Candy CDNF 3800 E Bedienungsanleitung

INSTRUCTIONS MANUAL

REFRIGERATOR

DOUBLE DOORS

CDNF 3800 E

ENGLISH

Page…1

ITALIAN Pagina…13

FRENCH Page…25

DEUTSCH

Seite…36

SPANISH

Página…48

PORTOGUESE

Página…60

GREEK ελίδα…72

POLISH Strona…84

CZECH Strana…96

RUMANIAN Pagina…108

HUNGARIAN Oldal…120

SLOVAK Strana…132

CROATIAN

Stranica…144

Please always follow the safety hint listed below:

The unit should be operated in the absence of flammable or

explosive fumes.

It is prohibited to put the flammable, acid or volatile goods

in cabinet.

Please unplug the unit first when you

replace the light bulb or repair the

refrigerator.

Please unplug the unit immediately if you find

any abnormal smell or smoke, and contact your

local service center.

Please don’t allow water on the cabinet, or put a

vessel full of water on the refrigerator. If the refrigerator

is wet, the electrical insulation capability may be weakened.

Hanging or sitting on the door is very dangerous, it

may overturn the unit and subvert the goods in (or on)

the refrigerator.

SAFETY PRECAUTIONS

ENGLISH

Due to the production’s improvement, the unit you purchased maybe different from below

sketch.

1. Freezer shelf

2. Control House freezer

3. Control House refrigerator

4. Shelf

5. Power plug

6. Crisper

7. Freezer door tray

8. Door shelve

9. Bottles door tray

10. Feet

PARTS

The unit should be placed in a ventilated and dry environment.

Do not put the unit in direct sunshine, and keep it as far

as possible from heat sources.

The unit should be placed on flat and steady ground.

Keep the unit level by adjusting the front leg levellers.

Don’t put the unit in cold area.

There should be enough spare space around the

unit as shown, to allow proper ventilation.

PLACEMENT

690mm

1284mm

600mm

965mm

Make sure the unit has been placed properly and

all instructions have been observed.

Adjust the control knob to the middle position,

and then plug in the unit.

OPERATION CHECK

The temperature in the fresh compartment is between

0~10 C, although this lower temperature can limit

the bacteria propagation, it is not suitable for a

long period of food storage.

FRESH FOOD STORAGE

Do not place hot food directly into the refrigerator.

The internal temperature will increase and force the

compressor to work harder and will consume more energy.

It is better to put the food in a sealed bag before placing

into the refrigerator.

In order to keep vegetables fresh in the crisper, any water should

be removed first, otherwise the vegetables may spoil. If you put

the vegetables in a bag, they may be stored for a longer period.

FOOD STORAGE

Control knob

It is used to adjust the temperature of different compartment. User can adjust for desired

temperature.

User can adjust the temperature of cooling or freezing by turn-control knob located at the back

of the cooling zone cabinet. According to the above picture, the highter knob is used for

controlling temperature of freezing while the lower one is for cooling.

Temperature shall get lower if turning the knobs by clockwise sense while it will get higher if

anticlockwise.

ATTENTION:

When the freezer control knob is set at “7”, you can turn the control knob of the fresh food

compartment to “4” or even smaller number to avoid too low storage temperature.

FROZEN FOOD STORAGE

The temperature of the freezer is colder than -18C. It is to store food to be

kept for a long period.

After buying frozen food, please put it into the freezer

compartment as soon as possible.

FOOD STORAGE

Any hot food must be cooled down to room temperature before

to put into the freezer.

Please don’t put glass containers filled with liquid into the freezer

compartment as the liquid into the freezer compartment as the

glass may break.

It is better to pre-sort the foods before putting them into the freezer.

Put the same kinds of food together to help to minimize the time of

the freezer door opening when you take the food out, and helps to

save energy.

The food should not be put too close to the outlet or

inlet of the airflow. It may affect the air circulation.

DOOR TRAY

There are some ventilation holes on the bottom of the door

tray, please try not to block all of them when you put the food in.

FOOD STORAGE

Cleaning

Always unplug the unit before cleaning.

The unit should be cleaned frequently both inside and

outside using water and a little neutral detergent .

never use boiling water, harsh cleaning agents, acid,

alkali or benzene etc.

Water pan cleaning

The water pan is located in the back of cabinet. Its function is

to collect and evaporate the defrost water. Usually it doesn’t

need special care , but if you find some water overflow or odd

smell, it may need to be checked and cleaned . pull out the

power cord first . lift the water pan up a little , and then pull it

straight out carefully (caution make sure the discharge pipe is

not too hot) after cleaning , re-fix the water pan into the original

position .Make sure that the pipe is on top of the water pan

before you push it into the original position.

Leaving the unit switched off

If the unit will be switched off for a long time ,the plug

should be pulled out , then clean the unit thoroughly .

Ensure that the door cannot be fully closed

(leave a suitable gap), and place the unit in a

well-ventilated area to avoid any odor.

MAINTENANCE
