Caraudio-Systems TF-RTI11 Bedienungsanleitung

Version 05.11.2012 TF-RTI11

TV-Free

Video-in-motion Interface

TF-RTI11

for Volvo

RTI 2011 navigation systems

Legal Information

By law, watching moving pictures while driving is prohibited, the driver must not be

distracted. We do not accept any liability for material damage or personal injury resulting,

directly or indirectly, from installation or operation of this product. This product should only

be used while standing or to display fixed menus or rear-view-camera video when the

vehicle is moving, for example the MP3 menu for DVD upgrades.

Changes/updates of the vehicle’s software can cause malfunctions of the interface. We

offer free software-updates for our interfaces for one year after purchase. To receive a free

update, the interface must be sent in at own cost. Labor cost for and other expenses

involved with the software-updates will not be refunded.

Version 05.11.2012 TF-RTI11

Page1

Contents

1. Prior to installation

1.1. Delivery contents

1.2. Check compatibility of vehicle and accessories

1.3. Setting the Dip-switches of the CAN-Box TV-500

1.4. Pin-assignments

2. Installation

3. Activation of the video-in-motion function

3.1. Vehicles without extra equipment

3.2. Vehicles with extra equipment

4. Specifications

5. Technical support

1. Prior to installation

Read the manual prior to installation. Technical knowledge is necessary for installation. The

place of installation must be free of moisture and away from heat sources.

1.1. Delivery contents

CAN-box TV-500

HW_____ SW_____

Harness

TV-VOL01

Take down the SW-version and HW-version of the interface boxes, and store this

manual for support purposes.

Version 05.11.2012 TF-RTI11

Page2

1.2. Check compatibility of vehicle and accessories

1.3. Setting the Dip-switches of the Can-Box TV-500

Fahrzeug/ Navigation

Dip

Vehicles WITHOUT extra equipment (lane pilot,

distance assistant, city safety system)

OFF

Vehicles WITH extra equipment (lane pilot, distance

assistant, city safety system)

OFF

Note: Dip switch functions of the TV-500

Dip 1 –activation TV-free

Dip 2 –no function

Dip 3 –no function

Dip 4 –no function

Dip 5 –CAN-bus termination resistor on the vehicle side

Dip 6 –CAN-bus termination resistor on the head-unit side

Requirements

Vehicle Volvo S-series, V-series, XC60

Navigation RTI 2011

Limitations

Vehicles with lane pilot, The included green cable is used to activate the video-in-motion

distance assistant and function (+12V = activated).

city safety system

Lane pilot, distance assistant and city safety system do not work while TV-free is activated!

Version 05.11.2012 TF-RTI11

Page3

1.4. Pin-assignments

Pin-assignment factory monitor connector

Pin-assignment of the CAN-Box TV-500 (Molex 8pin)

●Red +12V battery power Pin 4

●Black Ground Pin 8

●Yellow CAN High Navi Pin 1

●Blue CAN Low Navi Pin 2

●●Yellow/Black CAN High Vehicle Pin 5

●●Blue/Black CAN Low Vehicle Pin 6

2. Installation

Switch off ignition and disconnect the vehicle’s battery! If according to factory rules

disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in

sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a

resistor lead.

Place of installation is at the back of the factory monitor.

3. Activation of the video-in-motion function

3.1. Vehicles without extra equipment

On vehicles without extra equipment and Dip1 to ON (see chapter “Setting the Dip-switches

of the Can-Box TV-500”) the video-in-motion function is activated permanently without

disturbing the navigation performance.

Cable colour

Assignment

●●Purple/Red

+12V Permanent

●●Black/Grey

Ground

●●Grey/Orange

CAN HIGH Pin 10

●●Purple/Orange

CAN LOW Pin 09

Back factory monitor

Version 05.11.2012 TF-RTI11

Page4

3.2. Vehicles with extra equipment

On vehicles with extra equipment and Dip1 to OFF (see chapter “Setting the Dip-switches of

the Can-Box TV-500”) the included green cable is used to activate the video-in-motion

function.

Connect a switch to the green cable and connect the green cable to +12V ACC.

●+12V = TV-Free is activated

●0V = TV-Free is not activated

Note: As long as the video-in-motion function is activated, the navigation will NOT be

working!

4. Specifications

Operation voltage 10.5 –14.8V

Stand-by power drain <2mA

Operation power drain ~60mA

Power consumption ~0,08W

Temperature range -30°C to +80°C

Weight 44g

Measurements (box only) W x H x D 76 x 27 x 54 mm

5. Technical Support

Caraudio-Systems Vertriebs GmbH NavLinkz GmbH

manufacturer/distribution corporate sales/tech dealer-support

Rheinhorststr. 22 Eurotec-Ring 45

D-67071 Ludwigshafen am Rhein D-47445 Moers

phone +49 180 3 907050

email [email protected]

Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered

trademarks ® of their corresponding legal owners.
