Operation
Warning: Before using your drill be sure to read the instruction
manual carefully .
Installing the auxiliary handle (see Dia 1)
For your personal safety we recommend using the
auxiliary handle at all times.
To fit the handle, loosen the locking screw for
handle collar anti-clockwise. Slide clamping loop
over the handle collar. Rotate the handle around
the handle collar until the handle is in the desired
position. Tighten the locking screw clockwise to
secure the handle. If you are right handed fit the
handle as shown in Dia2. If you are left handed fit
the handle the other way round.
Installing the depth gauge (see Dia 2)
The depth gauge can be used to set a constant
depth to drill. To use the depth gauge, loosen the
locking screw for gauge by rotating the auxiliary
handle anti-clockwise. Insert the depth gauge
through hole in handle. Slide the depth
gauge to required depth and tighten the locking
screw by rotating the locking screw clockwise.
Inserting the key into chuck (see Dia 3)
Warning: Before installing tool,
remove mains plug from mains supply .
Remove chuck key from key storage tab at base
of drill handle, place key into chuck, turn key
anti-clockwise to undo/loosen chuck, inset
drill/tool and firmly tighten chuck by turning
key clockwise. Remove key and replace in storage
tab at base of drill handle.
Operating the On/Off switch (see Dia 4)
Press the on/off switch in for operation, release
switch to stop.If you wish to use the drill
continuously the switch lock button can be
pushed in after the on/off switch has been
depressed. To release the lock button simply
depress on/off switch fully, the button will
automatically release.
Variable speed control selector (see Dia5)
The maximum speed can be altered by turning
the variable speed control. Turn clockwise to
increase and anti-clockwise to decrease speed.
The speed of the drill varies with the amount of
pressure applied to the on/off switch, i.e. more
pressure for higher speed.
