Woollens, silk, delicate fabrics, nylon

stockings, delicate embroidery, fabrics with

metallic decorations, garments with PVC or

leather trimmings, training shoes, bulky

items such as sleeping bags, etc.

IMPORTANT: Do not dry articles which

have been treated with a dry cleaning

fluid or rubber clothes (danger of fire or

explosion).

Energy saving

Only put into the tumble dryer laundry

which has been thoroughly wrung or spin-

dried. The drier the laundry the shorter the

drying time thus saving electricity.

ALWAYS try to dry the maximum weight

of laundry, this will save time and

electricity.

NEVER exceed the maximum weight, this

will waste time and electricity.

ALWAYS check that the filter is clean

before every drying cycle as this aids

efficiency.

NEVER put dripping wet items into the

tumble dryer, this may damage the

appliance and waste time and efficiency.

Preparing the load Door

Opening the door

The door may be opened by pushing on the

textured panel of the door (fig 2). This is a

safety feature to prevent the entrapment of

minors in the drum.

To restart the dryer, close the door and

press the ‘ON’ button.

WARNING!

WHEN THE TUMBLE DRYER IS

IN USE THE DRUM AND DOOR

MAY BE VERY HOT.

05651181 25/6/01 8:33 pm Page 5

Filter Water container

Filter

IMPORTANT: To maintain the efficiency

of the dryer check that the fluff filter is

clean before each drying cycle.

Water Container

The water removed from the laundry

during the drying cycle is collected in a

container at the bottom of the dryer.

When the container is full the ‘EMPTY

WATER’ indicator on the control panel will

light, and the container MUST be emptied.

However, we recommend that the container

is emptied after each drying cycle.

NOTE: Very little water will collect during

the first few cycles of a new machine as an

internal reservoir is filled first.

To remove the container:

1. Gently pull the bottom of the kickplate

so that it unclips from the dryer. The top

section can then be unhinged allowing

the kickplate to be completely removed

(fig. 4).

2. Pull firmly on the handgrip and slide the

water container out of the dryer (fig. 5).

1. Gently remove lint using a soft brush or

your fingertips (fig 3).

Clean Filter Indicator lights when the

filter needs cleaning. If the laundry is not

drying check that the filter is not clogged.

05651181 25/6/01 8:33 pm Page 6

Condenser

Support the container with both hands.

When full, the water container will

weigh about 4kg (fig. 6).

3. Open the lid located on the top of the

container and empty the water (fig. 7).

4. Refit the lid and slide the water

container back into position. PUSH

FIRMLY INTO PLACE.

5. Refit the kickplate by engaging the

hinges at the top and ‘snapping’ the

lower clips into place.

Condenser

IMPORTANT: Always switch off and

remove the plug from the electricity

supply before cleaning the condenser.

To maintain the efficiency of the dryer

regularly check that the condenser is

clean.

To remove the condenser:

1. Remove the kickplate (fig. 4).

2. Turn the two locking levers anti-

clockwise (fig. 8).

3. Pull out the condenser unit (fig. 9).

4. Gently remove any dust or fluff with a

cloth, then wash the unit by holding it

under a running tap (fig. 10) turning it

so that water flows between the plates,

to remove any dust or fluff.

5. Refit the condenser ensuring it is

pushed firmly into place. Lock the two

levers by turning them clockwise.

6. Refit the kickplate.

05651181 25/6/01 8:33 pm Page 7

Drying guide Controls and indicators

Control panel and indicator lights

Drying guide

The table shows approximate drying times, depending on the type of fabric and dampness

of the clothes.

REMEMBER: During the last 15 minutes the load is always tumbled in cool air.

120-135 Min

70-85 Min

50-65 Min

70-80 Min

55-65 Min

40-50 Min

50-65 Min

40-55 Min

30-40 Min

HIGH

LOW

COTTON

SYNTHETICS

ACRYLIC

LIGHT LOADMEDIUM LOADHEAVY LOADHEAT SETTING

05651181 25/6/01 8:33 pm Page 8

Operation

1. Open the door and load the drum with

laundry. Ensure that garments do not

hinder closure of the door.

