REFRIGERATION CONNECTION

CPR ADJUSTMENT

CHARGE

TXV ADJUSTEMENT

Carrier

T R A N S I C O L D

& INTEGRA 35 X

P/N : 62-61309-01 / rev B

ITEM P/N

90° ORS 1/4->3/8" 40-60048-01

90° ORS 3/8" 40-60048-02

135° ORS 3/8" 40-60049-02

90° ORS 1/2" 40-60048-03

90° ORS 5/8" 40-60048-04

90° ORS 3/4" 40-60048-05

135° ORS 1/2"-->5/8" 40-60049-06

90° O-RING 5/8" 40-60061-04

90° O-RING 1/2" 40-60061-03

180° O-RING 1/2" 40-60060-03

90° O-RING 5/8" 40-60061-04

180° O-RING 5/8" 40-60060-04

90° O-RING 5/8"->3/4" 40-60061-07

180° O-RING 5/8"->3/4" 40-60060-07

HP SERVICE VALVE 1/2" 40-60059-03

LP SERVICE VALVE 3/4" 40-60058-05

CLAMP 3/8" (mod 6) 34-60019-02

CLAMP 1/2" (mod 8) 34-60019-03

CLAMP 5/8" (mod 10) 34-60019-04

CLAMP 3/4" (mod 12) 34-60019-05

HOSE 3/8" (mod 6) 58-60115-02

HOSE 1/2" (mod 8) 58-60115-03

HOSE 5/8" (mod 10) 58-60115-04

HOSE 3/4" (mod 12) 58-60115-05

CHECK VALVE 3/8" (option) 14-00286-00

Standby suction

90° O-RING 5/8"

Liquid

180° ORS 3/8"

Hot gas

90° ORS 3/8"

Road discharge

90° ORS 1/2"

Standby suction

90° ORS 5/8"

Road suction

O-Ring pilot 3/4"

Hot gas

90° ORS 3/8"

LP service valve

3/4"

Oil return

90° ORS 1/4"->3/8"

HP service valve,1/2"

Carrier

T R A N S I C O L D

Road Suction

90° ORS 3/4"

Road discharge

O-Ring pilot 1/2"

Liquid

90° ORS 3/8" Check valve

With HGS2 only

OPERATING CONDITIONS

Road ONLY (2400 rpm)

Heating or Defrost mode

Run the unit on " HEAT or DEFROST " mode

Adjust the CPR to get the following gauge pressure values

STANDARD ADJUSTMENT

XARIOS 350 : 2,4 bars (35 psig) !Pressure value is given at the CPR port

!CPR adjustment must be increased by :

0,1(bar) x D(m)

D: Evaporator location from the front of the box (in meter)

3 m

6 m

Carrier

T R A N S I C O L D

Standard

Standard + 0,6

Standard + 0,3

OPERATING CONDITIONS

Road (2400 rpm) or Standby mode

Run the unit on

"COOL " mode

INITIAL CHARGE

XARIOS 350 = 1,7 Kg

!COMPLETE THE CHARGE ON THE SIGHT GLASS

AT 0°C BOX TEMPERATURE

Po : Pressure at manifold

To : Temperature at manifold

T1 : Temperature with thermocouple

SUPERHEAT = To - T1

The superheat should be :

!8°C at 0°C box T° (14.4°F at 32°F box T°)

4°C at -20°C box T° (7.2°F at -4°F box T°)

Carrier

T R A N S I C O L D

Beginning of

evaporating

Evaporating of the last liquid drop

Remote the bulb location

Superheat area

P0 - T0
