Candy CY2104-16S Bedienungsanleitung

W.MACHINE/WASHER-DRYER

31000970 CY2104-16S

Service Manual

31000970 CY2104-16S 0512 (17/03/2005)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

2 Programs disc 41014633 0648 (01/12/2006)

2 Programs disc 41015946 0648 (01/12/2006)

14h Therm/potent. knob spring 41013044 0648 (01/12/2006)

15 Cam disc 91602569 0648 (01/12/2006)

19a Button 0/1 41013656

31 Control panel 41015446

32 Dispenser drawer front 41014566

40 Insert 41013917

47 Table top front frame 91602091

48 R/H side frame 91601694

48a L/H side frame 91601695

49 Top rear frame 91601681

51 Work top 90489680

60 Hinge 91700102

62 Door surround 41013807

65a Door catch with spring service pack 49005361

67 Glass door with frame 41014742

67d Counter ring 41013808

76 Cabinet assy 41003254

77 Rear panel 90481367

78 Socle 41006148

79 Rear foot 90481375

80 Front foot 91671122

94d Filter w/knob without screw 41004157

97c Stopper x drain/recycle pump 91941774

97d Filt hous w/filter cartridge 49002227

101 Dispenser drawer 41000142 0648 (01/12/2006)

101 Dispenser drawer 41021547 0648 (01/12/2006)

103 Rack 91602943 0648 (01/12/2006)

109 Dispenser bottom section assy 91671224

109b Dispenser bottom section 41021545 0648 (01/12/2006)

110 Dispenser top section 41021549 0648 (01/12/2006)

31000970 CY2104-16S 0512 (17/03/2005)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

112 Distribution connecting rod 92884212 0648 (01/12/2006)

113 Lever 91602939 0648 (01/12/2006)

114 Driving lever 41000950 0648 (01/12/2006)

114a Hose clip 92470061

116 Cam 92621614 0648 (01/12/2006)

118 Spring 92483148 0648 (01/12/2006)

131 Hose clip 90249756

132 Valve hose cold water 90482365 0648 (01/12/2006)

132 Valve hose cold water 41021552 0648 (01/12/2006)

134 Solenoid valve 90450750 0648 (01/12/2006)

134 Solenoid valve 41021555 0648 (01/12/2006)

138 Drain hose 92693373

138a Drain house elbow 92689587

138b Hose clamp 92895051

142 Fill hose 92250869

151b Motorized selector 22 settings 41003735 0648 (01/12/2006)

151g selector 22 settings 41014503 0648 (01/12/2006)

153 Pressure switch 41008943 0541 (03/10/2005)

153 Pressure switch 41016044 0541 (03/10/2005)

157 Harness 41014812 0648 (01/12/2006)

157 Harness 41022622 0648 (01/12/2006)

157u 16 Way flat cable 41012505

161d Drain/recycle pump complete 41005956

162 Door safety device 91201208 0527 (01/07/2005)

162 Door safety device 41016879 0527 (01/07/2005)

164 Anti jamming filter radio 91212795 0648 (01/12/2006)

164 Anti jamming filter radio 91200098 0648 (01/12/2006)

202 Drum 91750615

203 Tub 41005500

204a Front flange 41006951

205 Drum shaft assy 92994862

211 Bolt 92419498

213a Spring 92436781

215 Tub gasket 92131689

31000970 CY2104-16S 0512 (17/03/2005)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

217 Seal retainer 92445600

218 Bearing 92440171

219 Bolt 92418714

221 Nut 90319153

224 Bearing 92440197

225a Gasket 92445626

230 Tub gasket clip 91750626

230a Tub gasket clip 90488603

232 Heater holder 92736586

242 Support spring. 92484492

242b L/H support spring 90481433

244 Washer 92430206

244a Counter weight washer 92430214

245a Asbestos washer 90318015

246 Bolt 90319336

246b Slide 04110150

247 Upper balance weight 41005511 0648 (01/12/2006)

247 Upper balance weight 41021554 0648 (01/12/2006)

248 Lower balance weight 90482423

250 Damper pads 92697838

251 Shoch absorber spring 92483049

256 Clamp 92851302

257 Damper slide 92863976

259 Support 92673961

271 Door gasket 90489151

272 Discharge pipe 41005510

273 Fill pipe 90440397

274 Pressure switch air chamber 91611202

275 5x8 hose 90416454

276 Steam hose 92604123

277 Hose spring 90386137

31000970 CY2104-16S 0512 (17/03/2005)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

279 Hose clip 92470285

281 Shock Absorder grommet 92606227

286 Heater 41009027

287m NTC probe 92743616

290 Drum pulley 41005509

292 Drive belt 41003164

292b Bottom panel 90489155

292c Clips 92473636

328 Control panel electronic module 41013732

328a Electronic module container 41014492

328f Pcb protection 41013672

422 Circlip 91941775

473a Commutator motor SOLE-ACC 41006952

479i Coreboard 32K programmed 49006361 0648 (01/12/2006)

479i Coreboard 32K programmed 49009943 0648 (01/12/2006)

479m Electronic control 32K not programmed 41014792 0648 (01/12/2006)

479m Electronic control 32K not programmed 41021513 0648 (01/12/2006)

483a Brush with brush holder 49000466

487 Special bolt 92419548

488 Rivet 92466655

491 Mains cable 91200194

535 Knob handle 41013665

547 Module protection 41003583

547a Module protection cover 91601843

556 Electric valve support 92883925 0648 (01/12/2006)

558a Press/timer bracket 92880814

571 Top sleeve 92730159

588 Siphon 41013613 0648 (01/12/2006)

622 Stopper D.12 90415761

630a Stopper drain hose 90434853

631 Stopper 90415951

632 Control support plate 41001410 0648 (01/12/2006)

31000970 CY2104-16S 0512 (17/03/2005)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

632 Control support plate 41013659 0648 (01/12/2006)

643 Door handle assembly 41013809

643a Handle plate 41014004

734 Timer protection 41009649

806 Door upper hinge 41013810

807 Door lower hinge 41013811

809 Cabinet hole stopper 90415753

828b Tach.coil 49000464

832 Discharge pipe circlip 91408004

833 Upper counterweight support 92898915

834 Lower counterweight supp. 92898923

835a Magnet 49000465

840 Drum paddle 91607697

841 Drum paddle fixing screw 92419555

856 Upper front crosspiece 90481151

999 Wiring diagram 41014083 0648 (01/12/2006)

999 Wiring diagram 41019172 0648 (01/12/2006)

1147 Transit bolt kit 49003280