2. If drying delicate items press the

‘HEAT SETTING’ button to reduce the

heat level. Press again on completion, to

select high temperature.

3. Turn ‘DRYING TIME’ dial until the

required drying time aligns with the

symbol (▼).

4. Gently close the door pushing it slowly

until you hear the door ‘click’ shut.

5. Press the ‘ON’ button. The indicator

will light and the drying cycle begins.

6. The load is dried by tumbling in

thermostatically controlled warm air.

Cool air is used for the last 15 minutes

to reduce creasing and cool the load

ready for handling.

7. When the program is fully completed

the drum will stop rotating and the dial

will point to the symbol (▼).

Open the door and remove the load.

8. Clean the filter and empty the water

container after every drying cycle to

ensure maximum dryer efficiency.

(See ‘Filter’ and ‘Water Container’

sections).

9. Clean the condenser after

approximately every 10 drying cycles to

ensure maximum dryer efficiency.

(See ‘Condenser’ section).

1. ‘ON’ button and indicator – press to switch on, the indicator will light.

2. ‘HEAT SETTING’ button - press to reduce the heat level for delicate items, press

again to select high temperature.

3. ‘DRYING TIME’ dial - selects drying time or pre-ironing option (a).

4. ‘CLEAN FILTER’ indicator - lights when the filter needs cleaning.

5. ‘EMPTY WATER’ indicator - lights when water container is full.

Heat setting

Operation

WARNING!

THE DRUM, DOOR AND LOAD

MAY BE VERY HOT.

05651181 25/6/01 8:33 pm Page 9

Cleaning

Cleaning the dryer

IMPORTANT: Always switch off and

remove the plug from the electricity

supply before cleaning this appliance.

Clean the filter and empty the water

container after every drying cycle.

Regularly clean the condenser.

After each period of use, wipe the inside of

the drum and leave the door open for a

while to allow circulation of air to dry it.

Wipe the outside of the machine and the

door with a soft cloth.

DO NOT use abrasive pads or cleaning

agents.

To prevent the door sticking, periodically

clean the door gasket with a ‘non- scratch

cream cleaner.’

Technical

specifications

Drum capacity 115 litres

Maximum load 6 kg

Height 85cm

Width 60cm

Depth 60cm

Energy Label Band C

Note: For electrical data refer to the rating

label on the front of the dryer cabinet (with

the door open).

05651181 25/6/01 8:33 pm Page 10

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Candy Trockner Handbücher

Candy

Candy EVOC 580B Bedienungsanleitung

Candy

Candy Grand O comfort GCH 980NA1T Bedienungsanleitung

Candy

Candy GCC 590NB Bedienungsanleitung

Candy

Candy CDV 160 Bedienungsanleitung

Candy

Candy GO DC 68G Bedienungsanleitung

Candy

Candy GrandO GO DV 16 Bedienungsanleitung

Candy

Candy CSOE C9TE-S Bedienungsanleitung

Candy

Candy GCC 570NB Bedienungsanleitung

Candy

Candy Grand O Evo Easy Case Bedienungsanleitung

Candy

Candy Grand'O GO DV 38 Bedienungsanleitung

Candy

Candy CIC209X Bedienungsanleitung

Candy

Candy Grand Evo EVOH 971NA2T Bedienungsanleitung

Candy

Candy Slim Smart CR4 H7A1DE-S Bedienungsanleitung

Candy

Candy GO DC 78GT Bedienungsanleitung

Candy

Candy CS C8LF Bedienungsanleitung

Candy

Candy ROW4966DWMCE/1-S Bedienungsanleitung

Candy

Candy GCC 590NB Bedienungsanleitung

Candy

Candy GOC 970AT Bedienungsanleitung

Candy

Candy EVOC 781BT Bedienungsanleitung

Candy

Candy Grand O Comfort GCC 780NBT Bedienungsanleitung

Candy

Candy CDC266X CH Bedienungsanleitung

Candy

Candy EVOC 570B Bedienungsanleitung

Candy

Candy GCC 781NBT Bedienungsanleitung

Candy

Candy GO DC 218 Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
