Candy CMB655XGG Bedienungsanleitung
Instructions Book Made in China
Cooker Hood
Model CMB655XGG
CAUTION:Accessible parts may become not when used with cooking appliances.
In certain circumstances electrical appliance may be a danger hazard.
G) Disconnect the electrical plug prior to any maintenance.
F)Constantly check food frying to avoid overheated oil splashing and becoming a
fire hazard.
E)Avoid opening gasometer when there is no pan on the stove, as it is damaging
for the filters and a fire hazard.
D)Do not light a flame under the cooker hood.
C)Do not touch the light bulb within half an hour after appliance has been use.
B)Do not check the status of the filters while the cooker hood is operating.
A) There must be adequate ventilation of the room when the cooker hood is used
at the same time as appliances burning gas or other fuels.
H) Regulations concerning the discharge of air have to be fulfilled.
I) When the range hood and appliances supplied with energy Other than electricity
are simultaneously in operation.The negative pressure in the room must not
exceed 4 Pa (4x10 bar)
¯5
J)If the supply cord is damaged,it must be replaced by the manufacturer,its service
agent or similarly qualified persons in order to avoid a hazard.
K)This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
L)the range hood is inteded to be installed over a hob having no more than four hob
elements.
M) Indoor use and household use only
O) Attention ! Observe the warning in the instruction sheet concerning the operation
of the appliance when air is discharged from the room
N)When the appliance is not in use and before cleaning, unplug the appliance from
the outlet.
CAUTION:Accessible parts may become not when used with cooking appliances.
P) There is a fire risk if cleaning is not carried out in accordance with the instructions.
Know your cooker hood
Please read these instructions Before using your cooker hood
Congratulations on the
purchase of our Cooker hood,
which is designed to include
many superior features that
permit you the fullest
expression of your living.
Before installing and/or using
the cooker hood carefully read
all the instructions.
1
1.Filter assembly
2.Air duct assembly
3.Main body assembly
4.LED light
5.Bellows
6.Outside chimney
7.Inner chimney
2
3
5
6
7
4
1
We recommend that after
installation the bottom of
the hood should be no less
than 650mm and no more
than 750mm above the
stove's heating elements
and burners.
Check voltage and
Frequency given on the
rating plate located on the
inside of the hood.
The air must
not be discharged into
a flue that is used for
exhausting fumes from
appliances burning gas or
other fuels (not applicable
to appliances that only
discharge the air back into
the room)
Rating plate
Information and advice
Information
2
3
According to
the Fig.4
make sure the
position of the
hoods on the
wall. Then use
the stencil to
drill four 8
holes on the
wall. Fix four
sets expanding
plugs screws
at the four holes.
8
4
5
When
cutting or
drilling
into wall
or ceiling,
do not
damage
electrical
wiring or
other
hidden
utilities.
Screw down the four screws. first screw down the upper two screws, then
screw down the others.
Hang the
hood and
let it's two
installation
holes aim at
two screws,
adjust it to
setting
position.
10mm
Installation
work and
electrical
wiring must
be done by
qualified
person(s) in
accordance
with all
applicable
codes and
standards,
including
fire-rated
construction.
According to
the dimension
of the chimney
fixed bolster,
make sure the
position of the
two chimneys.
Put the outer
chimney on the
windshield.
Install the chimney fixed bolster on the corresponding position on
the wall.
8
13
To install
this hood
you will
require
two
assistants
